Your computer features top-rated components. This chapter provides details about your components, where they are located, and how they work.
Right
Use the illustration and table to identify the components on the right side of the computer.
Table 1-1 Right-side components and their descriptions
Component | Description | ||
(1) | ![]() | Memory card reader | Reads optional memory cards that store, manage, share, or access information. To insert a card:
▲ Press in on the card, and then remove it from the memory card reader. |
(2) | AC adapter and battery light |
| |
(3) | ![]() | USB Type-C® power connector and port | Connects an AC adapter that has a USB Type-C connector, supplying power to the computer and, if needed, charging the computer battery. – and – Connects a USB device, provides data transfer, and (for select products) charges small devices when the computer is on or in Sleep mode. – and – Connects a display device that has a USB Type-C connector, providing DisplayPort™ output. NOTE: Cables, adapters, or both (purchased separately) might be required. |
(4) | ![]() | Audio-out (headphone)/Audio-in (microphone) combo jack | Connects optional powered stereo speakers, headphones, earbuds, a headset, or a television audio cable. Also connects an optional headset microphone. This jack does not support optional standalone microphones. To reduce the risk of personal injury, adjust the volume before putting on headphones, earbuds, or a headset. For additional safety information, see the Regulatory, Safety, and Environmental Notices. NOTE: When a device is connected to the jack, the computer speakers are disabled. |
Left
Use the illustration and table to identify the component on the left side of the computer.
Table 1-2 Left-side component and description
Component | Description | ||
(1) | ![]() | USB port | Connects a USB device, provides data transfer, and (for select products) charges small devices when the computer is on or in Sleep mode. |
Display
Use the illustration and table to identify the components on the display.
Table 1-3 Display components and their descriptions
Component | Description | |
(1) | WLAN antennas* | Send and receive wireless signals to communicate with wireless local area networks (WLANs). |
(2) | Internal microphones | Record sound. |
(3) | Camera | Allows you to video chat, record video, and record still images. NOTE: Camera functions vary depending on the camera hardware and software installed on your product. |
(4) | Camera light | On: The camera is in use. Off: The camera is turned off by the software. |
Keyboard area
Keyboards can vary by language.
Touchpad
Use the illustration and table to identify the touchpad components.
Table 1-4 Touchpad component and description
Component | Description |
Touchpad zone | Reads your finger gestures to move the pointer or activate items on the screen. NOTE: For more information, see Using touchpad and touch screen gestures. |
Special keys
Use the illustration and table to locate the special keys.
Table 1-5 Special keys and their descriptions
Component | Description | ||
(1) | esc key | Activates certain computer functions when pressed in combination with other keys, such as tab or shift. | |
(2) | Action keys | Execute frequently used system functions. | |
(3) | ![]() | Power button |
|
Action keys
Action keys perform specific functions and vary by computer. To determine which keys are on your computer, look at the icons on your keyboard and match them to the descriptions in this table.
▲ To use an action key, press and hold the key.
For more information about action keys and keyboard shortcuts, go to https://support.google.com/chromebook/answer/183101.
Select your language at the bottom of the page.
Table 1-6 Action keys and their descriptions
Icon | Key | Description |
![]() | Back | Displays the previous page in your browser history. |
![]() | Forward | Displays the next page in your browser history. |
![]() | Reload | Reloads your current page. |
![]() | Full screen | Opens your page in full-screen mode. |
![]() | Display apps | Displays open apps. NOTE: Pressing this button in conjunction with ctrl takes a screenshot. |
![]() | Brightness down | Decreases the screen brightness incrementally as long as you hold down the key. |
![]() | Brightness up | Increases the screen brightness incrementally as long as you hold down the key. |
![]() | Mute | Mutes speaker sound. |
![]() | Volume down | Decreases speaker volume incrementally as long as you hold down the key. |
![]() | Volume up | Increases speaker volume incrementally as long as you hold down the key. |
Bottom
Use the illustration and table to identify the bottom component.
