REEFE HOT WATER CIRCULATING
CODE
MODEL
SPEED
3
2
7372
RHC2060
1
3
2
18828
RHC3280
1
* MAX MAINS PRESSURE 500kPa as per AS3500.1 *
PUMP INSTRUCTION MANUAL
POWER
AMPS
P1 (W)
0.45
100
0.35
70
0.25
55
1.1
245
0.85
190
0.6
135
MAXIMUM
FLOW
HEAD (m)
(L/min)
PORT TO PORT
48
6
35
4.5
21
2.5
25mm/1" MBSP
PORT TO PORT PORT TO PORT
166
8.2
77
7
33
5
50mm/2" MBSP 32mm/1¼" MBSP
SIZE
Bare Pump
With Union
LENGTH
130mm
185mm
PORTS
PORTS
20mm/¾" MBSP 32mm/1¼" MBSP
Bare Pump
With Union
180mm
230mm
PORTS
PORTS
With Bush
Length
150mm
PORTS
Advertisement
Table of Contents
Related Manuals for Reefe RHC2060
Summary of Contents for Reefe RHC2060
- Page 1 REEFE HOT WATER CIRCULATING PUMP INSTRUCTION MANUAL POWER MAXIMUM SIZE CODE MODEL SPEED Bare Pump With Union With Bush FLOW AMPS P1 (W) HEAD (m) (L/min) PORT TO PORT LENGTH Length 0.45 130mm 185mm 150mm 0.35 PORTS PORTS PORTS 7372 RHC2060 0.25...
- Page 2 CIRCULATOR PUMP FUNCTION AND APPLICATION 1. Maximum Mains Pressure 500kPa as per AS 3500.1 2. Maximum water temperature of 110°C !! IMPORTANT !! Tempering valves should be installed in accordance with Australian Standard AS3500.4.2 Clause 1.6. and manufacturer’s instructions. 3. This pump is used to circulate clean, fresh hot water around a ring main so users have quick access to hot water when the pump is on.
- Page 3 IMPORTANT NOTICE This pump is not suitable for outdoor use it must be protected from the weather by way of a weatherproof enclosure. Failure to do so voids all warranty. This pump must not be run dry, it must be installed using barrel-union connections, by a licenced person who is authorised to install this type of device.
- Page 4 IMPORTANT!! The pump bearing is lubricated by the pumped water. This pump cannot run dry for periods exceeding 10 seconds. Do not pump any flammable or corrosive liquids. DANGER!! USE FOR CLEAN FRESH WATER ONLY WITH MAXIMUM TEMPERATURE OF 110°C!! You MUST bleed the air out of the pump before turning on the power.
- Page 5 Installation This pump must be installed horizontally and must be level (picture 3) Pump must be installed as per illustration below (picture 4) IMPORTANT!! *Incorrect orientation voids all warranty *Pump must be protected from the weather Only qualified and competent tradespeople should attempt installation or electrical work.
- Page 6 Once installed, bleed air prior to operation, as shown in picture 7. WARNING!! Operating pump with air in it voids the warranty. Maintenance and Repair Should the power cable need replacement, it must be installed by a licenced electrician. DANGER!! *Disconnect from power before touching the pump *Pump will be HOT –...
- Page 7 Troubleshooting Guide...
- Page 8 2. 2 Year Warranty against Defects: This warranty covers failure due to manufacturing defects for REEFE Hot Water Circulator Pumps purchased from Ascento Group Australia, and used in mainland Australia. We shall replace the pump when we ascertain that the fault is due to manufacturing defect, during the 2 year period from date of purchase.
