CHIEF KTG220 Specification Sheet

KTG220
FEAturEs
CEntris™ tEChnology
1
PAtEntED FEAtURE
Provides smooth fingertip tilt in all directions
using the screen's center of gravity . Screen
angle stays set until you decide to re-adjust .
AdvAnCEd displAy Mounting
2
teardrop hole pattern makes mounting the
screen quick and easy .
indEpEndEnt AdjustMEnt
3
Adjust each screen independently for
ergonomic alignment .
4 CAblE MAnAgEMEnt
Conceal and protect cables using snap-on
covers and cable clip
sPECiFiCAtions
Pole Height 14" (356 mm)
Max. Width 22.7" (577 mm)
Per Monitor
Max. Height 26" (660 mm)
Per Monitor
tilt ±15°
Weight Capacity 35 lbs (15.9 kg)
Per Monitor*
Grommet size .38 - 3" (10 - 76 mm)
Colors Black, silver
* Weight capacity given for KTG220. See www.chiefmfg.com
for more information on other product options.
tECHniCAL DrAWinGs
Ø 8"
(203 mm)
23 .84"
(606 mm)
Ø 1 .9"
1 .06"
(48 mm)
(27 mm)
CliCk
www.chiefmfg.com
HoRIZontAL GRoMMEt MoUntS
™
4
WHAt You nEED to KnoW
OTHEr PrODucT OPTiONS
VESA
75 mm & 100 mm
5 .86"
(149 mm)
4 .5"
(114 mm)
14"
(356 mm)
Dual mONiTOr mOuNTS
1
KTG225
Widescreen Dual
Hor. Grommet Mount
KTG320
triple Horizontal
Grommet Mount
KTG440
triple Horizontal
Grommet Mount
rECoMMEnDED ACCEssoriEs
KSa1007
n
KTa1001
n
KTa1028
n
For a complete list of monitor mount accessories see page
CAll
800.582.6480
2
3
KTG230
Dual Vertical
Grommet Mount
KTG330
six Monitor
Grommet Mount
KTG445
Quad Monitor
Grommet Mount
Centris Quick
release interface
Array Connector
28" Extension Column
108.