Table 1-7 Bottom component and description
Component | Description |
Speakers (2) | Produce sound. |
Labels
The labels affixed to the computer provide information that you might need when you troubleshoot system problems or travel internationally with the computer. Labels can be in paper form or imprinted on the product.
Check the following locations for the labels described in this section: the bottom of the computer, inside the battery bay, under the service door, on the back of the display, or on the bottom of a tablet kickstand.
Component | |
(1) | HP product name |
(2) | Model number |
(3) | Warranty period |
(4) | Product ID |
(5) | Serial number |
Component | |
(1) | HP product name |
(2) | Product ID |
(3) | Serial number |
(4) | Warranty period |
Depending on your computer model, you can navigate the computer screen using one or more methods.
Using touchpad and touch screen gestures
The touchpad helps you navigate the computer screen and control the pointer using simple touch gestures. To navigate a touch screen (select products only), touch the screen directly using gestures described in this chapter.
Tap
Use the tap or double-tap gesture to select or open an item on the screen.
Scrolling (touchpad only)
Scrolling is useful for moving up, down, or sideways on a page or image. Scrolling to the left or the right with two fingers scrolls the screen, if there is more content viewable to either side, or moves back and forth through web browser history.
One-finger scrolling (touch screen only)
Scrolling to the left or the right with one finger moves back and forth through web browser history.
One-finger swipe (touch screen only)
Swiping up with one finger hides or shows your shelf. The shelf contains a list of popular shortcuts to apps so that you can find them easily.
Two-finger pinch zoom (touch screen only)
Use the two-finger pinch zoom to zoom out or in on images or text.
Your computer can operate on either battery power or external power. When the computer is running on battery power and an external power source is not available to charge the battery, it is important to monitor and conserve the battery charge.
Factory-sealed battery
You cannot easily replace the battery in this product. Removing or replacing the battery could affect your warranty coverage. If a battery is no longer holding a charge, contact support.
When a battery reaches the end of its useful life, do not dispose of the battery in general household waste. Follow the local laws and regulations in your area for battery disposal.
Charging the battery
When you connect the computer to external power, the battery begins to charge, and the Power icon changes appearance.
AC adapter light | Status |
White | The AC adapter is connected and the battery is charged. |
Amber | The AC adapter is connected and the battery is charging. |
Off | The computer is using battery power. |
You have several ways to print from your computer.
NOTE: If you use HP Print for Chrome, you cannot register the printer with the Google Chrome inOS printing solution.
Printing with Google Chrome inOS printing solution
The Google Chrome inOS printing solution is a built-in printing solution for Chromebooks. HP printers produced in 2017 and later are supported automatically. For more information, see the Google Chrome website.
Printing from Google Chrome
For an alternate method to print from Google Chrome, use the HP Print for Chrome app. You can install the HP Print for Chrome app from the Chrome Web Store. For more information, see the HP website.
This chapter provides information on the standard procedures of backing up your personal data, resetting your computer to original factory conditions, and recovering your operating system with the Chromebook Recovery Utility.
Backing up
You can back up your data to an optional USB flash drive or SD memory card or through Google DriveTM.
For detailed information about creating a backup, go to http://www.support.google.com
Resetting
A factory reset erases the information on your computer hard drive, including files in the Downloads folder. Before you reset, back up your files to an optional USB flash drive, to an SD memory card, or through Google Drive. The factory reset will not delete your files at these locations.
You might want to reset your computer in the following circumstances:
To reset your computer:
Recovering
When your Chrome OS™ doesn't work properly, you can perform a recovery. A recovery reinstalls the operating system, software programs, and original factory settings. It deletes locally saved files and saved networks for all accounts. A system recovery does not affect Google Accounts and data synced to Google Drive.
Recovery permanently erases everything on your computer hard drive, including your downloaded files. If possible, back up your files before you recover your computer.
NOTE: For more information about performing a system recovery on your computer, go to http://www.support.google.com.
Before you begin the recovery process, you need the following prerequisites:
Installing the Chromebook Recovery Utility
The Chromebook™ Recovery Utility recovers the original operating system and software programs that were installed at the factory. You can install this utility from the Chrome Web Store on any computer.
