Page 1 Hardware and Software Guide HP Compaq Notebook Series Document Part Number: 393677-002 June 2005 This guide explains how to identify and use the notebook hardware features, including connectors and external devices. It also includes security, software, and specification information.
Page 2 The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Page 3: Table Of Contents
1 Notebook Features Top Components ....... 1–2 Lights ........1–2 Pointing Devices .
Page 4 Contents Default Power Settings......2–9 Turning the Notebook or Display On or Off ..2–10 Initiating or Resuming from Standby .
Page 5 3 Pointing Devices and Keyboard Pointing Devices ....... 3–1 TouchPad (Select Models Only) ....3–1 Pointing Stick (Select Models Only) .
Page 6 Contents Using WinDVD Creator Plus Select Models Only) ......4–12 Using Sonic RecordNow! ....4–13 Changing DVD Region Settings (Select Models Only).
Page 7 Adding and Upgrading Memory Modules ... 5–20 Adding a Memory Module to the Expansion Memory Module Slot......5–21 Upgrading the Memory Module in the Primary Memory Module Slot.
Page 8 HP and Windows Password Guidelines ..7–6 HP Administrator Passwords ..... . 7–7 Setting HP Administrator Passwords .
Page 9 Accessing Computer Information ....11–2 Obtaining the Support Software CD ... . 11–3 Software Updates and the HP Web Site ..11–3 Hardware and Software Guide...
Page 10 Contents System Recovery ......11–8 Safeguarding Your Data ..... 11–8 Altiris Local Recovery.
Page 11: Notebook Features
Notebook Features This chapter describes hardware features of the notebook. ✎ Components included with your notebook may vary by geographical region and by model. The illustrations in this chapter identify the standard external features included in most notebook models. Refer to the illustrations that most closely match your notebook.
Page 12: Top Components
Notebook Features Top Components Lights ✎ Refer to the illustration that most closely matches your notebook. Component Power/standby light Wireless lights (2) 1–2 Description Green: The notebook is on. Blinking green: The notebook is in standby mode. Off: The notebook is off or in hibernation.
Page 13 Component Power/standby light Battery light IDE (Integrated Drive Electronics) drive light Volume mute light Num lock light Caps lock light Hardware and Software Guide Notebook Features Description Green: The notebook is on. Blinking green: The notebook is in standby mode. Off: The notebook is off or in hibernation.
Page 14 Notebook Features Component Power/standby light Wireless lights (2) Power/standby light 1–4 Description Green: The notebook is on. Blinking green: The notebook is in standby mode. Off: The notebook is off or in hibernation. On: An integrated wireless device, such as a wireless LAN device and/or a Bluetooth device is turned on.
Page 15 Component Battery light IDE drive light Num lock light Caps lock light Hardware and Software Guide Notebook Features Description Amber: A battery pack is charging. Green: A battery pack is close to full charge capacity. Blinking amber: A battery pack that is the only available power source has reached a low-battery condition.
Page 16: Pointing Devices
Notebook Features Pointing Devices TouchPad (Select Models Only) Component TouchPad* Left TouchPad button* Right TouchPad button* TouchPad scroll zone* *This table describes default settings. For information about changing the functions of TouchPad features, see the section in Chapter 3 , “Pointing Devices and Keyboard.” 1–6 Description Moves the pointer and selects or...
Page 17 Pointing Stick (Select Models Only) Component Pointing stick Left pointing stick button Right pointing stick button Hardware and Software Guide Notebook Features Description Moves the pointer and selects or activates items on the screen. Functions like the left button on an external mouse.
Page 18: Buttons And Switches
Notebook Features Buttons and Switches ✎ Refer to the illustration that most closely matches your notebook. Component Power/standby button* 1–8 Description When the notebook is: ■ Off, press the button to turn on the notebook. ■ In standby, briefly press the button to exit standby.
Page 19 To establish a wireless connection, a wireless network must already be set up. For more information about establishing a wireless connection from Windows, visit http://www.hp.com/go/wireless. Turns on Presentation mode. Mutes system sound. Decreases system volume. Increases system volume. “Power Options”...
Page 20 Notebook Features Component Power/standby button* 1–10 Description When the notebook is: ■ Off, press the button to turn on the notebook. ■ In standby, briefly press the button to exit standby. ■ In hibernation, briefly press the button to exit hibernation. If the notebook has stopped responding and Microsoft Windows shutdown procedures cannot be used,...
Page 21 To establish a wireless connection, a wireless network must already be set up. For more information about establishing a wireless connection from Windows, visit http://www.hp.com/go/wireless. “Power Options” For information about changing the functions of Chapter 6 , “Wireless.” Notebook Features section in...
Page 22: Keys
Notebook Features Keys ✎ Your notebook may look slightly different from the illustration in this section. Component Function keys fn key Windows logo key Windows applications key Keypad keys 1–12 Description Execute frequently used system functions when pressed in combination with the fn key.
Page 23: Front Components
Front Components ✎ Refer to the illustration that most closely matches your notebook. Component Infrared port Speakers (2) 6-in-1 Digital Media Slot (select models only) 6-in-1 Digital Media Slot light (select models only) Display release latch Hardware and Software Guide Notebook Features Description Provides wireless communication...
Page 24 Notebook Features Component Speaker Display release latch 1–14 Description Produce notebook sound. Opens the notebook. Hardware and Software Guide...
Page 25: Wireless Antennae (Select Models Only)
Wireless Antennae (Select Models Only) Å WARNING: Exposure to Radio Frequency Radiation. The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential for human contact during normal operation is minimized.
Page 26: Rear Components
Notebook Features Rear Components ✎ Refer to the illustration that most closely matches your notebook. Component Security cable slot Power connector Parallel port S-Video-out jack 1–16 Description Attaches an optional security cable to the notebook. Ä Security solutions are designed to act as deterrents. These deterrents may not prevent a product from being mishandled or stolen.
Page 27 Component Security cable slot Power connector Hardware and Software Guide Notebook Features Description Attaches an optional security cable to the notebook. Ä Security solutions are designed to act as deterrents. These deterrents may not prevent a product from being mishandled or stolen. Connects an AC adapter or an optional automobile or aircraft adapter.
Page 28: Right-Side Components
Notebook Features Right-Side Components ✎ Refer to the illustration that most closely matches your notebook. Component Audio-out (headphone) jack Audio-in (microphone) jack USB ports (2) Optical drive (select models only) Optical drive button (select models only) Serial port 1–18 Description Produces system sound when connected to optional powered stereo speakers, headphones, headset, or...
Page 29 Component Audio-out (headphone) jack Audio-in (microphone) jack Optical drive (select models only) Optical drive button (select models only) Hardware and Software Guide Notebook Features Description Produces system sound when connected to optional powered stereo speakers, headphones, headset, or television audio. Connects an optional stereo or monaural microphone.
Page 30: Left-Side Components
Notebook Features Left-Side Components ✎ Refer to the illustration that most closely matches your notebook. Component USB ports (2) External monitor port RJ-11 (modem) jack RJ-45 (network) jack 1–20 Description Connect USB 1.1- and 2.0-compliant devices to the notebook using a standard USB cable, or connect an optional External MultiBay II to the notebook.
Page 31 Component 1394 port PC Card slots (2) PC Card slot eject buttons (2) Eject PC Cards from the PC Card Hardware and Software Guide Notebook Features Description Connects an optional IEEE 1394 device, such as a camcorder. Support optional Type I, Type II, or Type III 32-bit (CardBus) or 16-bit PC Cards.
Page 32 Notebook Features Component USB ports (2) External monitor port RJ-11 (modem) jack RJ-45 (network) jack 1394 port PC Card slot (1) PC Card slot eject button (1) 1–22 Description Connect USB 1.1- and 2.0-compliant devices to the notebook using a standard USB cable, or connect an optional External MultiBay II to the notebook.
Page 33: Bottom Components
Bottom Components ✎ Refer to the illustration that most closely matches your notebook. Component Primary battery bay Primary battery release latches (2) Travel battery connector Expansion memory module compartment Hardware and Software Guide Notebook Features Description Holds the primary battery pack. Releases the primary battery pack from the battery bay.
Page 34 Notebook Features Component Hard drive bay Vents (4) Docking connector 1–24 Description Holds the hard drive. Enable airflow to cool internal components. Ä To prevent overheating, do not obstruct vents. Using the notebook on a soft surface, such as a pillow, blanket, rug, or thick clothing, may block airflow.
Page 35 Component Primary battery bay Primary battery release latches (2) Travel battery connector Expansion memory module compartment Hard drive bay Vents (4) Hardware and Software Guide Notebook Features Description Holds the primary battery pack. Release the primary battery pack from the battery bay. The primary battery locking latches must be in the unlocked position.
