- Page 1 SOLAR/DC POWERED VORTEX SUMP PUMP EXPLODED VIEW & INSTRUCTION MANUAL MODEL: RSE24V CODE: 21026 www.reefe.com.au...
- Page 2 COMPONENTS & MATERIALS POSITION COMPONENT MATERIAL A Discharge Polymer B Pump Body Polymer C Pump Base Polymer POSITION COMPONENT 1 Flange 2 Plane Washer 3 Tooth Washer 4 Seeger Din 5 Induced 6 Stator www.reefe.com.au...
- Page 3 15 Float Switch 4 Sleeve Socket Vertical Float Switch 5 External Cover Carbon 6 O-Ring Screw 7 Motor and Impeller Connector 8 Ball Bearing Cable with Pliers 9 Flat Seal 20 Washer 10 Body Pump 21 Cable Gland 11 Suction Grid www.reefe.com.au...
- Page 4 INSTRUCTION | Dear Client, Congratulations on your purchase of this REEFE® pump product. These pumps are developed and manufactured using the latest in technology and advanced electrical and motor parts. Please check the following points upon receipt of your pump: Is the pump exactly what you ordered? Please check the nameplate.
- Page 5 4. Before installing pump, clear sump basin of any water,debris,or sediment. Example：Use 24V/120AH Fully charged Battery, Warning: Sump basin must be vented in accordance with local plumbing codes. REEFE Sump pumps are not designed for and CANNOT be installed in Run time :6 .5 hrs locations classified as hazardous.
- Page 6 2. Warranty covers only motor failure and manufacturing defects for pumps used for domestic or commercial use, within a 24 month period from the original date of purchase for REEFE™ pumps purchased and used in mainland Australia. No warranty applies for pump used for hire or on building sites.
