C236 WSI4
User Manual
Version 1.0
Published July 2016
Copyright©2016 ASRock Rack INC. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C236 WSI4 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK Rack C236 WSI4 Series

Summary of Contents for ASROCK Rack C236 WSI4 Series

  • Page 1 C236 WSI4 User Manual Version 1.0 Published July 2016 Copyright©2016 ASRock Rack INC. All rights reserved.
  • Page 2 In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you may contact your dealer for further information. ASRock Rack Incorporation 6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District, Taipei City 112, Taiwan (R.O.C.)

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installation of Memory Modules (SODIMM) Expansion Slot (PCI Express Slot) Jumper Setup Onboard Headers and Connectors Driver Installation Guide Dua LAN and Teaming Operation Guide M.2_SSD (NGFF) Module Installation Guide...
  • Page 5 Advanced Screen 3.3.1 CPU Configuration 3.3.2 Memory Configuration 3.3.3 Chipset Configuration 3.3.4 Storage Configuration 3.3.5 NVMe Configuration 3.3.6 ACPI Configuration 3.3.7 USB Configuration 3.3.8 WHEA Configuration 3.3.9 Intel Server Platform Services 3.3.10 Super IO Configuration 3.3.11 Serial Port Console Redirection 3.3.12 H/W Monitor 3.3.13 Voltage Control 3.3.14 Trusted Computing...
  • Page 6 Support CD Information 4.2.1 Running The Support CD 4.2.2 Drivers Menu 4.2.3 Utilities Menu 4.2.4 Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service Chapter 6: Net Framework Installation Guide Installing .Net Framework 3.5.1 (For Server 2008 R2)

  • Page 7: Chapter 1 Introduction

    In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. You may find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com If you require technical support related to this motherboard, please visit our website for specific information about the model you are using.

  • Page 8: Specifications

    1.2 Specifications C236 WSI4-85 / C236 WSI4-85L / C236 WSI4-65L MB Physical Status Form Factor Mini ITX Dimension 6.7'' x 6.7'' (17.02cm x17.02 cm) Processor System C236 WSI4-85: 65W: E3-1585 V5 C236 WSI4-85L: 45W: E3-1585L v5 C236 WSI4-65L: 35W: E3-1565L v5  Chipset Intel®...
  • Page 9 128Mb AMI UEFI Legal BIOS BIOS Features - Plug and Play (PnP) - ACPI 2.0 Compliance Wake Up Events - SMBIOS 2.8.0 Support - ASRock Rack Instant Flash Hardware Monitor Temperature - CPU Temperature Sensing - System Temperature Sensing - System TR Temperature Sensing...
  • Page 10 Support OS Microsoft® Windows® - Windows Server 2008 R2 (64 bit) - Windows Server 2012 (64 bit) - Windows Server 2012 R2 (64 bit) Linux® - RedHat Enterprise Linux Server 6.6 (32 / 64 bit) / 7.0 (64 bit) - SUSE Enterprise Linux Server 11 SP3 (32 / 64 bit) /12.0 (64 bit) - Ubuntu 15.04 (64 bit) / 15.10 (64 bit) (AHCI mode) * Please refer to our website for the latest OS support list.

  • Page 11: Unique Features

    POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to your USB flash drive, floppy disk or hard drive, then you can update your BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 12: Motherboard Layout

    1.4 Motherboard Layout 17.0cm (6.7 in) CMOS USB 3.0 Battery ATXPWR1 T: USB3_1 B: USB3_2 CON1 DDR4_B2 (64 bit, 260-pin module) COM1 DDR4_B1 (64 bit, 260-pin module) TPM1 DDR4_A2 (64 bit, 260-pin module) USB3_3_4 CPU_FAN1 DDR4_A1 (64 bit, 260-pin module) HDMI1 CLRMOS1 USB_1_2...
  • Page 13 C236 WSI4 Series Description COM Port Header (COM1) TPM Header (TPM1) CPU Fan Connector (CPU_FAN1) ATX Power Connector (ATXPWR1)* 12V DC Input Power Connector (CON1)* 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_A2, DDR4_B2) 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_A1, DDR4_B1) USB 2.0 Header (USB_1_2)
  • Page 14 Description Front Panel Audio Header (HD_AUDIO1) ME Recovery Jumper Jumper (SEC_OR1) Non Maskable Interrupt Button (NMI_BTN1) *Please use either the 12V DC Input Power Connector (CON1) or the ATX Power Connector (ATXPWR1) at one time. Do not connect them both simutaneously.