Page 36: Additional Hardware Components
Notebook Features Additional Hardware Components Component Power cord* AC adapter Primary battery pack Modem cable* (select models only) *Modem cables and power cords vary in appearance by region and country. Battery packs vary by model. 1–26 Description Connects an AC adapter to an AC Outlet.
Page 37: Labels
Labels The labels affixed to the notebook provide information you may need when you troubleshoot system problems or travel internationally with the notebook. ■ Service Tag—Provides the product name, product number (P/N), and serial number (S/N) of your notebook. You may need the product number and the serial number when you contact Customer Care.
Page 38: Power
Power Power Control and Light Locations The following illustration and table identify and describe the power control and light locations. ✎ Your notebook may look slightly different from the illustrations in this section. Hardware and Software Guide 2–1...
Page 39 Power Component Power/standby light Power/standby button* 2–2 Description Green: The notebook is on. Blinking green: The notebook is in standby mode. Off: The notebook is off or in hibernation. When the notebook is: ■ Off, press the button to turn on the notebook.
Page 40 Component Power/standby light Battery light fn+f3 Display switch Hardware and Software Guide Description Green: The notebook is on. Blinking green: The notebook is in standby mode. Off: The notebook is off or in hibernation. Amber: A battery pack is charging. Green: A battery pack is close to full charge capacity.
Page 41: Power Sources
Power Power Sources The notebook can run on internal or external AC power. The following table indicates the best power sources for common tasks. Task Work in most software applications Charge or calibrate a battery pack in the notebook Install or modify system software or write to a CD 2–4 Recommended Power Source...
Page 42: Standby And Hibernation
Standby and Hibernation Standby and hibernation are energy-saving features that conserve power and reduce startup time. They can be initiated by you or by the system. Refer to the Shutdown” each setting. Standby Ä CAUTION: To avoid a complete battery discharge, do not leave your notebook in standby for extended periods.
Page 43: Hibernation
Power Hibernation Ä CAUTION: If the configuration of the notebook is changed during hibernation, resuming from hibernation may not be possible. When the notebook is in hibernation: ■ Do not dock the notebook or undock the notebook from a docking device.
Page 44: Initiating Standby, Hibernation Or Shutdown
Initiating Standby, Hibernation or Shutdown The following sections explain when to initiate standby or hibernation and when to shut down your notebook. ✎ You cannot initiate any type of networking communications or perform any computer functions while the notebook is in standby or hibernation.
Page 45: When The Power Supply Is Uncertain
Power When the Power Supply Is Uncertain Make sure that hibernation remains enabled, especially if you are operating the notebook on battery power and do not have access to an external power supply. If the battery pack fails, hibernation saves your work to a hibernation file and shuts down the notebook.
Page 46: Default Power Settings
Power Default Power Settings This section explains the default standby, hibernation, and shutdown procedures. For information about changing the function of some of the power features, on your notebook, see the section later in this chapter. “Power Options” The controls and lights discussed in this section are illustrated in “Power Control and Light Locations”...
Page 47: Turning The Notebook Or Display On Or Off
Power Turning the Notebook or Display On or Off Task Procedure Turn on the Press the power/standby button. notebook. Shut down the Save your work and close all open notebook.* applications. Then either ■ Press the power/standby button and follow the on-screen directions (if displayed) for shutting down the notebook.
Page 48: Initiating Or Resuming From Standby
Initiating or Resuming from Standby Task Procedure ■ Initiate With the notebook on, press standby. fn+f3 ❐ ❐ ■ Close the notebook lid. Allow the No action required. system to ■ If the notebook is running on initiate battery power, the system standby.
Page 49: Initiating Or Restoring From Hibernation
Power Initiating or Restoring from Hibernation Hibernation cannot be initiated unless it is enabled. Hibernation is enabled by default. To verify that hibernation remains enabled: » Select Start > Control Panel > Performance and Maintenance > Power Options > Hibernate tab. If hibernation is enabled, the Enable Hibernation check box is selected.
Page 50 Task Procedure Allow the system No action required. If the to initiate notebook is running on hibernation (with battery power, the system hibernation initiates hibernation enabled). ■ ■ Power settings and timeouts can be changed in the Power Options in Windows Control Panel.
Page 51: Using Emergency Shutdown Procedures
Power Using Emergency Shutdown Procedures Ä CAUTION: Emergency shutdown procedures result in the loss of unsaved data. If the notebook is unresponsive and you are unable to use normal Windows shutdown procedures, try the following emergency procedures in the sequence provided: ■...
Page 52: Accessing The Power Options Properties
Accessing the Power Options Properties To access the Power Options Properties: ■ Right-click the Power Meter icon in the notification area (at the far right of the taskbar), and then select Adjust Power Properties. – or – ■ Select Start > Control Panel > Performance and Maintenance >...
Page 53: Setting Or Changing A Power Scheme
Power Setting or Changing a Power Scheme The Power Schemes tab in the Power Options Properties dialog box assigns power levels to system components. You can assign different schemes depending on whether the notebook is running on a battery pack or external power. You can also set a power scheme that initiates standby or turns off the display or hard drive after a time interval that you specify.
Page 54: Processor Performance Controls
Processor Performance Controls On select notebook models, Windows XP supports software that enables you to control processor performance. The central processing unit (CPU) speed can be set for optimal performance or for optimal power conservation. For example, the software can be set to trigger an automatic change in processor speed when the power source changes from external power to battery pack power, or when the notebook use changes between active and idle.
Page 55 After a power scheme has been set, no other intervention is required to control the performance of your notebook processor. The following table describes the processor performance on external and battery power for the available power schemes. Power Scheme Home/Office Desk Portable/Laptop Presentation Always On Minimal Power Management Max Battery 2–18...
Page 56: Battery Packs
Power Battery Packs When the notebook is connected to external AC power, the notebook runs on AC power. When a charged battery pack is in the notebook and the notebook is not connected to external power, the notebook runs on battery power. The notebook alternates between AC power and battery power according to the availability of an external AC power source.
Page 57: Identifying Battery Packs
Å WARNING: To reduce potential safety issues, only the battery pack provided with the computer, a replacement battery pack provided by HP, or a compatible battery pack purchased as an accessory from HP should be used with the notebook. 2–20 “Storing a Battery Pack”...
Page 58: Inserting Or Removing A Primary Battery Pack
Inserting or Removing a Primary Battery Pack Ä CAUTION: To prevent loss of work when removing a battery pack that is the sole power source, initiate hibernation or turn off the notebook before removing the battery pack. To insert a primary battery pack: 1.
Page 59 Power To remove a primary battery pack: 1. Turn the notebook upside down with the battery bay facing you. 2. Slide the battery locking latch 1 to the right. 3. Slide and hold the battery release latch 2 to the right. 4.
Page 60: Charging Battery Packs
WARNING: To reduce potential safety issues, only the AC adapter provided with the computer, a replacement AC adapter provided by HP, or an AC adapter purchased as an accessory from HP should be used with the notebook. Hardware and Software Guide Power 2–23...
Page 61: Charging A New Battery Pack
Power Charging a New Battery Pack Fully charge the battery pack while the notebook is connected to external power through the AC adapter. A new battery pack that has been partially charged can run the notebook, but the battery charge indicators may be inaccurate. Charging an In-Use Battery Pack To prolong battery life and increase the accuracy of battery charge indicators:...
Page 62: Monitoring The Charge Of A Battery Pack
Monitoring the Charge of a Battery Pack This section explains several ways to determine the amount of charge in your battery pack. Obtaining Accurate Charge Information To increase the accuracy of all battery charge displays: ■ Allow a battery pack to discharge to about 10 percent of a full charge through normal use before charging it.
Page 63 Power Interpreting Charge Displays Most charge displays report battery status as both a percentage and as the the number of minutes of charge remaining: ■ The percent indicates the approximate amount of charge remaining in the battery pack. ■ The time indicates the approximate running time remaining on the battery pack if the battery pack continues to provide power at the current level.
Page 64: Managing Low-Battery Conditions
Managing Low-Battery Conditions The information in this section describes the alerts and system responses set at the factory. Some low-battery condition alerts and system responses can be changed using Power Options in Windows Control Panel. Preferences set in the Power Options window do not affect lights.
Page 65: Resolving Low-Battery Conditions
Power Resolving Low-Battery Conditions Ä CAUTION: To reduce the risk of data loss when the notebook reaches a critical low-battery condition and has initiated hibernation, do not restore power until the power/standby lights are turned off. When External Power Is Available To resolve a low-battery condition when external power is available, do one of the following: ■...