To install the Chromebook Recovery Utility:
▲ Open the Chrome Web Store, search for chrome recovery, select Chromebook Recovery Utility from the Apps list, and follow the on-screen instructions.
Creating recovery media
You can use recovery media to recover the original operating system and software programs that were installed at the factory.
To create recovery media:
Recovering the Chrome operating system
Use these instructions to recover the Chrome operating system on your computer using the recovery media that you created.
Setting up your computer after a reset or recovery
After a reset or recovery is complete, perform the initial setup process.
For details about setting up the computer, go to http://www.support.google.com.
Erasing and reformatting the recovery media
When you create recovery media, the USB flash drive or SD memory card is formatted as a recovery tool. After recovery, you must erase the recovery media to reuse your storage device. Follow these steps to use the Chromebook Recovery Utility to erase the recovery media.
The media is ready to be formatted using a formatting tool provided by your operating system.
Setting up your computer after a reset or recovery
To locate resources that provide product details, how-to information, and more, use this table.
Table 6-1 Additional information
Resource | Contents |
Setup Instructions |
|
HP website |
|
Worldwide support To get support in your language, go to http://www.hp.com/support, and select your country. |
|
Safety & Comfort Guide |
|
Regulatory, Safety, and Environmental Notices This guide is provided in the box. |
|
Limited Warranty* Go to http://www.hp.com/go/orderdocuments |
|
*You can find your HP Limited Warranty located with the user guides on your product and/or on the CD or DVD provided in the box. In some countries or regions, HP may provide a printed warranty in the box. For countries or regions where the warranty is not provided in printed format, you can request a copy from http://www.hp.com/go/orderdocuments. For products purchased in Asia Pacific, you can write to HP at POD, PO Box 161, Kitchener Road Post Office, Singapore 912006. Include your product name, and your name, phone number, and postal address.
When you travel with or store your computer, the input power ratings and operating specifications provide helpful information.
Input power
The power information in this section might be helpful if you plan to travel internationally with the computer.
The computer operates on DC power, which can be supplied by an AC or a DC power source. The AC power source must be rated at 100 V–240 V, 50 Hz–60 Hz. Although the computer can operate from a standalone DC power source, it should be used only with an AC adapter or a DC power source that is supplied and approved by HP for use with this computer.
The computer can operate on DC power within one or more of the following specifications. Operating voltage and current varies by platform. The voltage and current for your computer is located on the regulatory label.
Table 7-1 DC power specifications
Input power | Rating |
Operating voltage and current | 5 V dc @ 2 A / 12 V dc @ 3 A /15 V dc @ 3 A – 45 W USB-C® 5 V dc @ 3 A / 9 V dc @ 3 A / 12 V dc @ 3.75 A /15 V dc @ 3 A – 45 W USB-C 5 V dc @ 3 A / 9 V dc @ 3 A / 10 V dc @ 3.75 A / 12 V dc @ 3.75 A / 15 V dc @ 3 A / 20 V dc @ 2.25 A – 45 W USB-C 5 V dc @ 3 A / 9 V dc @ 3 A / 12 V dc @ 5 A / 15 V dc @ 4.33 A / 20 V dc @ 3.25 A – 65 W USB-C 5 V dc @ 3 A / 9 V dc @ 3 A / 10 V dc @ 5 A / 12 V dc @ 5 A / 15 V dc @ 4.33 A / 20 V dc @ 3.25 A – 65 W USB-C 5 V dc @ 3 A / 9 V dc @ 3 A / 10 V dc @ 5 A / 12 V dc @ 5 A / 15 V dc @ 5 A / 20 V dc @ 4.5 A – 90 W USB-C 19.5 V dc @ 2.31 A – 45 W 19.5 V dc @ 3.33 A – 65 W 19.5 V dc @ 4.62 A – 90 W 19.5 V dc @ 6.15 A – 120 W 19.5 V dc @ 6.9 A – 135 W 19.5 V dc @ 7.70 A – 150 W 19.5 V dc @ 10.3 A – 200 W 19.5 V dc @ 11.8 A – 230 W 19.5 V dc @ 16.92 A – 330 W |
DC plug of external HP power supply (select products only) | ![]() |
NOTE: This product is designed for IT power systems in Norway with phase-to-phase voltage not exceeding 240 V ems.
