Typical Characteristics (continued)
At T = 25°C, AVDD = 5 V, DVDD = 3 V, internal reference V
A
24000
18000
12000
6000
0
131059 131063 131067 131071 131075 131079 131083
Mean = 131072.3, sigma = 2.76, input = 0 V,
range = ±0.625 × V
Figure 8. DC Histogram for Mid-Scale Inputs (±0.625 × V
20000
16000
12000
8000
4000
0
131058 131063 131068
Mean = 131072.3, sigma = 2.71, input = 0.625 × V
range = 1.25 × V
Figure 10. DC Histogram for Mid-Scale Inputs
1.4
1
0.6
0.2
-0.2
-0.6
-1
±40 ±7
Free-Air Temperature (
All input ranges
Figure 12. DNL vs Temperature