Page 66: Calibrating A Battery Pack
Calibrating a Battery Pack When to Calibrate Even if a battery pack is heavily used, it should not be necessary to calibrate it more than once a month. It is not necessary to calibrate a new battery pack before first use. Calibrate the battery pack under the following conditions: ■...
Page 67: Discharging The Battery Pack
Power Discharging the Battery Pack Before you begin a full discharge, disable hibernation. To disable hibernation: 1. Select Start > Control Panel > Performance and Maintenance > Power Options > Hibernate tab. 2. Clear the Enable Hibernation check box 3. Select Apply. The notebook must remain on while the battery pack is being discharged.
Page 68 To fully discharge a battery pack: 1. Right-click the Power Meter icon in the notification area (at the far right of the taskbar), and then select Adjust Power Properties. – or – Access the Power Schemes tab by selecting Start > Control Panel >...
Page 69: Recharging The Battery Pack
Power Recharging the Battery Pack To recharge the battery pack: 1. Connect the notebook to external power and maintain the connection until the battery pack is fully recharged. At that time, the battery light on the notebook is turned off. You can use the notebook while the battery pack is recharging but the battery pack will charge faster if the notebook is off.
Page 70: Conserving Battery Power
Conserving Battery Power Using the battery conservation procedures and settings described in this section extends the time that a battery pack can run the notebook from a single charge. Conserving Power As You Work To conserve power as you use the notebook: ■...
Page 71: Selecting Power Conservation Settings
Power Selecting Power Conservation Settings To set the notebook to conserve power: ■ Select a short wait for the screen saver and select a screen saver with minimal graphics and motion. To access screen saver settings: Select Start > Control Panel > Appearance and Themes > Choose a screen saver.
Page 72: Storing A Battery Pack
Storing a Battery Pack Ä CAUTION: To prevent damage to a battery pack, do not expose it to high temperatures for extended periods of time. If a notebook will be unused and disconnected from external power for more than 2 weeks, remove any battery packs and store them separately.
Page 73: Disposing Of A Used Battery Pack
In Europe, dispose of or recycle the battery packs by using the public collection system or by returning them to HP, your authorized service partner, or their agents. 2–36...
Page 74: Pointing Devices And Keyboard
Pointing Devices and Keyboard Pointing Devices TouchPad (Select Models Only) The following illustration and table identify and describe the notebook TouchPad. Component TouchPad* Hardware and Software Guide Description Moves the pointer and selects or activates items on the screen. Can be set to perform other mouse functions, such as scrolling, selecting, and double-clicking.
Page 75: Using The Touchpad
Pointing Devices and Keyboard Component Left TouchPad button* Right TouchPad button* TouchPad scroll zone* *This table describes default settings. For information about changing the functions of TouchPad features, see the section in this chapter. Using the TouchPad To move the pointer, slide your finger across the TouchPad surface in the direction you want the pointer to go.
Page 76: Pointing Stick (Select Models Only)
Pointing Stick (Select Models Only) Component Pointing stick Left pointing stick button Right pointing stick button Hardware and Software Guide Pointing Devices and Keyboard Description Moves the pointer and selects or activates items on the screen. Functions like the left button on an external mouse.
Page 77: Using The Pointing Stick
Pointing Devices and Keyboard Using the Pointing Stick To move the pointer, press the pointing stick in the direction you want to move the pointer. Use the left and right pointing stick buttons as you would the left and right buttons on an external mouse.
Page 78: Using An External Mouse
Using an External Mouse An external USB mouse can be connected to the notebook using one of the ports on the right or left side of the notebook. An external serial mouse, external PS/2 mouse, or USB mouse can be connected to the system using the connectors on an optional docking device (select models only).
Page 79: Hotkeys
Pointing Devices and Keyboard Hotkeys Hotkeys are preset combinations of the key 2 or one of the function keys 3. The icons on the hotkey functions. Hotkey functions and procedures are discussed in the following sections. ✎ Your notebook may look slightly different from the illustration in this section.
Page 80: Hotkey And Shortcut Key Quick Reference
Hotkey and Shortcut Key Quick Reference Function Initiate standby Switch between notebook display and external display View battery information Decrease screen brightness Increase screen brightness Display system information Hardware and Software Guide Pointing Devices and Keyboard Key Combination to Activate Function fn+f3 fn+f4...
Page 81: Initiating Standby (Fn+F3)
Pointing Devices and Keyboard Initiating Standby (fn+f3) When the notebook is on, press the standby. When standby is initiated, your work is saved in random access memory (RAM), the screen is cleared, and power is conserved. While the notebook is in standby, the power/standby lights blink.
Page 82: Switching Displays (Fn+F4)
Switching Displays (fn+f4) hotkey switches the image among display devices fn+f4 connected to the external monitor connector or the S-Video-out jack (select models only) on the notebook. For example, if an external monitor is connected to the notebook, pressing the hotkey multiple times alternates the image between the notebook display, the external monitor display, and a simultaneous display on both the notebook and the monitor.
Page 83: Decreasing Screen Brightness (Fn+F9)
Pointing Devices and Keyboard Decreasing Screen Brightness (fn+f9) Press to decrease screen brightness. Hold down the hotkey fn+f9 to change the brightness level incrementally. Increasing Screen Brightness (fn+f10) Press fn+f10 to change the brightness level incrementally. Displaying System Information (fn+esc) Press fn+esc components and software version numbers.
Page 84: Quick Launch Buttons (Select Models Only)
Quick Launch Buttons (Select Models Only) Use the Quick Launch buttons to open frequently used applications. Component Info Center button Presentation mode button Hardware and Software Guide Pointing Devices and Keyboard Description Launches Info Center, which enables you to open various software solutions. Refer to “Info Center (Select Models Only)”...
Page 85: Keypads
Pointing Devices and Keyboard Keypads The notebook has an embedded numeric keypad and also supports an optional external keypad or an optional external keyboard that includes a numeric keypad. ✎ Your notebook may look slightly different from the illustration in this section.
Page 86: Using The Embedded Numeric Keypad
Using the Embedded Numeric Keypad The 15 keys of the embedded numeric keypad can be used like the keys on an external keypad. When the embedded numeric keypad is turned on, each key on the keypad performs the function indicated by the icon in the upper-right corner of the key. Enabling and Disabling the Embedded Numeric Keypad Press...
Page 87: Using An External Keypad
Pointing Devices and Keyboard Using an External Keypad Most keys on most external keypads function differently according to whether num lock mode is on or off. (By default num lock mode is off.) For example: ■ When num lock is on, most keypad keys type numbers. ■...
Page 88: Multimedia
Multimedia Audio Features The following figure and table describe the audio features of the notebook. ✎ Components included with your notebook may vary by geographical region and by model. The illustrations in this chapter identify the standard features included in most notebook models.
Page 89 Multimedia Component Volume mute button Volume mute light Volume down button Volume up button Audio-in (microphone) jack Audio-out (headphone) jack Speakers (2) 4–2 Description Turns off notebook sound. On: Notebook sound is turned off. Decreases notebook sound. Increases notebook sound. Connects an optional stereo or monaural microphone.
Page 90 Component Speaker Audio-out (headphone) jack Audio-in (microphone) jack Hardware and Software Guide Description Produces notebook sound. Produces notebook sound when connected to optional powered stereo speakers, headphones, headset, or television audio. Connects an optional stereo or monaural microphone. Multimedia 4–3...
Page 91: Using The Audio-In (Microphone) Jack
Multimedia Using the Audio-In (Microphone) Jack Your notebook is equipped with a stereo microphone jack that supports a stereo array and monaural microphone. Using sound recording application software with an external, stereo microphone allows for stereo (dual channel) recordings and stereo playbacks.
Page 92: Adjusting The Volume
Adjusting the Volume You can adjust the volume using any of the following controls: ■ Notebook volume buttons (select models only) ❏ To mute or restore volume, press the volume mute button. ❏ To decrease the volume, press the volume down button. ❏...
Page 93: Video Features (Select Models Only)
Multimedia Video Features (Select Models Only) The notebook features a 7-pin S-Video-out jack that connects the notebook to an optional S-Video device such as a television, VCR, camcorder, overhead projector, or video capture card. The notebook can support one S-Video device connected to the S-Video-out jack while simultaneously supporting an image on the notebook display and on any other supported external display.
Page 94: Using The S-Video-Out Jack
Using the S-Video-out Jack To connect a video device to the S-Video-out jack: 1. Plug one end of the S-Video cable into the S-Video-out jack on the notebook. 2. Connect the other end of the cable to the video device, as instructed in the documentation included with the device.
Page 95: Connecting A Monitor Or Projector
Multimedia Connecting a Monitor or Projector To connect an external monitor or projector to the notebook, insert the monitor cable into the external monitor port on the left side of the notebook. ✎ Your notebook may look slightly different from the illustration in this section.
