- Page 1 Network Camera Installation Manual DC-D4532WERA Powered by...
-
Page 2: Before Reading This Manual
Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product. -
Page 3: Safety Precautions
Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1. -
Page 4: Fcc Compliance Statement
IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements. -
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
• Wide dynamic range compensation (True WDR) for compresses and transmits video over Ethernet. improved video quality in high-contrast situations You can use the IDIS Discovery program to change • Slow shutter support for improved low-lighting video network camera settings or the IDIS Solution Suite... -
Page 7: Accessories
Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. RJ45 moduler jack, RJ45 waterproof rubber ring, RJ45 Network Camera connector protect cover, cable waterproof rubber ring, RJ45 connector back cover Guide Pattern Allen Wrench Quick Guide... -
Page 8: Overview
Part 1 – Introduction Overview • Wall/Ceiling Installation Hole Used to screw the camera in place on a wall or a ceiling. • Top Cover Assembly Guide The top cover rotates on the bottom cover and is tightened. • SD Memory Card Slot Used to insert a micro SD memory card into the camera. -
Page 9: Cable
For more information on network connection setup, Connect a mechanical or electrical switch to the refer to the IDIS Discovery operation manual. alarm in port and the GND (ground) connector. Alarm in range is 0V to 5V. In order to detect alarm... -
Page 10: Factory Reset
It's also possible to do a factory reset by pressing and releasing the reset button while the camera is turned on or using the IDIS Discovery program from a remote location. A factory reset will reboot the system. For more information on factory reset, refer to the IDIS Discovery operation manual. -
Page 11: Inserting A Sd Memory Card
Part 1 – Introduction Inserting a SD Memory Card Waterproof Cable Installation Loosen the screws counterclockwise and remove the RJ45 waterproof rubber ring cover. RJ45 modular jack RJ45 waterproof rubber ring RJ45 modular jack RJ45 waterproof rubber ring RJ45 connector protect cover RJ45 modular jack cable waterproof rubber ring (The waterproof rubber ring is fastened to the connector protect cover.) - Page 12 Part 1 – Introduction Installation • Check the wall or ceiling to see if it needs to be reinforced. The camera may fall off if the wall or ceiling is not strong enough to support its weight. • Install the camera in a shaded area. If the camera is installed in direct sunlight, it may be affected adversely.
-
Page 13: Angle Adjustment
Part 1 – Introduction Angle Adjustment After the angle adjustment is finished, tighten the front screw to completely attach the main body. The lens can be rotated along three axes. The top cover rotates on the bottom cover and is tightened. As shown in the picture, align the markings on the bottom cover and the top cover of the main body and join them. -
Page 14: Dimension
Part 1 – Introduction Dimension Ø 135mm... -
Page 15: Part 2 - Camera Connection
Part 2 - Camera Connection Use the camera by connecting to DirectIP® NVR or non DirectIP® NVR, VMS such as IDIS Solution Suite Compact. With DirectIP® NVR-based Layout Audio In Audio Out Alarm Out Power Alarm In Network Camera Monitor Out... -
Page 16: With Non Directip® Nvr-Based Layout
Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP® NVR connection or VMS connection such as IDIS Solution Suite Compact. -
Page 17: Part 3 - Appendix
ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 10 or below. -
Page 18: Specifications
Part 3 - Appendix Specifications These product specifications may change without prior notice. Video Image Sensor 1/2.8" CMOS Max. Resolution 2592 x 1944 (4:3) 2592 x 1456 (16:9) Scanning Mode Progressive Scan Lens type Motorized Vari-focal Focal Length F1.6 ~ 3.3, f=3.2mm ~ 10.5mm Iris Control P-IRIS Angular... -
Page 19: Operating Humidity
Part 3 - Appendix Edge Storage* (Optional) (Micro SD/SDHC/SDXC memory card (class 6 or higher, max. 512GB)) * An SLC (Single Level Cell) or MLC (Multi Level Cell) card by SanDisk or Transcend is recommended to ensure stable recording performance. * An SD memory card is a consumable product with a finite service life. - Page 20 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