  • Page 15: Onboard Led Indicators

    C236 WSI4 Series 1.5 Onboard LED Indicators CMOS USB 3.0 ATXPWR1 Battery T: USB3_1 B: USB3_2 CON1 DDR4_B2 (64 bit, 260-pin module) COM1 DDR4_B1 (64 bit, 260-pin module) TPM1 DDR4_A2 (64 bit, 260-pin module) USB3_3_4 CPU_FAN1 DDR4_A1 (64 bit, 260-pin module)

  • Page 16: I/O Panel

    1.6 I/O Panel No. Description No. Description USB 3.0 Port (USB3_2) LAN RJ-45 Port (LAN2)* USB 3.0 Port (USB3_1) LAN RJ-45 Port (LAN3)* VGA Port (VGA1) LAN RJ-45 Port (LAN4)* HDMI Port Front Speaker (Lime) LAN RJ-45 Port (LAN1)* LAN Port LED Indications *There are two LEDs on each LAN port.

  • Page 17: Block Diagram

    C236 WSI4 Series 1.7 Block Diagram...

  • Page 18: Chapter 2 Installation

    Chapter 2 Installation This is a mini ITX form factor (6.7'' x 6.7'', 17.02 cm x 17.02 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries to you and damages to motherboard components.

  • Page 19: Installation Of Memory Modules (Sodimm)

    C236 WSI4 Series 2.3 Installation of Memory Modules (SODIMM) This motherboard provides four 260-pin DDR4 (Double Data Rate 4) SO-DIMM slots, and supports Daul Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 SO-DIMM pairs.

  • Page 21: Expansion Slot (Pci Express Slot)

    C236 WSI4 Series 2.4 Expansion Slot (PCI Express Slot) There is a PCI Express slot on this motherboard. PCIE slot: PCIE7 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width cards. Slot Generation Mechanical Electrical Source PCIE 7 Installing an expansion card Step 1.

  • Page 22: Jumper Setup

    2.5 Jumper Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins.
  • Page 23 C236 WSI4 Series Chassis ID0 Jumper (3-pin CHASSIS_ID0) (see p.6, No. 34) Chassis ID1 Jumper (3-pin CHASSIS_ID1) (see p.6, No. 33) Chassis ID2 Jumper (3-pin CHASSIS_ID2) Reserved for system level Reserved for system level (see p.6, No. 32) Chassis ID0 Jumper (3-pin CHASSIS_ID0) (see p.6, No.

  • Page 24: Onboard Headers And Connectors

    2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header C onnec t t he power sw itch, PLED+ PLED-...
  • Page 25 C236 WSI4 Series Auxiliary Panel Header This header supports multiple (18-pin AUX PANEL_1) functions on the front panel, (see p.6, No. 26) including the front panel SMB, internet status indicator and chassis intrusion pin. A. Front panel SMBus connecting pin (6-1 pin FPSMB) This header allows you to connect SMBus (System Management Bus) equipment.
  • Page 26 Serial ATA3 Connectors These SATA3 connectors (SATA_0) support SATA data cables for SATA_1 (see p.6, No. 16) internal storage devices with SAT A_2 (SATA_1) up to 6.0 Gb/s data transfer (see p.6, No. 14) rate. SAT A_3 (SATA_2) (see p.6, No. 15) SAT A_4 (SATA_3) (see p.6, No.
  • Page 27 Fan) connectors. If you plan FAN_SPEED_CONTROL to connect a 3-Pin CPU fan, please connect it to Pin 1-3. *For more details, please refer to the Cooler QVL list on the ASRock Rack website. Front Fan Connector Please connect fan cables to the FAN_VOLTAGE...
  • Page 28 TPM Header This connector supports (17-pin TPM1) Trusted Platform Module (see p.6, No. 2) (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. Serial General Purpose The headers support Serial Input/Output Headers...
  • Page 29 C236 WSI4 Series Front Panel Audio Header This header is for OUT_RET OUT2_L (9-pin HD_AUDIO1) connecting audio J_SENSE MIC_RET OUT2_R (see p.6, No. 35) devices to the front PRESENCE# MIC2_R GN D MIC2_L audio panel. 1. High Definition Audio supports Jack Sensing, but the panel wire on the chassis must sup- port HDA to function correctly.

  • Page 30: Driver Installation Guide

    Serial Port Header This COM header supports a RRI#1 RRTS#1 CCTS# (9-pin COM1) serial port module. DDSR#1 (see p.6, No. 1) DDTR#1 TTXD1 RRXD1 DDCD#1 +12V SATA Power Connectors Please connect a SATA power (4-pin SATA_PWR1) cable to the SATA power (see p.6, No.

  • Page 31: Dua Lan And Teaming Operation Guide

    C236 WSI4 Series 2.8 Dua LAN and Teaming Operation Guide Dual LAN with Teaming enabled on this motherboard allows two single connections to act as one single connection(s) for twice the transmission bandwidth, making data transmission more effective and improving the quality of transmission of distant images.

