User's Manual
Model______________
SWTC16WS
WARNING
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
Maximum user weight 200 lbs.
IMPORTANT
CAUTION: Adult Assembly
Required
Trampoline and Enclosures are
susceptible to winds. Be sure to
secure your trampoline and enclosure.
Wind Damage is not covered in the
warranty of your trampoline

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWTC16WS and is the answer not in the manual?

Questions and answers

Related Manuals for Skywalker SWTC16WS

Summary of Contents for Skywalker SWTC16WS

  • Page 1 User’s Manual Model______________ SWTC16WS WARNING Read all precautions and instructions in this manual before using this equipment. Save this manual for future reference. Maximum user weight 200 lbs. IMPORTANT CAUTION: Adult Assembly Required Trampoline and Enclosures are susceptible to winds. Be sure to secure your trampoline and enclosure.

  • Page 2: Table Of Contents

    SWTC16WS Model_____________ A serial decal is found on one of the trampoline legs. Model number decal tag is located on the jumping mat. CONTENTS Important Precautions...........3 Warning Label Placement........4 Before You Begin..........4 Trampoline Safety Information......5 Enclosure Safety Information.......6 Methods of Accident Prevention......7 Important Warnings..........8...

  • Page 3: Important Precautions

    USE INSTRUCTIONS WARNING: To reduce the risk of serious injury, read and follow all of the warnings, precautions, and instructions in this manual before you use the trampoline enclosure. Warnings and instructions for care, maintenance, and use of this trampoline and enclosure are included to promote safe, enjoyable use of this equipment. It is the responsibility of the owner and supervisors of the Do not attach anything to the enclosure barrier that is not a trampoline and enclosure to make sure all users obey the safety...

  • Page 4: Warning Label Placement

    BEFORE YOU BEGIN Thank you for choosing your Skywalker Trampolines brand Trampoline. Skywalker Trampoline round Trampolines are designed and crafted to provide many years of fun and fitness. This trampoline comes equipped with warnings and instructions for the assembly, care, maintenance, and use of the trampoline.

  • Page 5: Trampoline Safety Information

    TRAMPOLINE SAFETY INFORMATION In trampoline use, as in all active recreational sports, participants can be injured. However, there are steps that can be taken to reduce the risk of injury. In this section, primary accident patterns are identified and the responsibilities of supervisors and jumpers in accident prevention are described.

  • Page 6: Enclosure Safety Information

    ENCLOSURE SAFETY INFORMATION NEED FOR TRAMPOLINE ENCLOSURE SAFETY A trampoline enclosure is a recreational product. The information on this page and on pages 7-9 identify important safety precautions. The precautions are not all-inclusive, because an enclosure can be used in ways that this manual cannot cover completely. To prevent pinches and cuts during enclosure use, a frame pad must be installed on the trampoline (See the trampoline manufacturer’s instructions).

  • Page 7: Methods Of Accident Prevention

    METHODS OF ACCIDENT PREVENTION The Supervisor's Role in Preventing Accidents It is the responsibility of the supervisors of trampoline users to provide knowledgeable and mature supervision. They need to know and enforce all of the rules and warnings printed in this manual to minimize the likelihood of accidents and injuries.

  • Page 8: Important Warnings

    • Wear clothing that does not have drawstrings, hooks, loops or anything else that could get caught while using the trampoline/enclosure and result in entanglement or strangulation, or both. • Do not attach anything to the netting that is not a Skywalker Trampolines approved accessory or part of the of the trampoline enclosure.

  • Page 9: Use And Instructional Material

    D-ring on the jump mat and that the horizontal clips are attached to the D-rings on the enclosure netting, both during use and after use. For additional information regarding equipment, contact Skywalker Holding, LLC. For additional information regarding skill training, contact a trainer certification organization.

  • Page 10: Instructional Program And Model Lessons

    INSTRUCTIONAL PROGRAM AND MODEL LESSONS The following lessons are examples of an instructional program. They should follow a complete discussion and demonstration of body mechanics between the supervision and the student(s). See also page 11. 1. Mounting and dismounting (getting on and off)-Demonstration and practice of proper techniques. 2.
  • Page 11 Lesson 5: Seat Drop Lesson 6: Front Drop 1. Review and practice of skills already learned. 1. To save time and avoid mat (bed) burns, all students should 2. Land in a sitting position with your legs parallel to the be requested to assume the front drop position on the floor mat.

