DP586 DMR Two Way Radio
We are very grateful for your purchasing Kirisun brand DMR Two Way Radio produced by
Kirisun Communications Co., Ltd.
We believe Kirisun two-way radio, which always incorporates the latest technology, can bring
great convenience to your life and work. We also believe that the quality and function of Kirisun
two-way radio can meet your demands for reliable communication.
II
I
User Manual
DP586
DMR Two Way Radio
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP586 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kirisun DP586

Summary of Contents for Kirisun DP586

  • Page 1 Kirisun Communications Co., Ltd. We believe Kirisun two-way radio, which always incorporates the latest technology, can bring great convenience to your life and work. We also believe that the quality and function of Kirisun two-way radio can meet your demands for reliable communication.
  • Page 2 Any design and materials may not be modified, copied, extracted or translated without the authorization of Kirisun or its authorized parities. Due to the update or modification of the product, Kirisun owns the right to change the specifications of software and hardware described in this manual without further notice. Specifications and information contained in this manual are for reference only.
  • Page 3 International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 ◆ Using the designated accessories Use the antenna, battery, adapter or charger supplied or sold by Kirisun only, or otherwise it causes damage to the product. If you want to purchase or replace the accessories, please contact your local dealer or Kirisun.
  • Page 4 DP586 DMR Two Way Radio User Manual 4. Do not operate the radio, disassemble or charge the battery in the potentially flammable and explosive atmosphere (such as gas station, coal gas station, etc.). 5. Do not place the radio under the direct sunlight or near the area with heating devices.
  • Page 5 DP586 DMR Two Way Radio User Manual Do not disassemble the radio by yourself. This product can only be maintained by the professional technicians. Contact us or your local dealer for help if you want to re-develop or modify the radio.

  • Page 6: Fcc Statement

    DP586 DMR Two Way Radio User Manual FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 7 DP586 DMR Two Way Radio User Manual NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. SAR warning Output power listed is rated conducted. This device must be restricted to work-related operations only in an Occupational/Controlled RF exposure environment and must operate with a duty factor not exceeding 50%.

  • Page 8: Technical Parameters

    DP586 DMR Two Way Radio User Manual Technical Parameters PMR: Operation Frequency Range: 400 to 470MHz Rated Output Power: High Power: 4W / Low Power: 1W Modulation Type: Analog: FM / Digital: 4FSK Channel Separation: Analog: 12.5kHz Digital: 12.5kHz Bluetooth: Supported Type: Bluetooth 4.2 EDR+BLE...

  • Page 9: Disposing Of Batteries

    Please dispose of your waste product according to your national and local regulations. Contact your service provider or Kirisun for information about disposing of this product in your region of the world.
  • Page 10 DP586 DMR Two Way Radio User Manual DP586 Quick Reference Brief Introduction 1．Attaching the antenna: put the antenna into the antenna interface, and rotate the antenna clockwise to fix it. 2．Powering on: rotate the power/volume knob to power on the radio.
  • Page 11 DP586 DMR Two Way Radio User Manual...

  • Page 12: Table Of Contents

    DP586 DMR Two Way Radio User Manual Contents CAUTION ....................错误!未定义书签。 TECHNICAL PARAMETERS ...................... 7 RESTRICTIONS FREQUENCIES ARE VALID FOR THE EUROPEAN COUNTRY .. 错误!未定义书签。 RESTRICTIONS ARE VALID FOR THE EUROPEAN COUNTRY ......错误!未定义书签。 Disposing of batteries ....................... 8 错误...
  • Page 13 DP586 DMR Two Way Radio User Manual 3.1 A ................18 TTACHING ETACHING THE ATTERY 3.2 A ................19 TTACHING ETACHING THE NTENNA ................19 3.1 A TTACHING ETACHING THE 3.2 W HEN DETACHING LOOSEN THE TWO SCREWS ON THE BELT CLIP AND REMOVE THE .
  • Page 14 DP586 DMR Two Way Radio User Manual 6.3 A ..................... 28 DJUSTING THE OLUME 6.4 I ........................ 28 NITIATING A ........................... 29 6.5 R ECEIVING ....................... 29 6.6 R EPLYING TO THE FEATURES AND OPERATION ..................30 7.1 TOT ( ) .......................

  • Page 15: Unpacking And Checking

    DP586 DMR Two Way Radio User Manual Unpacking and Checking Please carefully open the box, and check if the accessories listed below are contained in the package. For any missed or damaged item, please contact your local dealer for solution.

  • Page 16: Battery Information

    DP586 DMR Two Way Radio User Manual User Manual Radio 2 Battery Information Notice The battery is not charged before delivery, so please charge the battery for your first use. If the battery is not used for a long time or the battery is used up, please charge it before use. Charge/discharge for twice or three times alternately to achieve its optimal performance.