  • Page 32: M.2_Ssd (Ngff) Module Installation Guide

    2.9 M.2_SSD (NGFF) Module Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mSATA. The Ultra M.2 Socket (M2_1) supports a M.2 SATA3 6.0 Gb/s module. Installing the M.2_SSD (NGFF) Module Step 1 Prepare a M.2_SSD (NGFF) module...
  • Page 33 C236 WSI4 Series Step 3 Move the standoff based on the module type and length. The standoff is placed at the nut location D by default. Skip Step 3 and NUT80 NUT60 NUT42 NUT30 4 and go straight to Step 5 if you are going to use the default nut.

  • Page 34: Chapter 3 Uefi Setup Utility

    Chapter 3 UEFI Setup Utility 3.1 Introduction Th is section explains how to use the UEFI SETUP UTILITY to confi gure your system. Th e UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer.

  • Page 35: Navigation Keys

    C236 WSI4 Series 3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 36: Main Screen

    3.2 Main Screen Once you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The Main screen provides system overview information and allows you to set the system time and date.

  • Page 37: Advanced Screen

    C236 WSI4 Series 3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Memory Configuration, Chipset Configuration, Storage Configuration, NVMe Configura- tion, ACPI Configuration, USB Configuration, WHEA Configuration, Intel Server Plat- form Services, Super IO Configuration, Serial Port Console Redirection, H/W Monitor, Voltage Control, Trusted Computing, Intel TXT Information and Instant Flash.

  • Page 38: Cpu Configuration

    3.3.1 CPU Configuration Spread Spectrum Use this to enable and disable Spread Spectrum. Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved. Active Processor Cores Select the number of cores to enable in each processor package.
  • Page 39 C236 WSI4 Series Package C State Support Enable CPU, PCIe, Memory, Graphics C State Support for power saving. CPU Thermal Throttling Enable CPU internal thermal control mechanisms to keep the CPU from overheating. No-Execute Memory Protection Processors with No-Execution Memory Protection Technology may prevent certain classes of malicious buffer overflow attacks.

  • Page 40: Memory Configuration

    3.3.2 Memory Configuration DRAM Frequency If [Auto] is selected, the motherboard will detect the memory module(s) inserted and assign the appropriate frequency automatically. ECC Support Use this item to enable or disable DDR ECC Support.

  • Page 41: Chipset Configuration

    C236 WSI4 Series 3.3.3 Chipset Configuration Primary Graphics Adapter If PCI Express graphics card is installed on the motherboard, you may use this option to select PCI Express or Onboard as the primary graphics adapter. Top of Lower Usable Dram Maximum Value of TOLUD.
  • Page 42 PCI-E ASPM Support This option enables or disables the ASPM support for all CPU downstream devices. PCH PCI-E ASPM Support This option enables or disables the ASPM support for all PCH downstream devices. DMI ASPM Support This option enables/disables the control of ASPM on CPU side of the DMI Link. PCH DMI ASPM Support This option enables/disables the ASPM support for all PCH DMI devices.
  • Page 43 C236 WSI4 Series Restore on AC/Power Loss This allows you to set the power state after an unexpected AC/power loss. If [Power Off] is selected, the AC/power remains off when the power recovers. If [Power On] is selected, the AC/power resumes and the system starts to boot up when the power recovers. If [Last...

  • Page 44: Storage Configuration

    3.3.4 Storage Configuration SATA Controller(s) Use this item to enable or disable SATA Controllers. SATA/M.2_SATA Mode Selection Identify the SATA/M.2_SATA port is connected to Solid State Drive or Hard Disk Drive. Press <Ctrl+I> to enter RAID ROM during UEFI POST process. Launch Storage OpROM Policy Select UEFI only to run those that support UEFI option ROM only.

  • Page 45: Nvme Configuration

    C236 WSI4 Series 3.3.5 NVMe Configuration The NVMe Configuration displays the NVMe controller and Drive information.

  • Page 46: Acpi Configuration

    3.3.6 ACPI Configuration PCIE Devices Power On Use this item to enable or disable PCIE devices to turn on the system from the power-soft- off mode. Ring-In Power On Use this item to enable or disable Ring-In signals to turn on the system from the power- soft-off mode.

  • Page 47: Usb Configuration

    C236 WSI4 Series 3.3.7 USB Configuration Legacy USB Support Use this option to enable or disable legacy support for USB devices. The default value is [Enabled]. PS/2 Simulator Enable PS/2 Simulator. This should be enabled for the complete USB keyboard legacy support for non-USB aware OSes.

  • Page 48: Whea Configuration

    3.3.8 WHEA Configuration WHEA Support Use this item to enable or disable Windows Hardware Error Architecture.

  • Page 49: Intel Server Platform Services

    C236 WSI4 Series 3.3.9 Intel Server Platform Services Displays the information of the Intel server platform services.

