- Page 1 Network Camera Installation Manual DC-D4536RX DC-D4536HRX DC-D4536RX-A DC-D4536HRX-A Powered by...
- Page 2 Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
- Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
- Page 4 IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements.
-
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
• Two-way audio communication support for remote Ethernet. audio dialog DC-D4536RX, DC-D4536HRX models only You can use the IDIS Discovery program to change • Video stream buffering to counter pre-/post-event network camera settings or the IDIS Solution Suite buffering and network delays for improved network... - Page 7 • Network-based integrated management of multiple Remote monitoring and recording via multi streaming network cameras are available using the IDIS Solution Suite Compact • Multiple event detection modes program. For more information on using IDIS Solution Suite Compact, refer to its operation manual.
-
Page 8: Accessories
Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. DC-D4536RX/DC- DC-D4536HRX/DC- D4536RX-A D4536HRX-A Terminal Blocks (2 ea.) Network Camera Desiccant (3ea.), double-sided tape (2ea.) Allen Wrench DC-D4536RX/DC-... -
Page 9: Overview
Part 1 – Introduction Overview Body DC-D4536RX/DC-D4536RX-A Dome Cover DC-D4536RX/DC-D4536RX-A DC-D4536HRX/DC-D4536HRX-A... - Page 10 For more information on network connection setup, refer to the IDIS Discovery operation manual. The table below shows the network cable specifications. <The network cable specifications>...
- Page 11 Part 1 – Introduction • Alarm • Check your local laws and regulations on making - O (Out): It is the BJT (Bipolar Junction Transistor) video or audio recordings. The user will be held - open collector output. If the voltage and current liable for any violation of the law.
-
Page 12: Factory Reset
It's also possible to do a factory reset by pressing and releasing the reset button while the camera is turned on or using the IDIS Discovery program from a remote location. A factory reset will reboot the system. For more information on factory reset, refer to the IDIS Discovery operation manual. -
Page 13: Inserting A Sd Memory Card
Insert a SD memory card into the SD memory card slot Loosen the screws counterclockwise using the allen with the 'micro SD' print facing upward. wrench provided with the product. DC-D4536RX/DC-D4536RX-A DC-D4536HRX/DC-D4536HRX-A Remove the dome cover. Push the SD memory card until it disengages from the... -
Page 14: Installation
• Install the camera in a shaded area. If the camera is installed in direct sunlight, it may be affected adversely. DC-D4536RX/DC-D4536RX-A Make the LAN cable go through the cable rubber Use the screws, anchor provided with the camera to using the protect connector. - Page 15 Part 1 – Introduction Use the screws, anchor provided with the camera to To pass through a thin cable or more than two cables, secure the install body on a wall or a ceiling. it is advised to finish it using silicon to make sure waterproofed perfectly.
-
Page 16: Angle Adjustment
Part 1 – Introduction Angle Adjustment Closing the Dome Cover The lens can be rotated along three axes. DC-D4536RX/DC-D4536RX-A Attach the dome cover to the bottom cover. Turn the dome cover clockwise to fasten the dome cover. Lens Rotation Horizontal Rotation Vertical Rotation •... -
Page 17: Dimension
Part 1 – Introduction Fasten the screws for the dome cover clockwise Dimension using the Allen wrench provided with the camera. DC-D4536RX/DC-D4536RX-A Ø 122.4mm Ø 100mm Remove the protective film inside and outside. - Page 18 Part 1 – Introduction DC-D4536HRX/DC-D4536HRX-A Ø 100mm Ø 155mm...
-
Page 19: Part 2 - Camera Connection
Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Audio In Audio Out Alarm Out Power Sensor In Network Camera Monitor Out... -
Page 20: With Non Directip™ Nvr-Based Layout
Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP™ NVR connection or VMS connection such as IDIS Solution Suite Compact. -
Page 21: Part 3 - Appendix
ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 8.0 or below. -
Page 22: Specifications
Part 3 - Appendix Specifications These product specifications may change without prior notice. Video Image Sensor 1/2.8" CMOS Max. Resolution 2592 x 1944 (4:3) 2592 x 1456 (16:9) Scanning Mode Progressive Scan Lens type Motorized Vari-focal Focal Length f=3.0 - 13.5mm Aperture F=1.4 ~ 3.2 Iris Control... - Page 23 Test the SD memory card regularly and replace it whenever necessary. * microSD Logo is a trademark of SD-3C, LLC. Audio In/Out DC-D4536RX, Line-in 1ea / Line-out 1ea / Internal Mic 1ea( DC-D4536RX only DC-D4536HRX only Alarm In 1 TTL, NC/NO Programmable, 4.3V(NC) or 0.3V(NO) threshold, 5V DC Alarm Out 1 TTL open collector, Max.
- Page 24 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
