- Page 1 DVDO-Matrix-88 18Gbps 8x8 HDMI Matrix with ARC Function User Manual Version: V1.0.0...
- Page 3 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Table Of Contents
Table of Contents Introduction ...................... 5 Features......................5 Package Contents ................... 5 Specifications ....................6 Controls and Functions ..................7 IR Remote ......................9 IR Cable Pin Assignment ................10 EDID Management ..................11 Web GUI ......................13 RS-232 Control ....................19 Application Example .................. -
Page 5: Introduction
Introduction This 18Gbps 8x8 HDMI Matrix supports the transmission of video (up to 4K2K@60Hz YUV 4:4:4) and multi-channel high resolution digital audio from 8 HDMI sources to 8 HDMI displays. Audio de-embedded to analog and coaxial audio is supported from 8 HDMI output ports. -
Page 9: Ir Remote
IR Remote ① Power on or Standby: Power on the Matrix or set it to standby mode. ② Input 1/2/3/4/5/6/7/8: Select input source button. : Select the last or next input source button. Input ③ Output 1/2/3/4/5/6/7/8: Select output source button. All: Select all output source simultaneously. -
Page 10: Ir Cable Pin Assignment
below. IR Cable Pin Assignment... -
Page 11: Edid Management
EDID Management This Matrix has 21 factory defined EDID settings, 2 user-defined EDID modes and 8 copy EDID modes. You can select defined EDID mode or copy EDID mode to input port through front panel buttons, RS-232 control or Web GUI. On the initial OLED display screen, press “MENU”... - Page 12 The defined EDID setting list of the product is shown as below: EDID Mode EDID Description 1080p, Stereo Audio 2.0 1080p, Dolby/DTS 5.1 1080p, HD Audio 7.1 1080i, Stereo Audio 2.0 1080i, Dolby/DTS 5.1 1080i, HD Audio 7.1 3D, Stereo Audio 2.0 3D, Dolby/DTS 5.1 3D, HD Audio 7.1 4K2K30_444, Stereo Audio 2.0...
- Page 13 Web GUI User Guide The Matrix can be controlled by Web GUI. The operation method is shown as below: Step 1: Get the current IP Address. The default IP address is 192.168.1.100. You can get the current Matrix IP address in two ways: The first way: You can get the IP address via panel buttons.
- Page 14 After entering the password, click the “LOGIN” button and the following Status page will appear. ■ Status Page The Status page provides basic information about the Model, the installed firmware version and the network settings of the device. ■ Video Page You can do the following operations on the Video page: ①...
- Page 15 ■ Input Page You can do the following operations on the Input page: ① Inputs: Input channel of the device. ② Active: It indicates whether the channel is connected to a signal source. ③ Name: The input channel’s name. You can modify it by entering the corresponding name (max length: 12 characters) in the input box (Chinese name is unsupported).
- Page 16 ■ Output Page You can do the following operations on the Output page: ① Outputs: Output channel of the device. ② Name: The current output channel’s name. You can modify it by entering the corresponding name (max length: 12 characters) in the input box (Chinese name is unsupported). ③...
- Page 17 ■ Network Page Set the Default Network Click “Set Network Defaults”, there will be a prompt, as shown in the following figure: Click “OK” to search the IP Address again, as shown in the following figure: After searching is completed, it will switch to the login page, the default network setting is completed.
- Page 18 Modify Username Click the “User” button, enter the correct Old Password, New Password, and Confirm Password, then click “Save”. After successful modification, there will be a prompt, as shown in the following figure: Note: Input rules for changing passwords: The password can’t be empty. New Password can’t be the same as Old Password.
