Card reader board

Description
Card reader board (includes cable)
Card reader board bracket
Before removing the card reader board and bracket, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
a. Memory module compartment cover (see
b. Wireless module compartment cover (see
c. Switch cover and keyboard (see
d. Display assembly (see
e. Top cover (see
88 Chapter 4 Removal and replacement procedures
Battery on page 48), and then remove the following components:
Switch cover and keyboard on page
Display assembly on page
Top cover on page 85)
Expansion memory module on page
WLAN module on page
76)
Spare part number
598768-001
598767-001
52)
57)
69)
