READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Federal regulations require ceiling fans with light kits manufactured or imported after January 1, 2009, to limit total wattage consumed by the light kit to 190W. Therefore, this fan is equipped with a wattage limiting device.
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
blade edge 3. Installation Preparation. inches To prevent personal injury and damage, ensure that 7 feet (76cm) the hanging location allows the blades a clearance of (2.13m) 7ft. (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft.
Page 5
5. Fan Assembly (with downrod). If you wish to extend the hanging length of your set screw hole fan, you must remove the hanging ball from the set screw 4in. downrod provided to use with an extended stop pin downrod (sold separately). [If you wish to use the 4in.
5. Fan Assembly (with downrod). (cont. ) With the hanging bracket secured to the outlet box and able to support the fan, you are now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging bracket and let hanging hanging bracket tab ball rest on the hanging bracket.
7. Wiring. CAUTION: Be sure outlet box is properly grounded and that a ground wire (GREEN or Bare) is present. white supply wire Make sure all electrical connections comply with ground Local Codes or Ordinances and the National (green or bare) black supply wire Electrical Code.
9. Blade Assembly. motor housing Time Saver: Washers for blade screws can be set on each blade screw prior to installing blades. Locate 15 blade attachment screws and washers in hardware pack. Hold blade arm up to blade and align holes. Insert 3 blade attachment screws (along with washers) with fingers first and then tighten screws securely with Phillips screwdriver.
10. Light Kit Assembly (Optional). (cont.) Connect WHITE wire from switch housing to switch housing WHITE wire from light kit fitter. Connect BLACK (or BLUE) wire from switch housing to black white BLACK wire from light kit fitter. Be sure that molex (or blue) molex connections snap together securely.
Return fan, shipping prepaid, to 2. Verify that reverse switch is set completely in Craftmade/Ellington. We will repair or ship you a either direction. replacement fan, and we will pay the return shipping cost.
