- Page 1 All manuals and user guides at all-guides.com HD (IR) Vandal Proof Network Dome Camera User’s Manual Version 1.1.1...
- Page 2 All manuals and user guides at all-guides.com Welcome Thank you for purchasing our network camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference!
- Page 3 All manuals and user guides at all-guides.com Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC or 24V AC in the IEC60950-1.
- Page 4 All manuals and user guides at all-guides.com Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens surface. Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean the device.
-
Page 5: Table Of Contents
All manuals and user guides at all-guides.com Table of Contents General Introduction ........................1 Overview ........................1 Features ......................... 1 Specifications ........................ 2 1.3.1 Performance ......................2 1.3.2 Factory Default Setup ................... 4 Structure ............................ 11 Dimensions ........................11 Port Description ......................11 Bidirectional talk...................... - Page 6 All manuals and user guides at all-guides.com Network Connection ....................28 Login and Main Interface ................... 28 FAQ ............................31 Appendix Toxic or Hazardous Materials or Elements ............... 32...
-
Page 7: General Introduction
All manuals and user guides at all-guides.com 1 General Introduction 1.1 Overview This series network camera integrates the traditional camera and network video technology. It adopts audio and video data collection, transmission together. It can connect to the network directly without any auxiliary device. -
Page 8: Specifications
All manuals and user guides at all-guides.com time; it may result in device damage! Log function Support PAL/NTSC Support system resource information and running status real-time display. Day/Night mode auto switch (electromagnetic ICR switch). Assistant Built-in IR light. - Page 9 All manuals and user guides at all-guides.com H.264: 56Kbps-8192Kbps. It is adjustable ＭJPEG: 128Kbps-0480Kbps. It is adjustable and bit rate is adjustable. Video Bit Rate Support customized setup. Support mirror. Video Flip Support flip function. Snapshot Max 1f/s snapshot. File extension name is JPEG. Privacy Mask Supports max 4 privacy mask zones Video Setup...
-
Page 10: Factory Default Setup
All manuals and user guides at all-guides.com 1.3.2 Factory Default Setup Please refer to the following sheet for factory default setup information. Default setup Function IPC- IPC- Item Setup Type HDB/HDBW320 HDB/HDBW31 2 Series 01 Series Brightness Contrast Saturation Gain mode Auto Gain limit Exposure mode... - Page 11 All manuals and user guides at all-guides.com Default setup Function IPC- IPC- Item Setup Type HDB/HDBW320 HDB/HDBW31 2 Series 01 Series Bit rate type Reference bit 192-1024Kb/S rate Bit rate I frame interval Snap type General snap 1080P 720P Image size （1920*1080）...
- Page 12 All manuals and user guides at all-guides.com Default setup Function IPC- IPC- Item Setup Type HDB/HDBW320 HDB/HDBW31 2 Series 01 Series TCP port 37777 UDP port 37778 HTTP port RTSP port Enable Disable PPPoE User name Password Disable ，CN99 DDNS Server type Server IP none...
- Page 13 All manuals and user guides at all-guides.com Default setup Function IPC- IPC- Item Setup Type HDB/HDBW320 HDB/HDBW31 2 Series 01 Series Enable Enable Bonjour “Device name+SN”. Server name Depends on the device. Multicast 239.255.42.42 address Multicast Port 36666 Enable Disable Server IP 0.0.0.0 Auto register...
- Page 14 All manuals and user guides at all-guides.com Default setup Function IPC- IPC- Item Setup Type HDB/HDBW320 HDB/HDBW31 2 Series 01 Series Activation Disable Address Snapshot Disable Enable Disable Relay input Alarm1 Anti-dither Sensor type Record Enable channel Record delay Relay Enable (Alarm) Alarm setup...
- Page 15 All manuals and user guides at all-guides.com Default setup Function IPC- IPC- Item Setup Type HDB/HDBW320 HDB/HDBW31 2 Series 01 Series Relay output delay Send email Disable Enable Disable Record Enable Record delay Relay (Alarm) Enable output Relay output delay Enable Disable Record...
- Page 16 All manuals and user guides at all-guides.com Default setup Function IPC- IPC- Item Setup Type HDB/HDBW320 HDB/HDBW31 2 Series 01 Series Device name Device factory SN Language English Video NTSC NTSC standard Date format Y-M-D Time format Time zone GMT+08:00 Current time Sync PC Disable...
-
Page 17: Structure
All manuals and user guides at all-guides.com 2 Structure 2.1 Dimensions You can refer to the following figures for dimension information. The Unit is mm. See Figure 2-1 and Figure 2-2. Figure 2-1 Figure 2-2 2.2 Port Description For the non-IR series product, the interface is shown as in Figure 2-3 and Figure 2-4. - Page 18 All manuals and user guides at all-guides.com Figure 2-3 Figure 2-4 For the IR motorized zoom lens series product, the interface is shown as in Figure 2-5 and Figure 2-6.
