Battery - HP EliteBook 2540P Maintenance And Service Manual

Battery

Description
9-cell, 93-WH, 2.8-WH Li battery
6-cell, 62-WH, 2.8-WH Li battery
6-cell, 55-WH, 2.8-WH Li long life battery
3-cell, 31-WH, 2.8-WH Li battery
3-cell, 28-WH, 2.8-WH Li long life battery
Before disassembling the computer, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
Remove the battery:
1. Turn the computer upside down on a flat surface, with the battery bay toward you.
2. Slide the battery lock latch (1) to unlock the battery.
3. Slide the battery release latch (2) to release the battery.
4. Remove the battery (3) from the computer.
Install the battery by inserting it into the battery bay until you hear a click.
48 Chapter 4 Removal and replacement procedures
Spare part number
593587-001
593586-001
593585-001
492548-001
593584-001
ENWW
