Green Brook Orion Range OD102 Important Safety Instructions

Infra-red motion detector - ceiling mounted

Advertisement

Infra-red Motion Detector - Ceiling Mounted
Please read these instructions carefully before installation and keep safe for
future reference.
IMPORTANT
This product should be installed by a competent person and in accordance
with the current IET Wiring Regulations and Building Regulations.
If in doubt,consult a qualified electrician.
Always turn off the mains supply before commencing work.
As the detector responds to changes in temperature, avoid the following
situations:-
Avoid pointing the detector towards objects with highly reflective surfaces,
such as mirrors etc.
Avoid mounting the detector near heat sources, such as heating vents, air
conditioning units, lights etc.
Avoid pointing the detector towards objects that may move in the wind,
such as curtains, tall plants etc.
Switch the mains supply OFF first to prevent electric shock.
1. Remove the cover by rotating anti-clock wise.
2. Connect the mains in and load out wires according to Dia:1.
Dia:1
Note:
Please refer to Data Sheet on the GreenBrook website -
www.greenbrook.co.uk for wiring sensor in parallel.
'Orion Range'
Model: OD102
Important Safety Instructions
FIELD OF DETECTION

INSTALLATION

N = Neutral 'IN'
L = Live 'IN'
A = Output to Load

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Orion Range OD102 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Green Brook Orion Range OD102

  • Page 1 ‘Orion Range’ Infra-red Motion Detector - Ceiling Mounted Model: OD102 Important Safety Instructions • Please read these instructions carefully before installation and keep safe for future reference. IMPORTANT This product should be installed by a competent person and in accordance with the current IET Wiring Regulations and Building Regulations.
  • Page 2 3. Secure the sensor back plate to the wall using two wood screws (ensure there is no wiring/gas/water services directly behind the screws) Dia:2. Dia:2 TESTING 1. Turn ‘Time’ control fully anti- clockwise and ‘Lux’ control fully clock wise, refer to Dia: 3. Dia:3 2.