Page 96: Multimedia Software
If you do not have the Application and Driver Recovery disc, contact Customer Care for a copy of the restore solution for your notebook. ❏ Download the software from the HP Web site: http://www.hp.com ■ InterVideo WinDVD Creator Plus—Provides the ability to create, edit, and burn movies to a DVD or video CD.
Page 97: Installing Software
Multimedia Installing Software ✎ To use CDs or DVDs on notebooks shipped with no optical drive, you will need to use an optional external MultiBay or MultiBay II. To install software from a CD included with the notebook: 1. Insert the software CD into the optical drive (select models only) or into an optional external MultiBay or MultiBay II.
Page 98: Enabling Autoplay
Enabling AutoPlay AutoPlay is an option in Windows that turns the Autorun feature on or off. Autorun starts a program or plays a title on a disc as soon as it is inserted into the drive and the drive door is closed. By default, AutoPlay is enabled on the notebook.
Page 99: Using Windvd Player
Multimedia Using WinDVD Player InterVideo WinDVD can be used to play video CDs and DVD movies. To locate and install InterVideo WinDVD, refer to the “Installing Software” To open WinDVD when AutoPlay has been disabled: » Select Start > (All) Programs > InterVideo WinDVD > InterVideo WinDVD.
Page 100: Using Sonic Recordnow
Using Sonic RecordNow! RecordNow! can be used to create backups of data or audio CDs or DVDs, transfer audio files from CDs to a hard drive, and create personalized audio CDs. RecordNow! is preinstalled on your notebook. For more information about RecordNow! capabilities and instruction on creating data and audio CDs and DVDs, refer to the Sonic RecordNow! Tutorial and online Help.
Page 101: Using The Operating System
Multimedia Using the Operating System Ä CAUTION: The region settings on your DVD drive can be changed only 5 times. ■ The region setting you select the fifth time becomes the permanent region setting on the DVD drive. ■ The number of allowable region changes remaining on the drive is displayed in the Changes remaining field on the DVD Region tab..
Page 102: Using Other Dvd Software
Using WinDVD To change the region settings on a drive using WinDVD: 1. Open WinDVD through one of the following methods: ❏ Select the WinDVD Player icon in the notification area, at the far right of the taskbar. ❏ Select Start > (All) Programs > InterVideo WinDVD > InterVideo WinDVD.
Page 103: Presentation Mode (Select Models Only)
Multimedia Presentation Mode (Select Models Only) The Presentation Mode Quick Launch button turns Presentation mode on and off. Turning Presentation mode on opens an application, folder, file, or Web site that you specify. The image simultaneously displays on the notebook screen and on an external device connected to ■...
Page 104 When you first click on the Presentation mode button, the Presentation Settings dialog box displays. In this dialog box, you can ■ Set the program to start when the button is pressed. ■ Choose a power scheme. ■ Choose whether or not you want to show the Presentation Settings dialog box each time you press Presentation mode button.
Page 105: Quick Launch Buttons Control Panel
Multimedia Quick Launch Buttons Control Panel You can use the Quick Launch Buttons control panel to ■ Change Presentation mode settings (select models only). ■ Set preferences for tiling windows on the Windows desktop. ■ Set advanced preferences, including ❏ Setting preferences for the display of the Quick Launch Buttons icon.
Page 106: Setting Presentation Mode Preferences (Select Models Only)
Setting Presentation Mode Preferences (Select Models Only) Setting the Presentation Mode Button To set an application, folder, file, or Web site to start when the Presentation mode button is pressed: 1. Open the Quick Launch Buttons control panel: ❏ Select Start > Control Panel > Printers and Other Hardware >...
Page 107: Changing The Power Scheme
Multimedia Changing the Power Scheme By default the Presentation power scheme is selected when the Presentation mode button is pressed. To change the power scheme: 1. Open the Quick Launch Buttons control panel: ❏ Select Start > Control Panel > Printers and Other Hardware >...
Page 108: Setting Tiling Preferences
Switching to an External Display By default, the Automatically switch to external display setting in the Presentation tab is not selected. When you press the Presentation mode button, the application, folder, file, or Web site you selected in the Program to Start setting opens. To view the selected application, folder, file, or Web site on an additional, external display: 1.
Page 109: Setting Advanced Preferences
Multimedia Setting Advanced Preferences You can set icon and external keyboard assignments in the Quick Launch Button control panel. Displaying the Quick Launch Buttons Icon To show or hide the Quick Launch Buttons Properties icon in the notification area (at the far right of the taskbar) or on the Windows desktop: 1.
Page 110 Setting Button Assignments on an External Keyboard If you are using an optional HP external keyboard that features Easy Access buttons, you can set Easy Access button assignments and schemes on the Settings tab. The Settings tab is disabled and hidden by default. To display and...
Page 111: Info Center (Select Models Only)
Multimedia Info Center (Select Models Only) Info Center enables you to open the following software solutions: ■ Altiris Local Recovery ■ Contact HP ■ Help and Support ■ Options Demo ■ ProtectTools Security Manager ■ Software Setup ■ System Information ■...
Page 112: Hardware Components
Hardware Components Drives The following sections identify and describe the hard drive, and explain how to use hard drives and optical disc drives (select models only). Caring for Drives Drives are fragile notebook components that must be handled with care. The following cautions apply to all drives. Additional cautions are included with the procedures to which they apply.
Page 113 Hardware Components Ä CAUTION: To reduce the risk of damage to the notebook, damage to a drive, or loss of personal information or critical data, observe these precautions: ■ Initiate standby before you move a notebook or external hard drive from one location to another.
Page 114: Adding A Drive To The System
Adding a Drive to the System Removable drives enable you to store and access data. ■ A standard drive can be added to the system by inserting the drive into an optional docking device (select models only). ■ A USB drive can be added by connecting the drive to a USB port on the notebook or optional docking device (select models only).
Page 115: Identifying The Ide Drive Light
Hardware Components Identifying the IDE Drive Light The IDE drive light blinks when either the hard drive or optical drive (select models only) is being accessed. ✎ Your notebook may look slightly different from the illustration in this section. 5–4 Hardware and Software Guide...
Page 116: Replacing The Hard Drive
Replacing the Hard Drive Ä CAUTION: To prevent system lockup and loss of information: ■ Shut down the notebook before removing the hard drive from the hard drive bay. Do not remove the hard drive while the notebook is on, in standby, or in hibernation. ■...
Page 117 Hardware Components 6. Loosen the hard drive screw 1. 7. Pull the hard drive tab 2 to the right to disconnect the hard drive. 8. Lift the hard drive 3 from the notebook. 5–6 Hardware and Software Guide...
Page 118 Hardware Components To install a hard drive: 1. Insert the hard drive into the hard drive bay on the bottom of the notebook 1. 2. Pull the hard drive tab 2 to the left to connect the hard drive. 3. Tighten the hard drive screw 3. Hardware and Software Guide 5–7...
Page 119 Hardware Components 4. Align the tab 1 on the hard drive cover on the notebook. 5. Close the cover 2. 6. Tighten the hard drive cover screws 3. 5–8 Hardware and Software Guide...
Page 120: Inserting And Removing Optical Discs (Select Models Only)
Inserting and Removing Optical Discs (Select Models Only) ✎ Your notebook may look slightly different from the illustrations in this section. Inserting an Optical Disc 1. Turn on the notebook. 2. Press the release button 1 on the drive bezel to release the media tray.
Page 121 Hardware Components Removing an Optical Disc (With Power) If power is available: 1. Turn on the notebook. 2. Press the release button 1 on the drive bezel to release the media tray, and then pull the tray 2 out until it is fully extended.
Page 122 Hardware Components Removing an Optical Disc (Without Power) ✎ The following illustrations identify the standard external features included in most notebook models. Refer to the illustration that most closely matches your notebook model. If power is unavailable: 1. Insert the end of a paper clip into the release access in the front bezel of the drive.
Page 123 Hardware Components 2. Press gently on the paper clip until the media tray is released, and then pull out the tray until it is fully extended. 3. Remove the disc from the tray by gently pressing down on the spindle while lifting the outer edges of the disc. Handle the disc by the edges, not the flat surfaces.
Page 124: Displaying Optical Disc Contents (Select Models Only)
Displaying Optical Disc Contents (Select Models Only) When an optical disc is inserted into a drive, the contents of the disc display on the screen when Autorun is enabled. To display the contents of a disc when Autorun is not enabled: 1.
