User's Manual
OWTCS1414
Model
WARNING
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
Maximum user weight 250 lbs
IMPORTANT
Trampoline and Enclosures are
susceptible to winds. Be sure to
secure your trampoline and
enclosure.
Wind Damage is not covered in
the warranty of your trampoline

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWTCS015 and is the answer not in the manual?

Questions and answers

Related Manuals for Skywalker SWTCS015

Summary of Contents for Skywalker SWTCS015

  • Page 1 User’s Manual OWTCS1414 Model WARNING Read all precautions and instructions in this manual before using this equipment. Save this manual for future reference. Maximum user weight 250 lbs IMPORTANT Trampoline and Enclosures are susceptible to winds. Be sure to secure your trampoline and enclosure.

  • Page 2: Table Of Contents

    Model SWTCS015 A serial decal is found on one of the trampoline legs. Model number decal tag is located on the jumping mat. CONTENTS Important Precautions........3 Warning Label Placement........4 Before You Begin..........4 Trampoline Safety Information......5 Enclosure Safety Information.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read and follow all of the warnings, precautions, and instructions in this manual before you use the trampoline enclosure. Warnings and instructions for care, maintenance, and use of this trampoline enclosure are included to promote safe, enjoyable use of this equipment. 1.

  • Page 5: Warning Label Placement

    (not included). BEFOREYOU BEGIN Thank you for choosing your Skywalker Trampolines brand Trampoline. The Skywalker Trampoline square Trampolines are designed and crafted to provide many years of fun and fitness. This trampolines comes equipped with warnings and instructions for the assembly, care, maintenance, and use of the trampoline.

  • Page 6: Trampoline Safety Information

    TRAMPOLINE SAFETY INFORMATION In trampoline use, as in all active recreational sports, participants can be injured. However, there are steps that can be taken to reduce the risk of injury. In this section, primary accident patterns are identified and the responsibilities of supervisors and jumpers in accident prevention are described.

  • Page 7: Enclosure Safety Information

    ENCLOSURE SAFETY INFORMATION NEED FOR TRAMPOLINE ENCLOSURE SAFETY A trampoline enclosure is a recreational product. The information on this page and on pages 7-9 identify important safety precautions. The precautions are not all-inclusive, because an enclosure can be used in ways that this manual cannot cover completely. To prevent pinches and cuts during enclosure use, a frame pad must be installed on the trampoline (See the trampoline manufacturer’s instructions).

  • Page 8: Methods Of Accident Prevention

    METHODS OF ACCIDENT PREVENTION The Supervisor's Role in Preventing Accidents It is the responsibility of the supervisors of trampoline users to provide knowledgeable and mature supervision. They need to know and enforce all of the rules and warnings printed in this manual to minimize the likelihood of accidents and injuries.
  • Page 9 • Wear clothing that does not have drawstrings, hooks, loops or anything else that could get caught while using the trampoline/enclosure and result in entanglement or strangulation, or both. • Do not attach anything to the netting that is not a Skywalker Trampolines approved accessory or part of the of the trampoline enclosure.

  • Page 10: Use And Instructional Material

    When you are through the door and sitting on the frame pad, carefully step or jump to the ground. Close the zippers and refasten the plastic clips. For additional information regarding equipment, contact Skywalker Holding, LLC. For additional information regarding skill training, contact a trainer certification organization.

  • Page 11: Instructional Program And Model Lessons

    INSTRUCTIONAL PROGRAM AND MODEL LESSONS The following lessons are examples of an instructional program. They should follow a complete discussion and demonstration of body mechanics between the supervisor and the student(s). See pages 11 and 12 for descriptions of basic trampoline skills. Lesson 1 1.

  • Page 12: Basic Trampoline Skills

    BASIC TRAMPOLINE SKILLS Fundamental Bounce Knee Drop 1. Start from a standing position with your head erect 1. Start bouncing from a standing position, keeping your and your eyes on the frame pad. eyes on the frame pad. 2. Swing your arms forward and up in a circular motion. 2.
  • Page 13 BASIC TRAMPOLINE SKILLS Seat Drop Front Drop 1. Land in a sitting position with your legs parallel to the 1. Start from a low bounce and land on the mat in a mat. prone position. 2. Place your hands on the mat beside your hips. 2.