- Page 19 All manuals and user guides at all-guides.com Figure 2-5 Figure 2-6 For the IR manual zoom lens series product, the interface is shown as in Figure 2-7 and Figure 2-8.
- Page 20 All manuals and user guides at all-guides.com Figure 2-7 Figure 2-8 Please refer to the following sheet for external connection port definition information. Port Port Name Connector Function Description AC 24V power POWER Connect to AC 24V power. port DC 12V power POWER Connect to DC 24V power.
-
Page 21: Bidirectional Talk
All manuals and user guides at all-guides.com external connected cable RJ45 network Ethernet port Network cable port. port It includes alarm input/output, audio I/O port and analog output. Reset button. It is to restore factory RESET Reset button default setup. Adjust lens angle of view and AUTO definition. -
Page 22: Pc-End To The Device-End
All manuals and user guides at all-guides.com Please connect the speaker or the MIC to the audio input port of the device. Then connect the earphone to the audio output port of the PC. Login the Web and then click the Talk button to enable the bidirectional talk function. You can see the button becomes orange after you enabled the bidirectional talk function. - Page 23 All manuals and user guides at all-guides.com Figure 2-9 Please refer to the following figure for alarm input information. See Figure 2-10. Alarm input: When the input signal is idle or grounded, the device can collect the different statuses of the alarm input port.
-
Page 24: Installation
All manuals and user guides at all-guides.com 3 Installation Important Before you complete the installation and setup, do not remove the electrostatic attraction film on the transparent enclosure. Otherwise it may result in injury. After remove electrostatic attraction film, do not touch dome enclosure in case it may leave stain. - Page 25 All manuals and user guides at all-guides.com Figure 3-2 Step 1 Take the installation position map from the accessories bag and then paste it on the installation ceiling or the wall according to the monitor area. Please dig three bottom holes of the plastic expansion bolts according to the map.
- Page 26 All manuals and user guides at all-guides.com Figure 3-4 Step 5 Please refer to the Step 3 to put the driver module back to the metal hooks of the chassis. Then use the inner hex wrench to secure the two inner hex screws to the chassis. Then connect the network cable and the power terminal.
- Page 27 All manuals and user guides at all-guides.com Lock Screw A Adjust lend pan rotation angle. Figure 3-6 c). Lens tilt rotation angle. Please refer to Figure 3-7 to unfasten the lock screw B and lock screw C and adjust the tilt monitor angle to the proper position. Then fix the lock screw B and lock screw C. The tilt angle ranges from -23°...
-
Page 28: Manual Zoom Lens Focus Operation
All manuals and user guides at all-guides.com Please note Figure 3-6 and Figure 3-7 is based on the IR motorized zoom camera. For the IR manual zoom camera and non-IR series product, the lock screw position and the lens angle adjustment are the same. -
Page 29: Cable Connection
All manuals and user guides at all-guides.com Dig through here Figure 3-9 For some special user, he may need the metal protection tube to protect when he pulls through the cable from the side cable. There is PG11screw thread port when you pull through the cable from the side panel. -
Page 30: Micro Sd Card Installation
All manuals and user guides at all-guides.com Step 2 Before you go to the Step 4 in the chapter 3.2.1 installation steps, please pull through cable with the waterproof airproof plug to the device chassis via the installation hole at the bottom of the chassis and then connect the cable pins. -
Page 31: Quick Configuration Tool
All manuals and user guides at all-guides.com 4 Quick Configuration Tool 4.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 4.2 Operation Double click the “ConfigTools.exe”icon, you can see an interface is shown as in Figure 4-1. - Page 32 All manuals and user guides at all-guides.com Figure 4-2 Select the “Open Device Web” item; you can go to the corresponding web login interface. See Figure 4-3. Figure 4-3 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set.
- Page 33 All manuals and user guides at all-guides.com Figure 4-4 After you logged in, the configuration tool main interface is shown as below. See Figure 4-5. Figure 4-5 For detailed information and operation instruction of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD.
-
Page 34: Web Operation
All manuals and user guides at all-guides.com 5 Web Operation These series network camera products support the Web access and management via PC. Web includes several modules: Monitor channel preview, system configuration, alarm and etc. 5.1 Network Connection Please follow the steps listed below for network connection. ... - Page 35 All manuals and user guides at all-guides.com Figure 5-2 If it is your first time to login in, system pops up warning information to ask you whether install control webrec.cab or not after you logged in for one minute. Please click OK button, system can automatically install the control.
- Page 36 All manuals and user guides at all-guides.com Figure 5-4 Please refer to the Web Operation Manual included in the resource CD for detailed operation instruction.
-
Page 37: Faq
All manuals and user guides at all-guides.com 6 FAQ I can not boot up Please click RESET button for at least five seconds to restore the device. factory default setup. Micro card Do not set the Micro SD card as the storage media to storage the write times schedule record file. -
Page 38: Appendix Toxic Or Hazardous Materials Or Elements
All manuals and user guides at all-guides.com Appendix Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Circuit Board ○ ○ ○ ○ ○ ○ Component ○ ○ ○ ○ ○ ○ Device Case ○...