Page 125: Using Pc Cards
Hardware Components Using PC Cards Ä CAUTION: If you install software or enablers provided by a PC Card manufacturer, you may not be able to use other PC Cards. If you are instructed by the documentation included with your PC Card to install device drivers: ■...
Page 126: Inserting A Pc Card
Inserting a PC Card Ä CAUTION: To prevent damage to the connectors: ■ Use minimal pressure when inserting a PC Card into a PC Card slot. ■ Do not move or transport the notebook while a PC Card is inserted. 1.
Page 127: Removing A Pc Card
Hardware Components Removing a PC Card Ä CAUTION: To prevent loss of work or an unresponsive system, stop the PC Card before removing it. 1. Stop the PC Card by selecting the Safely Remove Hardware icon in the notification area (at the far right of the taskbar), and then select the PC Card.
Page 128: Using Digital Memory Cards (Select Models Only)
Using Digital Memory Cards (Select Models Only) Optional digital memory cards are removable storage cards that provide a convenient method of storing data and sharing it with other devices such as PDAs and cameras. The optional 6-in-1 Digital Media Slot supports the following digital memory card formats: ■...
Page 129: Inserting An Optional Digital Memory Card
Hardware Components Inserting an Optional Digital Memory Card Ä CAUTION: To prevent damage to the connectors to the digital memory card connectors, use minimal pressure when inserting a digital memory card into a Digital Media Slot. To insert a digital memory card: 1.
Page 130: Removing An Optional Digital Memory Card
Removing an Optional Digital Memory Card Ä CAUTION: To prevent loss of work or system lockup, stop the digital memory card before removing it. To remove a digital memory card: 1. Close all files and applications using the digital memory card. (To stop a data transfer, select the cancel button in the operating system Copying window.) 2.
Page 131: Adding And Upgrading Memory Modules
Hardware Components Adding and Upgrading Memory Modules The notebook has 2 memory module compartments. The primary memory module compartment is located under the keyboard. The expansion memory module compartment is located on the bottom of the notebook. The memory capacity of the notebook can be upgraded by adding a memory module to the expansion slot or by upgrading the existing memory module in the primary memory slot.
Page 132: Adding A Memory Module To The Expansion Memory Module Slot
Adding a Memory Module to the Expansion Memory Module Slot To add or replace a memory module in the expansion memory module slot: 1. Shut down the notebook. (If you are not sure whether the notebook is off or in hibernation, turn the notebook on by pressing the power/standby button.
Page 133 Hardware Components 8. If there is a memory module in the expansion memory module slot, remove it: a. Pull away the retention clips on each side of the memory module 1. (The memory module tilts upward.) b. Grasp the edges of the memory module and gently pull the module out of the memory slot 2.
Page 134 9. Insert the new memory module: a. Align the keyed (notched) edge 1 of the memory module with the tabbed area in the memory slot. b. With the memory module at a 45-degree angle from the surface of the memory module compartment, press the module into the memory slot until it is seated 2.
Page 135 Hardware Components c. Push the memory module downward until the retention clips snap into place. 5–24 Hardware and Software Guide...
Page 136 Hardware Components 10. Replace the memory module cover 1 and tighten the memory module cover screw 2. 11. Replace the battery pack. 12. Reconnect external power and external devices. 13. Restart the notebook. Hardware and Software Guide 5–25...
Page 137: Upgrading The Memory Module In The Primary Memory Module Slot
Hardware Components Upgrading the Memory Module in the Primary Memory Module Slot ✎ Your notebook may look slightly different from the illustrations in this section. To add a memory module to the primary memory module slot: 1. Shut down the notebook. (If you are not sure whether the notebook is off or in hibernation, turn the notebook on by pressing the power/standby button.
Page 138 Hardware Components 8. Remove the 2 keyboard screws. 9. Turn over the notebook and open it. 10. Slide the 4 keyboard latches to release the keyboard. Hardware and Software Guide 5–27...
Page 139 Hardware Components 11. Gently lift the top edge of the keyboard and tilt the keyboard over until it rets on the palm rest of the notebook. 5–28 Hardware and Software Guide...
Page 140 12. Remove the memory module from the memory module slot: a. Pull the retention clips 1 away from each side of the memory module. The memory module tilts upward when released. b. Lift the edge of the memory module 2 and gently remove it from the slot.
Page 141 Hardware Components 13. Insert the new memory module into the memory module slot: a. Align the keyed (notched) edge of the memory module 1 with the keyed area in the memory module slot. b. With the memory module at a 45-degree angle from the surface of the memory module compartment, press the module into the memory slot until it is seated 2.
Page 142 Hardware Components c. Press the memory module downward until the retention clips snap into place. Hardware and Software Guide 5–31...
Page 143 Hardware Components 14. Replace the keyboard and slide the keyboard latches up to lock them. 15. Replace the keyboard access screws located on the bottom of the notebook. 5–32 Hardware and Software Guide...
Page 144 Hardware Components 16. Replace the memory module cover 1 and the memory module cover screw 2. 17. Replace the battery pack. 18. Reconnect the external power and external drives. 19. Restart the notebook. Hardware and Software Guide 5–33...
Page 145: Effects Of Increasing Memory
Hardware Components Effects of Increasing Memory When random access memory (RAM) increases, the operating system increases the hard drive space reserved for the hibernation file. If you experience problems with hibernation after increasing RAM, verify that your hard drive has enough free space to accommodate a larger hibernation file.
Page 146: Connecting A Modem Cable
Connecting a Modem Cable The notebook’s internal modem is connected to an analog telephone line by means of a 6-pin, RJ-11 modem cable. In some countries, a country-specific modem adapter is required. Jacks for digital PBX systems may resemble analog telephone jacks, but are not compatible with the modem.
Page 147: Using A Modem Cable
Hardware Components Using a Modem Cable Å WARNING: To avoid the risk of electrical shock, fire, or damage to the equipment, do not plug a modem or telephone cable into the RJ-45 (network) jack. To connect a modem cable: 1. Plug the modem cable into the modem jack 1 on the notebook.
Page 148: Using A Country-Specific Adapter
Using a Country-Specific Adapter Å WARNING: To avoid the risk of electrical shock, fire, or damage to the equipment, do not plug a modem or telephone cable into the RJ-45 (network) jack. Telephone jacks vary by country. To use the modem and the modem cable outside the country in which you purchased the notebook, you must obtain a country-specific modem adapter.
Page 149: Connecting A Network Cable
Hardware Components Connecting a Network Cable ✎ Your notebook may look slightly different from the illustration in this section. A network cable has an 8-pin RJ-45 connector at each end. To connect the network cable: 1. Plug the network cable into the network jack 1 on the notebook.
Page 150: Linking To An Infrared Device (Select Models Only)
Linking to An Infrared Device (Select Models Only) The notebook is IrDA compliant—4 megabits per second (Mbps) standard—and can communicate with another infrared-equipped device that is also IrDA compliant. The infrared port supports both low-speed connections of up to 115 kilobits per second (Kbps) and high-speed connections of up to 4 Mbps.
Page 151: Setting Up An Infrared Transmission
Hardware Components Setting Up an Infrared Transmission For information about using infrared software, refer to your operating system Help file. To set up infrared devices for optimal transmission: ■ Prepare the infrared ports on both devices for transmission. ■ Position the devices so that their infrared ports face one another at a distance no greater than 1 meter (3.3 feet).
Page 152: Using Standby With Infrared
Using Standby with Infrared Standby is not compatible with infrared transmission. If the notebook is in standby, an infrared transmission cannot be initiated. If standby is initiated during an infrared transmission, the transmission stops. To resume from standby, press the power/standby button.
Page 153 Hardware Components USB hubs can be connected to a USB port on the notebook or on an optional docking device (select models only), or to other USB devices. Hubs support varying numbers of USB devices and are used to increase the number of USB devices in the system. Powered hubs must be connected to external power.
Page 154: Using A Usb Device
Using a USB Device A USB device functions in the same way as a comparable non-USB device, with one exception. By default, USB devices do not function unless an operating system that supports USB is installed in the notebook. Some USB devices may require additional support software, which is usually included with the device.
Page 155: Connecting Optional External Devices
Hardware Components Connecting Optional External Devices The jacks and connectors described in this guide support standard external devices. ■ For information about which jack or port to use, refer to the documentation included with the device. ■ For information about installing or loading any software required by the device, such as drivers, refer to the documentation included with the device.
Page 156: Connecting An Optional External Multibay
To print using Mobile Printing: 1. Select File > Print from any application. 2. Select HP Mobile Printing from the list of printers. 3. Select Print. 4. Enter the printer’s IP address or network path.
