Installing The Wine Cooler - CDA FWC861 Installation, Use And Maintenance Manual

Installing the wine
cooler
This appliance is intended to be
installed in a space between two
units.
The minimum space required is:
FWC861 – 600mm wide x 580mm deep x 1780mm high
Please note: When the product is installed, there should be a small
ventilation gap between the top of the unit and the underside of any
fitting above (6 mm or ¼").
This product should not be installed:
1. In direct sunlight.
2. Adjacent to a heat source (oven or radiator).
3. Below a hob unit.
4. Where a continuous plinth is to be used, it is necessary cut a section
out so that the ventilation slots at the front of the appliance are not
obstructed in any way (Fig. 4).
Attach the single piece lower ventilation trim to the plinth area of the
appliance.
IMPORTANT: Failure to follow the instructions regarding installation
and ventilation may affect the appliance and invalidate the warranty
supplied.
14
Fig. 4
