REEFE RHB1590 Hot & Cold Water Booster Pump
POWER (230-240V)
CODE
MODEL
AMPS
0.48
18811
RHB1590
** Max Mains Pressure 500kPa as per AS 3500.1-2018
FLOW
P1 (W)
HEAD (m)
(L/min)
105
23
9
MAXIMUM
MAINS
LIQUID
PRESSURE
TEMP
+2 - +60°C
500kPa**
SIZE
Bare Pump
With Union
PORT TO PORT
LENGTH
160mm
215mm
PORTS
PORTS
20mm/¾" MBSP 13mm/½" MBSP
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Reefe RHB1590
Summary of Contents for Reefe RHB1590
- Page 1 REEFE RHB1590 Hot & Cold Water Booster Pump POWER (230-240V) MAXIMUM SIZE CODE MODEL MAINS Bare Pump With Union FLOW LIQUID AMPS P1 (W) HEAD (m) PRESSURE (L/min) TEMP PORT TO PORT LENGTH 0.48 +2 - +60°C 160mm 215mm 500kPa**...
- Page 2 Australian Standard AS3500.4.2 Clause 1.6. and manufacturer’s instructions. 3. The RHB1590 is designed for boosting water pressure in domestic potable cold and hot water applications. 4. The pump provides additional pressure to showers, taps and similar outlet points.
- Page 3 IMPORTANT NOTICE This pump is not suitable for outdoor use it must be protected from the weather by way of a weatherproof enclosure. Failure to do so voids all warranty. This pump must not be run dry, it must be installed using barrel-union connections, by a licenced person who is authorised to install this type of device.
- Page 4 Dimensions: Pump Parts Description and Accessories: Installation Guide:...
- Page 5 ORIENTATION MUST BE CORRECT WARRANTY IS VOID IF ORIENTATION IS INCORRECT Warning!! WARNING!! This pump WILL NOT TURN OFF if switched to MANUAL (position II) mode – it will continue to run, even when there is no water. ENSURE that if MANUAL mode is used, it is turned back to AUTO (position III) or OFF as soon as it is no longer required.
- Page 6 Cleaning The Flow Switch Magnet: Cleaning the Flow Switch is required to be done every 6 months to ensure no debris build-up occurs – this will affect reliability of pump use REMOVE PLUG FROM POWER POINT BEFORE TOUCHING PUMP ALLOW PUMP TO COOL BEFORE OPENING ENSURE INLET AND OUTLET BALL VALVES/STOP VALVES HAVE BEEN CLOSED BEFORE OPENING PUMP CHECK FOR LEAKS AFTER REASSEMBLING PUMP...
- Page 7 Troubleshooting: WARNING!! This pump WILL NOT TURN OFF if switched to MANUAL (position II) mode – it will continue to run, even when there is no water. ENSURE that if MANUAL mode is used, it is turned back to AUTO (position III) or OFF as soon as it is no longer required.
- Page 8 2. 2 Year Warranty against Defects: This warranty covers failure due to manufacturing defects for REEFE Hot Water Circulator Pumps purchased from Ascento Group Australia, and used in mainland Australia. We shall replace the pump when we ascertain that the fault is due to manufacturing defect, during the 2 year period from date of purchase.