Page 157: Wireless
If your notebook is equipped with one or more integrated wireless devices such as 802.11 or Bluetooth wireless devices, you have a wireless notebook. ■ An 802.11 wireless notebook can connect to wireless networks in corporate offices, your home, and public places. Wireless networks include wireless local area networks (WLANs) or “hotspots.”...
Page 158 Wireless 6–2 Hardware and Software Guide...
Page 159 In addition to the wireless button and light, your notebook has software controls that enable you to turn on, turn off, enable, and disable your wireless devices. The following table explains the software controls. Wireless Control Wireless Assistant Computer Setup controls Hardware and Software Guide Description...
Page 160: Wireless Local Area Network (Select Models Only)
Wireless Wireless Local Area Network (Select Models Only) With the 802.11 wireless device, you can access a wireless local area network (WLAN), which is composed of other computers and accessories linked by a wireless router or a wireless access point. ■...
Page 161: Corporate Wlan
There are 3 popular implementations of WLAN adapters: ■ 802.11b only ■ 802.11b/g ■ 802.11a/b/g 802.11b, the first popular WLAN standard, supports data rates of up to 11 Mbps and operates at a frequency of 2.4 GHz. 802.11g, which came later, also operates at 2.4 GHz but supports data rates of up to 54 Mbps.
Page 162: Setting Up A Wlan In Your Home
Wireless Setting Up a WLAN in Your Home To set up a WLAN and connect to the Internet in your home, you need the following equipment. The following illustration shows an example of a completed wireless network installation that is connected to the Internet.
Page 163: Using A Wlan Connection
Using a WLAN Connection To use a WLAN connection: ■ Verify that all drivers required by the 802.11 wireless device are installed and that the 802.11 wireless device is correctly configured. ✎ If you are using an integrated 802.11 wireless device, all required drivers are installed and the adapter is preconfigured and ready for use.
Page 164: Using Wireless Security Features
■ Set security on your Web browser. ■ Enable MAC address filtering on the router. For more information about WLAN security, refer to the HP Web site at http://www.hp.com/go/wireless Installing Wireless Software (Optional) Microsoft Windows XP uses its Zero Client Configuration feature to support WLAN configuration.
Page 165: Identifying A Wlan Device
Identifying a WLAN Device To install HP WLAN software for an integrated 802.11 wireless device, you need to know the name of the integrated 802.11 wireless device on your notebook. To identify an integrated 802.11 wireless device: 1. Display the names of all the 802.11 wireless devices on your notebook: a.
Page 166: Troubleshooting 802.11 Wireless Devices
Wireless The WLAN software is also available as a SoftPaq at the HP Web site. To access, download, and install the SoftPaq, use either of the following procedures: ■ Select Start > Help and Support. – or – ■ Visit the HP Web site at a.
Page 167: Bluetooth Wireless Device (Select Models Only)
Bluetooth Wireless Device (Select Models Only) A Bluetooth wireless device provides short-range wireless communications that replace the physical cable connections that traditionally link electronic devices such as ■ Network access points. ■ Computers (desktop, notebook, PDA). ■ Phones (cellular, cordless, smart phone). ■...
Page 168 Wireless ■ Dial-up networking—Connects Bluetooth devices to the Internet. ■ Bluetooth serial port—Transfers data over the Bluetooth link using a virtual COM port. ■ Hands-Free—Enables a vehicle-embedded, hands-free unit or a notebook serving as a hands-free unit to establish a wireless connection to a cellular phone and to act as the Bluetooth cellular phone audio input and output mechanism.
Page 169: Turning On, Turning Off, Enabling And Disabling The 802.11 And Bluetooth Wireless Devices
Turning On, Turning Off, Enabling and Disabling the 802.11 and Bluetooth Wireless Devices The wireless button enables and disables 802.11 and Bluetooth wireless devices in conjunction with Wireless Assistant. By default, the 802.11 and Bluetooth wireless devices and wireless light are turned on when you turn on the notebook. ✎...
Page 170 Wireless To view the state of your wireless devices, place the cursor over the Wireless Assistant icon in the notification area, or open Wireless Assistant by double-clicking the icon in the notification area. Wireless Assistant displays the status of the devices as on, off, or disabled.
Page 171: Turning On The 802.11 Wireless And Bluetooth Devices
Turning On the 802.11 Wireless and Bluetooth Devices ■ Wireless Assistant shows that both WLAN and Bluetooth are off ■ Wireless light is off ■ Wireless Assistant shows that both WLAN and Bluetooth are disabled* ■ Wireless light is off Hardware and Software Guide You want to turn on either or both devices...
Page 172 Wireless ■ Wireless Assistant shows that one device is on and the other device is off ■ Wireless light is on *If the wireless devices are not both on when you disable the devices, pressing the wireless button again returns the devices to their previous on or off state. Pressing the button does not turn on both devices.
Page 173: And Bluetooth Devices
Turning Off and Disabling the 802.11 Wireless and Bluetooth Devices ■ Wireless Assistant shows that both WLAN and Bluetooth are on ■ Wireless light is on ■ Wireless Assistant shows that both WLAN and Bluetooth are off ■ Wireless light is off ■...
Page 174: Security
Security Security Features ✎ Security solutions are designed to act as deterrents. These deterrents may not prevent a product from being mishandled or stolen. The security features provided with your notebook can protect the notebook, personal information, and data from a variety of risks. Depending on your environment, some security features may be unnecessary.
Page 175 Power-on password* ■ ProtectTools Security Manager Refer to the Manager (Select Models Only)” in this chapter for additional information. HP administrator password* DriveLock* Device security* ■ Optional smart cards An enabled smart card can store both the Windows user password and the Windows administrator password;...
Page 176: Security Preferences In Computer Setup
For more details, refer to Hardware and Software Guide Use This Security Feature HP administrator password Security cable slot (used with an optional security cable). For more information on the security cable slot, refer to the “Optional Security Cable”...
Page 177: Passwords
Call Customer Care or your authorized service partner for additional information. ■ If you forget your HP administrator password, you will not be able to access Computer Setup. ■ If you forget the DriveLock user password but know the DriveLock master password, you can remove DriveLock protection from the drive.
Page 178 Protects access to Computer Setup. Used to access the notebook during startup and when you restart the notebook. Used by the HP administrator to access drives protected by DriveLock and to remove DriveLock protection from the drive. Used by the day-to-day user to access drives protected by DriveLock at startup.
Page 179: Hp And Windows Password Guidelines
Although you can use the same text for various passwords, HP passwords and Windows passwords function independently. Even if you plan to use the same text for an HP password and a Windows password, you must set the HP password in Computer Setup and the Windows password in your operating system.
Page 180: Hp Administrator Passwords
Does not display as it is set, entered, changed, or deleted. ■ Must be set and entered with the same type of keys. For example, an HP administrator password set with keyboard number keys will not be recognized if you enter it with embedded numeric keypad number keys.
Page 181: Setting Hp Administrator Passwords
Security Setting HP Administrator Passwords An HP administrator password is set, changed, or deleted in Computer Setup. To manage the password: 1. Open Computer Setup by turning on or restarting the computer, and then pressing Based Setup” message is displayed in the lower-left corner of the screen.
Page 182: Power-On Passwords
Power-On Passwords A power-on password prevents unauthorized use of the notebook. After this password is set, it must be entered each time the notebook is turned on or restarted. A power-on password ■ Does not display as it is set, entered, changed, or deleted. ■...
Page 183: Entering Power-On Passwords
Security ❏ To change a power-on password, type the current password in the Old password field, type the new password in the New password and Verify new password fields, and then press ❏ To delete a power-on password, type the current password in the Old password field, and then press 3.
Page 184: Requiring A Power-On Password At Restart
Requiring a Power-On Password at Restart You can require that a power-on password be entered each time the notebook is restarted. Enable and disable this feature in Computer Setup: 1. Open Computer Setup by turning on or restarting the computer, and then pressing Based Setup”...
Page 185: Drivelock
Security DriveLock Ä CAUTION: If you forget both the DriveLock user password and the DriveLock master password, the hard drive is permanently locked and can no longer be used. DriveLock prevents unauthorized access to the contents of a hard drive. After DriveLock protection is applied to a drive, a password must be entered to access the drive.
Page 186: Setting Drivelock Passwords
Setting DriveLock Passwords To access the DriveLock settings in Computer Setup: 1. Shut down the notebook. If you are not sure whether the notebook is off or in hibernation, turn the notebook on by pressing the power/standby button, and then shut down the notebook through the operating system.
Page 187: Entering Drivelock Passwords
Security Entering DriveLock Passwords 1. Be sure that the hard drive is inserted into the notebook (not into an optional docking device or external MultiBay). 2. When prompted for a DriveLock password, type your user or master password (using the same kind of keys you used to set the password), and then press ✎...
