- Page 1 Soundweb London BLU-101 Installation Guide 5033747-B...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING FOR YOUR PROTECTION READ THE FOLLOWING: KEEP THESE INSTRUCTIONS HEED ALL WARNINGS The symbols shown above are internationally accepted symbols that FOLLOW ALL INSTRUCTIONS warn of potential hazards with electrical products. The lightning flash The apparatus shall not be exposed to dripping or splashing liquid and no object filled with liquid, with arrowpoint in an equilateral triangle means that there are dangerous such as vases, shall be placed on the apparatus. - Page 3 TO WHICH IT IS CONNECTED CAN RESULT IN FULL LINE VOLTAGE BETWEEN CHASSIS AND EARTH GROUND. SEVERE INjURY OR DEATH CAN THEN RESULT IF THE CHASSIS AND EARTH GROUND ARE TOUCHED SI- Harman Music Group MULTANEOUSLY. 8760 South Sandy Parkway...
-
Page 4: Regulatory Information
Regulatory information An example of this equipment has been tested and found to comply with the following European and international Standards for Electromagnetic Compatibility and Electrical Safety: Radiated Emissions (EU): EN55022:2006 Immunity (EU): EN55024:1998 Electrical Safety (EU): IEC60065-01 + AMD1 Electrical safety (USA): UL60065-06 Important user information... -
Page 5: Front Panel
Front panel Input/Output channel monitoring Each channel has the following LED indicators: Clip Indicates clipping in the analogue domain for each input or output channel. The LED will illuminate at +18.5dB. Signal The Signal LED will illuminate for each input or output channel when the signal reaches or exceeds the signal threshold of -20dB. - Page 6 Audio cable wiring All audio and GPIO connections to the BLU-101 are via Klippon pluggable terminal block connectors (also known as BL, Phoenix or Combicon). The BLU-101 includes 3-way female Klippon connectors for individual channels. Audio Input and Output wiring convention Soundweb products provide cable shielding ‘back from the destination’...
-
Page 7: Rear Panel
Rear panel BLU link 100-240V ~ 50/60Hz, 50W CONTROL THIS EQUIPMENT MUST BE EARTHED OUTPUTS INPUTS MANUFACTURED IN THE USA BY BSS AUDIO LOCATE RS232 ETHERNET AC Mains AC Mains input to the universal switched-mode power supply, operates over a wide range of AC input voltages from 100V to 240V, 50/60Hz. - Page 8 Automatic Gain Control (AGC) and Noise Cancellation (NC) are also provided per AEC algorithm. AGC ensures that microphone levels remain at an optimum level, and NC removes steady state noise (such as from a projector fan or air conditioning device) from the signal path.
- Page 9 OPTO Output In addition to the six standard LOGIC OUTPUTS, there is an isolated output, which fails safe (open circuit) if the unit becomes faulty. 47kOhm 10K-100kOhm linear potentiometer potentiometer unconnected ladder ladder switch switch 3 wire mode 2 wire mode +supply voltage relay...
-
Page 10: Technical Specifications
Technical specifications FRONT PANEL LED INDICATORS Signal Present, CLIP, 48V (input only) Other: Control link status and activity for Ethernet and RS-232 connections (COM); Device configuration status (STAT); Error (ERR); Power/Locate (PWR) ANALOGUE INPUTS: 12 electronically balanced on Phoenix/Combicon removable screw connectors Mic/Line Inputs: Nominal gain 0dB, electronically switchable up to +48dB, in +6dB steps... - Page 11 CONTROL PORTS: 12 inputs and 6 outputs Control Input Voltage: 0 to 4.5v Control Input Impedance: 4.7kOhms to +5V (2-wire mode) >1MOhm (3-wire mode) Logic Output Voltage: 0 or +5V unloaded Logic Output Impedance: 440 Ohm Logic Output Current: 10mA source, 60mA sink WATCHDOG OUTPUT: Phoenix/Combicon connector for failsafe control Opto Output current:...
- Page 12 BSS Audio 8760 South Sandy Parkway Sandy, Utah 84070 801-566-8800 www.bssaudio.com Printed in Malaysia...