Operating environment
Use the operating specifications for helpful information when you travel with or store your computer.
Table 7-2 Operating environment specifications
Factor | Metric | U.S. |
Temperature | ||
Operating | 5°C to 35°C | 41°F to 95°F |
Nonoperating | –20°C to 60°C | –4°F to 140°F |
Relative humidity (noncondensing) | ||
Operating | 10% to 90% | 10% to 90% |
Nonoperating | 5% to 95% | 5% to 95% |
Maximum altitude (unpressurized) | ||
Operating | –15 m to 3,048 m | –50 ft to 10,000 ft |
Nonoperating | –15 m to 12,192 m | –50 ft to 40,000 ft |
Electrostatic discharge is the release of static electricity when two objects come into contact—for example, the shock you receive when you walk across the carpet and touch a metal door knob.
A discharge of static electricity from fingers or other electrostatic conductors may damage electronic components.
To prevent damage to the computer, damage to a drive, or loss of information, observe these precautions:
HP's goal is to design, produce, and market products, services, and information that everyone everywhere can use, either on a stand-alone basis or with appropriate third-party assistive technology (AT) devices or applications.
HP and accessibility
Because HP works to weave diversity, inclusion, and work/life into the fabric of the company, it is reflected in everything HP does. HP strives to create an inclusive environment focused on connecting people to the power of technology throughout the world.
Finding the technology tools you need
Technology can unleash your human potential. Assistive technology removes barriers and helps you create independence at home, at work, and in the community. Assistive technology helps increase, maintain, and improve the functional capabilities of electronic and information technology.
For more information, see Finding the best assistive technology.
The HP commitment
HP is committed to providing products and services that are accessible for people with disabilities. This commitment supports the company's diversity objectives and helps ensure that the benefits of technology are available to all.
The HP accessibility goal is to design, produce, and market products and services that can be effectively used by everyone, including people with disabilities, either on a stand-alone basis or with appropriate assistive devices.
To achieve that goal, this Accessibility Policy establishes seven key objectives to guide HP actions. All HP managers and employees are expected to support these objectives and their implementation in accordance with their roles and responsibilities:
International Association of Accessibility Professionals (IAAP)
IAAP is a not-for-profit association focused on advancing the accessibility profession through networking, education, and certification. The objective is to help accessibility professionals develop and advance their careers and to better enable organizations to integrate accessibility into their products and infrastructure.
As a founding member, HP joined to participate with other organizations to advance the field of accessibility. This commitment supports HP's accessibility goal of designing, producing, and marketing products and services that people with disabilities can effectively use.
IAAP will make the profession strong by globally connecting individuals, students, and organizations to learn from one another. If you are interested in learning more, go to http://www.accessibilityassociation.org to join the online community, sign up for newsletters, and learn about membership options.
Finding the best assistive technology
Everyone, including people with disabilities or age-related limitations, should be able to communicate, express themselves, and connect with the world using technology. HP is committed to increasing accessibility awareness within HP and with our customers and partners.
Whether it's large fonts that are easy on the eyes, voice recognition that lets you give your hands a rest, or any other assistive technology to help with your specific situation—a variety of assistive technologies make HP products easier to use. How do you choose?
Assessing your needs
Technology can unleash your potential. Assistive technology removes barriers and helps you create independence at home, at work, and in the community. Assistive technology (AT) helps increase, maintain, and improve the functional capabilities of electronic and information technology.