Page 188: Changing Drivelock Passwords
3. Open Computer Setup by turning on or restarting the computer, and then pressing Based Setup” message is displayed in the lower-left corner of the screen. ❏ To change the language, press ❏ For navigation instructions, press 4. Use the arrow keys to select Security > Password options > Require password on restart.
Page 189 Security 6. Use the arrow keys to select the field for the password you want to change. Type your current password in the Old password field, and then type the new password in the New password field and in the Verify new password field. Then press 7.
Page 190: Removing Drivelock Protection
Removing DriveLock Protection To access the DriveLock settings in Computer Setup: 1. Shut down the notebook. If you are not sure whether the notebook is off or in hibernation, turn the notebook on by pressing the power/standby button, and then shut down the notebook through the operating system.
Page 191: Device Security
■ Display a battery pack serial number. ✎ To prevent unauthorized access to this information, you must create an HP administrator password. For instructions, refer to “Setting HP Administrator Passwords” this chapter. 7–18 while the “F10 = ROM...
Page 192: Setting System Information Options
Setting System Information Options 1. Open Computer Setup by turning on or restarting the computer, and then pressing Based Setup” message is displayed in the lower-left corner of the screen. ❏ To change the language, press ❏ For navigation instructions, press 2.
Page 193: Antivirus Software
Security Antivirus Software When you use the notebook for e-mail, network, or Internet access, you expose the notebook to computer viruses. Computer viruses can disable your operating system, applications, or utilities, or cause them to function abnormally. Antivirus software can detect most viruses, destroy them, and in most cases, repair damage they have caused.
Page 194: Firewall Software
Firewall Software When you use the notebook for e-mail, network, or Internet access, it is possible for unauthorized persons to obtain information about you, your notebook, and your data. Firewalls monitor traffic on your computer by including features such as logging and reporting, automatic alarms, and user interfaces for configuring the firewall.
Page 195 Security Under some circumstances a firewall can block access to Internet games, interfere with printer or file sharing on a network, or block authorized e-mail attachments. If you are using Windows Firewall and an application attempts an inbound connection to your notebook for the first time, a security alert will be displayed.
Page 196: Critical Security Updates For Windows Xp
Critical Security Updates for Windows XP Ä CAUTION: Because new computer viruses are being detected all the time, it is recommended that you install all critical updates as soon as you receive an alert from Microsoft. You should also run Windows Update on a monthly basis to install the latest recommended updates from Microsoft.
Page 197: Protecttools Security Manager (Select Models Only)
BIOS Configuration for ProtectTools ■ Smart Card Security for ProtectTools Depending on your notebook model, add-on modules may be preinstalled, preloaded, or downloaded from the HP Web site. Visit http://www.hp.com Credential Manager for ProtectTools Credential Manager for ProtectTools has security features that...
Page 198: Bios Configuration For Protecttools
BIOS Configuration for ProtectTools BIOS Configuration for ProtectTools provides access to BIOS security and configuration settings within the ProtectTools Security Manager application, which gives users better access to system security features that are managed by the system BIOS. With BIOS Configuration for ProtectTools, you can ■...
Page 199: Smart Card Security For Protecttools
Security Smart Card Security for ProtectTools With Smart Card Security for ProtectTools, you can ■ Access optional smart card security features. Security enhancements are supported by the optional ProtectTools Smart Card and an optional supported reader, such as a smart card reader.
Page 200: Optional Security Cable
Optional Security Cable ✎ Security solutions are designed to act as deterrents. These deterrents may not prevent a product from being mishandled or stolen. To install a security cable: 1. Loop the security cable around a secured object. 2. Insert the key 1 into the cable lock 2. 3.
Page 201: Multiboot
MultiBoot A bootable medium or network interface card (NIC) contains files that the notebook needs to start and operate properly. The MultiBoot utility, which is disabled by default, enables you to identify those devices and control the sequence in which the system attempts to boot from those devices, as it starts up your notebook.
Page 202: Default Boot Sequence
MultiBoot Default Boot Sequence By default, when more than one boot device is installed in the system, the notebook chooses the startup device by searching enabled devices and locations in a predetermined sequence. On every boot, the system looks for bootable drive A devices first.
Page 203 The following list describes the default sequence in which drive numbers are assigned. (The actual startup sequence varies by configuration.) ■ Default sequence for devices that boot as drive A: 1. Optical drive in an optional docking device (select models only) or in an external MultiBay that contains a disc that boots as drive A.
Page 204: Enabling Bootable Devices In Computer Setup
MultiBoot Enabling Bootable Devices in Computer Setup The notebook can start up from a USB device or the NIC only if that device has been enabled for inclusion in the boot sequence. To enable a device or location for inclusion in MultiBoot: 1.
Page 205: Boot Order Change Considerations
Boot Order Change Considerations Before changing the startup sequence, consider the following: ■ When the notebook restarts after the boot order has been changed, it considers only the first of each type of device (except for optical devices). For example, the notebook is connected to an optional docking device (select models only) that contains a hard drive.
Page 206: Multiboot Preferences
MultiBoot MultiBoot Preferences There are 2 ways to set MultiBoot sequences: ■ Set a new default boot sequence that the notebook uses each time it starts up. ■ Use variable boot sequences using MultiBoot Express. This feature prompts you for a startup device each time the notebook is started or restarted.
Page 207: Setting A Multiboot Express Prompt
Setting a MultiBoot Express Prompt To set the notebook to display the MultiBoot startup location menu each time the notebook is started or restarted: 1. Open Computer Setup by turning on or restarting the notebook, and then pressing Setup” message is displayed in the lower-left corner of the screen.
Page 208: Entering Multiboot Express Preferences
MultiBoot Entering MultiBoot Express Preferences When the Express Boot Menu is displayed during startup: ■ To specify a startup location from the Express Boot menu, select your preference within the allotted time, and then press enter ■ To prevent the notebook from defaulting to the current MultiBoot setting, press any key before the allotted time expires.
Page 209: Computer Setup
Using Computer Setup Computer Setup is a preinstalled, ROM-based utility that can be used even when the operating system is not working or will not load. If the operating system is working, the notebook restarts the operating system after you exit Computer Setup. ✎...
Page 210: Computer Setup Access
Computer Setup Computer Setup Access The information and settings in Computer Setup are accessed from the File, Security, Tools, and Advanced menus. 1. Open Computer Setup by turning on or restarting the notebook, and then pressing Setup” message is displayed in the lower left of the screen. ❏...
Page 211: Computer Setup Defaults
Computer Setup Defaults To return all settings in Computer Setup to the values that were set at the factory: 1. Open Computer Setup by turning on or restarting the notebook, and then pressing Setup” message is displayed in the lower-left corner of the screen.
Page 212: File Menu
Computer Setup File Menu Select System information Save to floppy Restore from floppy Restore defaults Ignore changes and exit Save changes and exit 9–4 To Do This ■ View identification information about the notebook, including the notebook serial number. ■ View specification information about the processor, cache and memory size, and system ROM.
Page 213: Security Menu
Security Menu Select Administrator password Power-On password Password options DriveLock passwords Smart card security Device security System IDs Hardware and Software Guide To Do This Enter, change, or delete an administrator password. Enter, change, or delete a power-on password. ■ Enable/disable stringent security.
Page 214: Tools Menu
Computer Setup Tools Menu Select Battery Status HDD Self Test options Memory Check Advanced Menu Select Language (or press f2) Boot options 9–6 To Do This View battery status information. Run a quick or comprehensive self test on any hard drive in the system. Run a comprehensive check on system memory.
Page 215 Select Device options Hardware and Software Guide To Do This ■ Swap the functions of the fn key and left ctrl key. ■ Enable/disable multiple standard pointing devices at startup. (To set the notebook to support only a single, usually nonstandard, pointing device at startup, select Disable.) ■...
Page 216: Client Management Solutions
Client Management Solutions Client Management Solutions provide standards-based solutions for managing client (user) desktop, workstation, and notebook computers in a networked environment. The key capabilities and features of client management are ■ Initial software image deployment. ■ Remote system software installation. ■...
Page 217: Configuration And Deployment
Using a disk cloning process to copy the contents from one hard drive to another. The deployment method you should use depends on your organization’s technology environment and processes. Visit the HP Web site at information on selecting the best deployment method for your organization. ✎...
Page 218: Client Manager Software
ROM BIOS. ✎ Additional functionality can be added when HP CMS is used with optional Altiris Solutions software (purchased separately). For more information on Client Manager, visit the HP Web site at http://www.hp.com/go/easydeploy. Hardware and Software Guide Client Management Solutions...
Page 219: Software Update And Recovery
Software Updates To stay current with the newest technology and maintain optimal performance, install the latest versions of HP software on your computer as they become available. To update HP software: 1. Identify your computer model, product category, and series or family.
