User's Manual
Model ______________
SWTC1500
WARNING
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
Maximum user weight 200 lbs
IMPORTANT
Trampoline and Enclosures are
susceptible to winds. Be sure to
secure your trampoline and enclosure.
Wind Damage is not covered in the
warranty of your trampoline

Advertisement

loading
Need help?

Need help?

Do you have a question about the SWTC1500 and is the answer not in the manual?

Questions and answers

Related Manuals for Skywalker SWTC1500

Summary of Contents for Skywalker SWTC1500

  • Page 1 User’s Manual Model ______________ SWTC1500 WARNING Read all precautions and instructions in this manual before using this equipment. Save this manual for future reference. Maximum user weight 200 lbs IMPORTANT Trampoline and Enclosures are susceptible to winds. Be sure to secure your trampoline and enclosure.

  • Page 2: Trampoline Placement

    ASSEMBLY ASSEMBLY (PUTTING THE TRAMPOLINE AND ENCLOSURE TOGETHER) IMPORTANT ASSEMBLY INFORMATION • Need phillips screw driver (included with trampoline) and 2 adjustable wrenches (for putting the trampoline together). A rubber mallet is also recommended to make assembly easier. • Assembly requires two adults. Keep children away from the trampoline and enclosure until they are completely put together. •...
  • Page 3 Note: This step requires two persons. During this Leg Section step, you will connect the six assembled leg sections with the remaining six Top Tubes (1). Flip two of the leg sections over so that the spring holes are now facing the sky instead of the ground. Stand two leg sections and hold them in the positions shown.
  • Page 4 After attaching the first four Springs (8) in step 4, start Inset drawing from the first spring you attached in step 4. Count exactly 12 V-ring V-rings and 12 frame holes in a clockwise direction. Attach another Spring to the V-ring and frame at this point. Count 24 V-rings and 24 frame holes in a clockwise direction and attach another Spring.
  • Page 5 Frame Using the included plastic tie, attach the Safety Placard to the frame near the point where jumpers will climb onto and off the trampoline. Safety Placard The trampoline is now fully assembled. Make sure that all parts are securely attached. Familiarize yourself and all users of the trampoline with the safety precautions, use and instructional materials, and care and maintenance instructions in this manual before using the trampoline.
  • Page 6 Enclosure Assembly 1. Sleeve the Straight Tube (5) and Curved Tube (6) with foam (8). Lay one Straight Tube (5) with foam and one Curved Tube (6) with foam on the ground, insert the StraightTube(5) into the curved tube(6), secure with the screw(4).
  • Page 7 Spring Jump mat V-ring Attach the Jump Mat to the trampoline frame by refer- ring to steps 4-5 in the trampoline assembly Align opening of enclosure Be sure to place the door opening in the enclosure net- as shown here, centered in between the legs of the ting so it is centered in between the two legs of the tra- trampoline.
  • Page 8 Poles Note: In Step 6 you will secure the enclosure poles to the frame of the trampoline. Start from the enclosure door, lift one of the poles assembled in Step 1, see the insert drawing. Insert the Straight Tube(5) Enclosure into the top hole of the Square Socket on trampoline frame Door as shown.
  • Page 9 . Insert the end cap(3) into the bottom hole of the Socket. socket Insert end cap(3) into end of Socket Your trampoline enclosure is now fully assembled (put together). Make sure that all parts are securely attached. Familiarize yourself and all users with the trampoline and enclosure with the safety precautions, use and instructional materials, and care and mainte- nance instructions in this manual before using the...

  • Page 10: Maintenance

    WARNING TRAMPOLINE AND ENCLOSURE CARE AND MAINTENANCE Care To avoid damage to the trampoline and enclosure, do not allow pets or animals inside the enclosure. The trampoline is intended to be used by one person at a time who weighs not more than 200 pounds. The user should be either barefoot, wearing socks, or wearing gymnastic shoes.

  • Page 11: Ordering Replacement Parts

    EXPLODED DRAWING AND PARTS LIST FOR TRAMPOLINE Qty. Description Qty. Description Springs Top Tube with T-joint Spring Tool Top Tube with Socket Screw Driver Leg extension User’s Manual and Safety Placard Brace Set of ASTM Frame Labels Jump Mat Frame Pad t - f (two spare parts) # These parts are not illustrated.
  • Page 12 EXPLODED DRAWING AND PARTS LIST FOR ENCLOSURE . y t . y t Pole Cap M5x50mm Bolt Mesh with straps End Cap t - f w(1 spare parts) Screw Driver (screw driver included with Trampoline parts ) s ’ r # These parts are not illustrated.