  • Page 50: Super Io Configuration

    3.3.10 Super IO Configuration Serial Port Use this item to enable or disable the onboard serial port. Serial Port Address Use this item to select an optimal setting for Super IO device.

  • Page 51: Serial Port Console Redirection

    C236 WSI4 Series 3.3.11 Serial Port Console Redirection COM1 Console Redirection Use this option to enable or disable Console Redirection. If this item is set to Enabled, you can select a COM Port to be used for Console Redirection. Console Redirection Settings Use this option to configure Console Redirection Settings, and specify how your computer and the host computer to which you are connected exchange information.
  • Page 52 Bits Per Second Use this item to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. The options include [9600], [19200], [38400], [57600] and [115200]. Data Bits Use this item to set the data transmission size.
  • Page 53 C236 WSI4 Series Legacy Console Redirection Legacy Console Redirection Settings Use this option to configure Legacy Console Redirection Settings, and specify how your computer and the host computer to which you are connected exchange information. Legacy Serial Redirection Port Use this item to select a COM port to display redirection of Legacy OS and Legacy OPROM Messages.

  • Page 54: H/W Monitor

    3.3.12 H/W Monitor In this section, it allows you to monitor the status of the hardware on your system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. CPU_FAN1 This allows you to set the CPU fan1’s speed.

  • Page 55: Voltage Control

    C236 WSI4 Series 3.3.13 Voltage Control DRAM Voltage Use this to select DRAM Voltage. The default value is [Auto].

  • Page 56: Trusted Computing

    3.3.14 Trusted Computing NOTE: Options vary depending on the version of your connected TPM module. TPM State Use this item to enable or disable Security Device. NOTE: Your computer will reboot during restart in order to change State of the Device. Pending Operation Schedule an Operation for the Security Device.

  • Page 57: Intel Txt Information

    C236 WSI4 Series 3.3.15 Intel TXT information Intel TXT(LT) Support Use this item to enable or disable Intel(R) TXT(LT) support.

  • Page 58: Instant Flash

    3.3.16 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows you to update system UEFI without entering operating systems ® first like MS-DOS or Windows . Just save the new UEFI file to your USB flash drive, floppy disk or hard drive and launch this tool, then you can update your UEFI only in a few clicks without preparing an additional floppy diskette or other compli- cated flash utility.

  • Page 59: Boot Screen

    C236 WSI4 Series 3.4 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot Option #1 Use this item to set the system boot order.
  • Page 60 Bootup Num-Lock If this item is set to [On], it will automatically activate the Numeric Lock function after boot-up. Boot Beep Select whether the Boot Beep should be turned on or off when the system boots up. Please note that a buzzer is needed. Full Screen Logo Use this item to enable or disable OEM Logo.

  • Page 61: Csm Parameters

    C236 WSI4 Series 3.4.1 CSM Parameters Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. If you are using Windows 8.1 64-bit and all of your devices support UEFI, you may also disable CSM for faster boot speed.

  • Page 62: Security

    3.5 Security In this section, you may set or change the supervisor/user password for the system. For the user password, you may also clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 63: Event Logs

    C236 WSI4 Series 3.6 Event Logs Change Smbios Event Log Settings This allows you to configure the Smbios Event Log Settings. When entering the item, you will see the followings: Smbios Event Log Use this item to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 64 View Smbios Event Log Press <Enter> to view the Smbios Event Log records. All values changed here do not take effect until computer is restarted.

  • Page 65: Exit Screen

    C236 WSI4 Series 3.7 Exit Screen Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY.

  • Page 66: Chapter 4 Software Support

    4.2.4 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, welcome to visit ASRock Rack’s website at http://www.ASRockRack.com; or you may contact your...

  • Page 67: Chapter 5 Troubleshooting

    C236 WSI4 Series Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot your system. Always unplug the power cord before adding, removing or changing any hardware com- ponents. Failure to do so may cause physical injuries to you and damages to motherboard components.
  • Page 68 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether your power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to your problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...

  • Page 69: Technical Support Procedures

    C236 WSI4 Series 5.2 Technical Support Procedures If you have tried the troubleshooting procedures mentioned above and the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Your contact information 2. Model name, BIOS version and problem type.

  • Page 70: Chapter 6: Net Framework Installation Guide

    Chapter 6: Net Framework Installation Guide ® To let Intel RSTe works properly, it is required to install Net Framework. Please follow the ® ® steps below to enable “.Net Framework” feature on Microsoft Windows Server 2008 R2. 6.1 Installing .Net Framework 3.5.1 (For Server 2008 R2) 1.
  • Page 71 C236 WSI4 Series 3. Check the box next to .Net Framework 3.5.1 and then click Next. 4. Click Next to continue.
  • Page 72 P/N: 15G065087000AK V1.0 5. Click Install to start installing .Net Framework 3.5.1. 6. After the installation completes, click Close.