Page 220: Accessing Computer Information
Software Update and Recovery Accessing Computer Information Before you access the updates for your computer, collect the following information: ■ The product category is Notebook. ■ The product family name and series number are printed on the display bezel. ■ Model information is provided on the serial number label on the bottom of the computer.
Page 221: Obtaining The Support Software Cd
CD, visit the HP Web site at Software Updates and the HP Web Site Most software on the HP Web site is packaged in compressed files called SoftPaqs. Some BIOS updates may be packaged in compressed files called ROMPaqs.
Page 222: Downloading A Bios Update
Do not insert, remove, connect, or disconnect any device, cable, or cord. To download a BIOS update: 1. Access the page on the HP Web site that provides software for your computer: ❏ Select Start > Help and Support, and then click a software update link.
Page 223: Installing A Bios Update
Installing a BIOS Update ✎ If your computer is connected to a network, it is recommended that you consult with your network administrator before installing any software updates, especially system BIOS updates. BIOS installation procedures vary. Follow any instructions that are displayed on the screen after the download is complete.
Page 224: Downloading And Installing Other Software
Software Update and Recovery Downloading and Installing Other Software To download and install software other than a BIOS update: 1. Access the page on the HP Web site that provides software for your computer: ❏ Select Start > Help and Support, and then click a software update link.
Page 225 4. When the download is complete, open Windows Explorer by selecting Start > All Programs > Accessories > Windows Explorer. 5. In the left pane of the Windows Explorer window: a. Click My Computer and then your hard drive designation. (The hard drive designation is typically Local Disk C.) b.
Page 226: System Recovery
Software Update and Recovery System Recovery The computer system recovery process provides several ways to recover optimal system functionality. For best results, attempt to recover optimal computer functionality by using the following procedures in the order described here. Safeguarding Your Data Software or devices added to the computer can cause your system to become unstable.
Page 227: Using System Restore Points
Drag the snapshot file to the appropriate location on your hard drive. For more information on configuring and using Altiris Local Recovery, visit the HP Web site at or open the software and click Help on the menu bar. Using System Restore Points...
Page 228: Creating A System Restore Point
Software Update and Recovery Creating a System Restore Point To create a system restore point: 1. Select Start > Help and Support. 2. Click System Restore. The System Restore window opens. 3. Click Create a restore point, and then click Next. 4.
Page 229: Reinstalling Applications
Reinstalling Applications Applications preinstalled or preloaded on your computer can be reinstalled by using the Recovery disc or a third-party software disc. ✎ In most cases, the applications preloaded on your computer, such as those available in the Software Setup utility, can be reinstalled from your hard drive.
Page 230: Reinstalling Applications From The Hard Drive
Software Update and Recovery Reinstalling Applications from the Hard Drive To reinstall a preloaded application or utility from your hard drive: 1. Select Start > All Programs > Software Setup, and then follow the instructions on the screen. 2. When you are prompted to select the software you want to reinstall, select or clear the appropriate check boxes.
Page 231: Repairing The Operating System
Repairing the Operating System To attempt an operating system repair without deleting your personal data, use the Operating System disc that was shipped with the computer: ✎ If your computer does not have an optical drive, you may need to connect to an optional external MultiBay. 1.
Page 232: Reinstalling The Operating System
Software Update and Recovery Reinstalling the Operating System Ä CAUTION: To protect your personal data and the software installed on the computer, back up your data before reinstalling the operating system. See the Windows online Help utility to learn more about backing up your files.
Page 233: Reinstalling Device Drivers And Other Software
8. Press system instead of repairing it. 9. Press enter 10. Press 11. Select Format the partition using the NTFS file system (Quick), and then press Ä Formatting this drive deletes all current files. 12. Press The reinstallation process begins. This process takes 1 to 2 hours to complete.
Page 234: Specifications
Operating Environment The operating environment information in the following table might be helpful if you plan to use or transport the notebook in extreme environments. Factor Temperature Operating (not writing to optical disc Operating (writing to optical disc) Nonoperating Relative humidity (noncondensing) Operating Nonoperating Maximum altitude (unpressurized)
Page 235: Rated Input Power
DC power source, it is strongly recommended that the notebook be powered only with an AC adapter or DC power cord supplied or approved by HP. The notebook is capable of accepting DC power within the...
Page 236 1394 port 1–21 6-in-1 Digital Media Slot location 1–13 supported formats 5–17 6-in-1 Digital Media Slot light 1–13 AC adapter, identifying 1–26 aircraft adapter 1–16 airport security devices 5–2 Altiris Local Recovery 11–8 altitude specifications 12–1 antennae 1–15 antivirus software 7–20 Application and Driver Recovery disc 4–9 Application and Driver Recov-...
Page 237 Index removing 2–21 storing 2–35 using 2–19 battery pack release latch 1–23 1–25 bays battery 1–23 hard drive 1–24 BIOS downloading and installing 11–4 finding version information 11–1 obtaining updates 11–1 BIOS Configuration for ProtectTools 7–25 BIOS information, displaying 3–10 7–3 Bluetooth device 6–11 Bluetooth label 1–27...
Page 238 Client Management Solutions 10–1 Client Manager software 10–3 compartments expansion memory module 1–23 1–25 primary memory module 5–20 5–26 components bottom 1–23 front 1–13 left-side 1–20 rear 1–16 right-side 1–18 top 1–2 composite video 3–9 computer model, family, type, and serial number 11–2 Computer Setup accessing 9–2 Advanced menu 9–6...
Page 239 Index avoiding standby and hibernation while using discs 5–13 boot order 8–2 caring for 5–1 IDE drive light 5–4 optical 1–18 USB 5–3 DVDs changing regional settings 4–13 creating 4–12 displaying contents 5–13 inserting 5–9 multimedia applications 4–11 playing 4–11 removing 5–9 writing to 4–12 eject buttons...
Page 240 Quick Reference 3–7 using with external keyboard 3–10 HP administrator password 7–7 HP password 7–4 HP password guidelines 7–6 HP Web site 11–3 humidity specifications 12–1 IDE drive light 1–3 IEEE 1394 port 1–21 Info Center button 1–9 infrared device, linking to 5–39...
Page 241 Index function 1–12 hotkeys 3–6 keypad 1–12 num lock scroll lock 2–11 shift Windows applications 1–12 Windows logo 1–12 labels Bluetooth 1–27 Microsoft Certificate of Authenticity 1–27 Modem Approval 1–27 Regulatory 1–27 Service Tag 1–27 wireless certification 1–27 WLAN 1–27 language, changing in Computer Setup 9–6 latches...
Page 242 5–9 optical drive button 1–18 1–19 parallel port 1–16 passwords DriveLock 7–13 forgetting 7–4 HP 7–4 HP administrator 7–7 HP guidelines 7–6 power-on 7–9 security 2–16 using 7–4 Windows 7–4 Windows guidelines 7–6 passwords, coordinating 7–6 PC Card inserting 5–15...
Page 243 Index pointing stick buttons 1–7 location 1–7 ports 1394 1–21 infrared 1–13 monitor 1–20 parallel 1–16 serial 1–18 USB 1–18 power conserving 2–33 control and light locations 2–1 schemes 2–16 setting preferences 2–14 sources 2–4 power adapter 2–4 power connector 1–16 power cord 1–26 Power Meter icon 2–15 power/standby button 1–8...
Page 244 restore points 11–9 RJ-11 (modem) jack 1–20 1–22 1–26 RJ-45 (network) jack 1–20 1–22 5–38 determining current version of 3–10 ROMPaq 11–3 screen saver 2–34 key 3–10 scroll lock scrolling regions, TouchPad 1–6 3–2 Secure Digital (SD) MemoryCard 1–13 security cable lock, connecting 7–27 security cable slot 1–16 security features 7–1...
Page 245 Index SoftPaq 11–3 support CD 11–3 System Restore 11–9 updates 11–3 updating 11–1 Sonic RecordNow! 4–13 speakers 1–13 specifications operating environment 12–1 rated input power 12–2 standby avoiding when using discs 5–13 initiating 2–11 resuming from 2–11 using with infrared 5–41 S-Video cable 4–6 S-Video-out jack 1–16 switches...
Page 246 viruses, antivirus software 7–20 volume buttons 1–9 volume, adjusting 4–5 Windows applications key 1–12 Windows firewall 7–2 Windows logo key 1–12 Windows Media Player 4–9 Windows password guidelines 7–6 WinDVD Creator Plus 4–12 WinDVD Player 4–12 wireless types of WLAN adapters 6–9 WLAN 6–8 WLAN software 6–10...