  • Page 14: Assembly

    ASSEMBLY ASSEMBLY (PUTTING THE TRAMPOLINE AND E NCLOSURE TOGETHER) IMPO R TANT ASSEMB LY INFOR MATION • Need phillips screw driver (included with trampoline) and 2 adjustable wrenches (for putting the trampoline together). A rubber mallet is also recommended to make assembly easier. •...
  • Page 15 Corner Tube Leg Post Key #1 Key #4 2.4 ” Diameter 2.4 ” Diameter w/ spring holes Key #2 2.4 ” Diameter Frame tube with square holes w/ spring holes Middle tube with bend Key #3 2.4 ” Diameter w/ spring holes 2.4 ”...
  • Page 16 2. Assemble Male curved Leg Brace (6) to the Female leg (5) before assembling the rest of the legs. Secure Female leg (5) sections with M6x70 Bolt(12) and M6 Washer(18) and M6 Nut(11). 11 18 18 11 Insert one end of the Leg Post (4) into the Leg Braces (5,6) assembled above.
  • Page 17 hands as the Springs and frame joints can pinch.
  • Page 18 Big Gold Color Springs 5. Attach the Springs as follows: Hook one end of a Spring into a V-ring. (See the inset drawing.) Hook the Spring tool to the free end of the first Big Gold Spring. Using the Spring Tool pull the first Spring until it Color Springs reaches the frame.
  • Page 19 Safety Note: Do not use the trampoline without the Frame Pad. The Frame Pad comes in 2 pieces. The Frame Pad is designed to reduce the possibility of injuries due to jumpers coming in contact with the trampoline frame. If you do not have a Frame Pad, contact your dealer to obtain one.
  • Page 20 Enclosure Assembly Slide an enclosure foam (6) onto the top curved tube (4). Lay two L-corner tubes(3), the top curved tube(4) and two middle tubes(5) on the ground as shown. Attach together using#8 screws(1) one by one, don’t tighten yet. Note: Top curved tube should be curved down.
  • Page 21 4. Locate one strap(9) with D-rings to the upper edge of the Netting. Lift the end of the strap(9) and insert it small belt through the small belt sewn on the upper edge of the netting,see the right drawing. Then Lift D-ring and hold it close to an L-tube(3)as shown in Inset Drawing A.
  • Page 22 Warning: Take care not to fall, use a ladder if needed. Attach the Netting (8) to the other L-tubes (3) and Inset Drawing A curved tubes(4) with the other Straps (9) in the same manner. 5. Tighten the Straps (9) attaching the Netting (8) to the L-tubes (3) and curved tubes(4) .

  • Page 23: Care And Maintenance

    WARNING TRAMPOLINE AND ENCLOSURE CARE AND MAINTENANCE Care To avoid damage to the trampoline and enclosure, do not allow pets or animals inside the enclosure. The trampoline is intended to be used by one person at a time who weighs not more than 250 pounds. The user should be either barefoot, wearing socks, or wearing gymnastic shoes.

  • Page 24: Exploded Drawing And Parts List

    EXPLODED DRAWING AND PARTS LIST FOR TRAMPOLINE Qty. Description Big Gold Color Springs Corner Frame Pieces Frame Pads Frame Tube with Square hole M6 Nut Middle Tube M6X70 Bolt Leg Posts M10X80 Bolt Female Curved Legs M10 Nut Male Curved Legs Bolt End Cap Stitched Bed with 88 V-Rings M10 Washer...

  • Page 25: Ordering Replacement Parts

    EXPLODED DRAWING AND PARTS LIST FOR ENCLOSURE Qty. Description Qty. Description Self-tapping Screw Foam End Cap Straight Tube L-corner tube Netting with attached Hardwar Curved Tube Strap with D-rings User’s Manual Middle Tubes Specifications are subject to change without notice. ORDERING REPLACEMENT PARTS To order replacement parts, visit our web site at www.skywalkertrampolines.com or call our toll-free Customer Care Hot Line at 1-866-603-Jump (5867), Monday through Friday, 8 a.m.

  • Page 26: Limited Warranty

    Skywalker Holdings, LLC authorized service center, or to products used for commercial or rental purpose. No other Warranty beyond that specifically set forth above is authorized by Skywalker Holdings, LLC.