  • Page 12: Part Identification Chart

    Model No. SWTC16WS Use below drawings to identify all the parts. Top Tube with T-joint (6 pcs) Top Tube with Socket (6 pcs) Leg extension (12 pcs) Leg brace (6 pcs) Jumping mat (1 pc) Frame Pad (1 pc) Enclosure net (1 pc) Spring (96 pcs) Straight Tube（6 pcs）...

  • Page 13: Exploded Drawing And Parts List

    Exploded Drawing----Model No. SWTC16WS...

  • Page 14: Ordering Replacement Parts

    SWTC16WS Key No. Qty. Description Top Tube with T-joint Top Tube with Socket Leg extension Leg brace Jumping mat Frame Pad Enclosure net Spring Straight Tube Curved Tube Foam Pole Cap End Cap M6x45mm Bolt M5x50mm Screw M6 Nut M6 Washer...

  • Page 15: Assembly

    ASSEMBLY ASSEMBLY (PUTTING THE TRAMPOLINE AND ENCLOSURE TOGETHER) IMPORTANT ASSEMBLY INFORMATION • Need phillips screw driver (included with trampoline) and 2 adjustable wrenches (for putting the trampoline together). A rubber mallet is also recommended to make assembly easier. • Assembly requires two adults. Keep children away from the trampoline and enclosure until they are completely put together. •...
  • Page 16 Insert the Leg Brace(4) into two Leg Extensions(3) as shown, then tighten with M6x45mm Bolts(14), M6 Washers(18) and M6 Nuts(17). Press down on both Leg Extensions(3) at the same time and fully insert them into the T-joint and Socket , then tighten by M6x50mm Bolts(19) , M6 Washers(18) and M6 Nuts(17).
  • Page 17 If the Enclosure net(7) and Jumping mat(5) are not pre-installed, follow below steps to install. Place the Jumping mat(5) on clear ground. Identify the warning label on mat top and the ID label on mat back as shown. the first hole the first V-ring ID label (on mat back) Place the Enclosure net(7) on the Jumping mat(5),...
  • Page 18 If the Enclosure net and Jumping mat are pre-installed, follow below steps to assemble the Jumping mat to frame. T-joint Warning 5.1 Inspect the connection of Jumping mat and Enclosure Decal net, make sure all the V-rings are passed through the corresponding net holes.
  • Page 19 Attach the Spring as follows: V-ring Hook one end of Spring into the V-ring sewn on Jumping mat. Hook a Spring Tool as shown to the free end of the Spring. Pull the Spring until it reaches the frame. Push the end of the Spring into a hole in the frame, then unlook the Spring Tool Frame CAUTION:...
  • Page 20 Attach all the remaining V-rings with spring to Top tube holes correspondlingly. Enclosure door T-joint Lay the Frame Pad(6) on the frame. Adjust it’s position so that the slits are just above the Sockets as shown. CAUTION: Do not use the trampoline without the Frame Pad(6).The Frame Pad is designed to reduce the possibility of injuries due to jumpers coming in contact with the trampoline frame.
  • Page 21 Slide the Straight Tube(9) and Curved Tube(10) into Foams (11) as shown. Lay one Straight Tube(9) with Foam and one Curved Tube(10) with Foam on the ground. Insert the Straight Tube(9) into the Curved Tube(10). Secure with a Self-tapping screw(16). Make sure the end of the curved tube with two holes is at the top.
  • Page 22 11. Start from the Enclosure door, lift one of the assembled poles and then insert the Straight Tube(9) into the vertical tube of Socket as shown. Make sure the bent side of the enclosure poles are facing toward the center of the trampoline. Enclosure door NOTE: The end of the Straight Tubes(9) are sharp.
  • Page 23 14. Using the included plastic tie, attach the Safety Placard Frame to the frame near the point where jumpers will climb onto and off the trampoline. Safety Placard 15. Insert one wind stake(23) into the ground over the trampoline leg as shown.Then insert the others in the same way on the other three legs as shown.

  • Page 24: Care And Maintenance

    WARNING TRAMPOLINE AND ENCLOSURE CARE AND MAINTENANCE Care To avoid damage to the trampoline and enclosure, do not allow pets or animals inside the enclosure. The trampoline is intended to be used by one person at a time who weighs no more than 200 pounds. The user should be either barefoot, wearing socks, or wearing gymnastic shoes.

  • Page 25: Limited Warranty

    Skywalker Holdings, LLC option, the product at one of this authorized service centers. All products for which a warranty claim is made must be received by Skywalker Holdings, LLC at one of its authorized locations. Preauthorization may be obtained by calling Skywalker Holding, LLC Customer Care Hot Line at 1-866-603-Jump(5867).