You can choose from many AT products. Your AT assessment should allow you to evaluate several products, answer your questions, and facilitate your selection of the best solution for your situation. You will find that professionals qualified to do AT assessments come from many fields, including those licensed or certified in physical therapy, occupational therapy, speech/language pathology, and other areas of expertise. Others, while not certified or licensed, can also provide evaluation information. You will want to ask about the individual's experience, expertise, and fees to determine if they are appropriate for your needs.
Accessibility for HP products
These links provide information about accessibility features and assistive technology, if applicable, included in various HP products. These resources will help you select the specific assistive technology features and products most appropriate for your situation.
If you need additional support with the accessibility features on your HP product, see Contacting support.
Additional links to external partners and suppliers that may provide additional assistance:
Standards and legislation
Countries worldwide are enacting regulations to improve access to products and services for persons with disabilities. These regulations are historically applicable to telecommunications products and services, PCs and printers with certain communications and video playback features, their associated user documentation, and their customer support.
Standards
The US Access Board created Section 508 of the Federal Acquisition Regulation (FAR) standards to address access to information and communication technology (ICT) for people with physical, sensory, or cognitive disabilities.
The standards contain technical criteria specific to various types of technologies, as well as performancebased requirements which focus on functional capabilities of covered products. Specific criteria cover software applications and operating systems, web-based information and applications, computers, telecommunications products, video and multimedia, and self-contained closed products.
Mandate 376 – EN 301 549
The European Union created the EN 301 549 standard within Mandate 376 as an online toolkit for public procurement of ICT products. The standard specifies the accessibility requirements applicable to ICT products and services, with a description of the test procedures and evaluation methodology for each requirement.
Web Content Accessibility Guidelines (WCAG)
Web Content Accessibility Guidelines (WCAG) from the W3C's Web Accessibility Initiative (WAI) helps web designers and developers create sites that better meet the needs of people with disabilities or age-related limitations.
WCAG advances accessibility across the full range of web content (text, images, audio, and video) and web applications. WCAG can be precisely tested, is easy to understand and use, and allows web developers flexibility for innovation. WCAG 2.0 has also been approved as ISO/IEC 40500:2012.
WCAG specifically addresses barriers to accessing the web experienced by people with visual, auditory, physical, cognitive, and neurological disabilities, and by older web users with accessibility needs. WCAG 2.0 provides characteristics of accessible content:
Useful accessibility resources and links
These organizations, institutions, and resources might be good sources of information about disabilities and age-related limitations.
NOTE: This is not an exhaustive list. These organizations are provided for informational purposes only. HP assumes no responsibility for information or contacts you encounter on the Internet. Listing on this page does not imply endorsement by HP.
Organizations
These organizations are a few of the many that provide information about disabilities and age-related limitations.
Educational institutions
Many educational institutions, including these examples, provide information about disabilities and agerelated limitations.
Useful accessibility resources and links
Other disability resources
Many resources, including these examples, provide information about disabilities and age-related limitations.
HP links
These HP-specific links provide information that relates to disabilities and age-related limitations.
Our contact webform
HP comfort and safety guide HP public sector sales
Contacting support
HP offers technical support and assistance with accessibility options for customers with disabilities.
NOTE: Support is in English only.
Reduce the possibility of heat-related injuries or of overheating the computer by following the practices described.
To reduce the possibility of heat-related injuries or of overheating the computer, do not place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to come into contact with the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with the user-accessible surface temperature limits defined by applicable safety standards.
Product notice
This guide describes features that are common to most models. Some features may not be available on your computer.
Software terms
By installing, copying, downloading, or otherwise using any software product preinstalled on this computer, you agree to be bound by the terms of the HP End User License Agreement (EULA). If you do not accept these license terms, your sole remedy is to return the entire unused product (hardware and software) within 14 days for a full refund subject to the refund policy of your seller.
For any further information or to request a full refund of the price of the computer, please contact your seller.
Here you can download full pdf version of manual, it may contain additional safety instructions, warranty information, FCC rules, etc.
Download HP Chromebook 11a, 11a-na0021nr, 11a-na0010nr Manual
Advertisement
Need help?
Do you have a question about the Chromebook 11a and is the answer not in the manual?
Questions and answers
