TAPE AND REEL INFORMATION
*All dimensions are nominal
Device
Package
Type
ADS8694IDBTR
TSSOP
ADS8698IDBTR
TSSOP
Package
Pins
SPQ
Reel
Drawing
Diameter
(mm)
DBT
38
2000
330.0
DBT
38
2000
330.0
Pack Materials-Page 1
PACKAGE MATERIALS INFORMATION
Reel
A0
B0
Width
(mm)
(mm)
W1 (mm)
16.4
6.9
10.2
16.4
6.9
10.2
K0
P1
W
Pin1
(mm)
(mm)
(mm)
Quadrant
1.8
12.0
16.0
Q1
1.8
12.0
16.0
Q1