  • Page 17: Battery Charging

    DP586 DMR Two Way Radio User Manual charging will shorten the battery life. ◆Do not put the fully-charged battery back to the charger for re-charging, or it may shorten the battery life. ◆Please try to keep the battery in an indoor environment at around 25℃. The battery may get easily spoiled after being kept in the environment below -10℃...
  • Page 18 The battery is not charged before delivery from the factory, so please charge the battery before your first use.  Kirisun KB-75A lithium-ion can be used for this radio.  If the battery which is stored for over 2 months or a new battery is charged for the first time, it should be charged repeatedly to gain full battery capacity.

  • Page 19: Attaching The Accessories

    DP586 DMR Two Way Radio User Manual low power, and when you charge it in the charger, the indicator will glow after 1-5 minutes. 3 Attaching the Accessories Attaching/Detaching the Battery ◆ Attaching the Battery (1) Slightly press the top of the belt clip as shown in ①;...

  • Page 20: Attaching/Detaching The Antenna

    DP586 DMR Two Way Radio User Manual (2) Slide the battery latch along the direction as shown in ① to bounce the battery as shown in ②. (3) Slide to take out the battery along the direction as shown in ③. If there is belt clip, slightly press the belt clip top as shown in ④...

  • Page 21: Belt Clip

    DP586 DMR Two Way Radio User Manual Align the two screws on the belt clip with the screw holes at the back of the radio. Use two 2.5x6.5 machine screws. 3.2 When detaching, loosen the two screws on the belt clip and remove the belt clip.
  • Page 22 DP586 DMR Two Way Radio User Manual...

  • Page 23: Introduction

    DP586 DMR Two Way Radio User Manual Introduction...
  • Page 24 DP586 DMR Two Way Radio User Manual Part Name Part Name Power/Volume Knob Turn it clockwise to turn on the radio. For turning radio, turn Antenna counter-clockwise until a click is heard. When the radio is on, rotate the knob to adjust the volume.

  • Page 25: Programmable Keys

    DP586 DMR Two Way Radio User Manual Programmable Keys” for further details External port Alarm Key Open the cover plate and connect the external speaker and microphone Speaker Belt Clip Voice output。 Channel Knob Battery Latch Rotate the knob to select channel 1-16.
  • Page 26 DP586 DMR Two Way Radio User Manual Short Press: press and release quickly. Long Press: press and hold for a while (press duration can be set by programming software) Programmable Application Feature None No feature High/Low Power Switch to high and low power...

  • Page 27: Led Indication

    DP586 DMR Two Way Radio User Manual Squelch Level Adjusts the signal strength required when receiving. Enable/Disable scan feature and listens to the communication Scan activities on other channels. Alert Tone on/off Enable/disable all the alert tones. Press this key to switch among different zones. The zones are Zone Selection programmed by programming software.

  • Page 28: Basic Operation

    DP586 DMR Two Way Radio User Manual Glows red Transmitting Glows green Receiving Flashes red Low battery Flashes green Channels are being scanned Flashes orange Digital call hang time and it will exit when the hang time is up Glows orange Blank channel which is not available.

  • Page 29: Powering On/Off The Radio

    DP586 DMR Two Way Radio User Manual 6.1 Powering on/off the Radio When the radio is off, rotate the power/volume knob clockwise until a click is heard to power on the radio. When the radio is on, rotate the power/volume knob counter-clockwise until a click is heard to turn off the radio.

  • Page 30: Receiving

    DP586 DMR Two Way Radio User Manual 6.5 Receiving When the radio receives RF signal on the current channel and reaches squelch start level, the green LED glows to indicate that carrier is received. When the current channel is digital channel and when it received private call, group call or all call, the radio will output the voice from the channel.

  • Page 31: Features And Operation

    DP586 DMR Two Way Radio User Manual Features and Operation 7.1 TOT (time-out-timer) TOT prevents the user from occupying the channel for too long. If the continuous transmission exceeds the duration set by dealer, the radio will stop transmitting and sound alarm. For stopping alarm, release PTT button.

  • Page 32: Initiating A Call During Scan

    DP586 DMR Two Way Radio User Manual 7.3 Initiating a Call during Scan When the radio is scanning, press PTT button and the radio will transmit and talk on the predefined channel. This channel is set by dealer. 7.4 Priority Scan When there is priority scan set in the scan list, the priority scan will be automatically enabled when the radio starts the scan feature.

  • Page 33: Emergency

    DP586 DMR Two Way Radio User Manual on digital mode. 7.6 Emergency In state of emergency, press the Emergency shortcut key to send emergency alarm. Emergency alarm consists of two parts: alarm type and alarm mode. Alarm mode is used to specify the contents sent to other members in emergency.

  • Page 34: Enabling Color Code On Digital Mode

    DP586 DMR Two Way Radio User Manual None: no alarm feature (default). Siren Only: after the radio enters the alarm state, the siren can only sound locally and the control center will not receive any alarm signals. Conventional: after the radio enters alarm state, there will be light and sound alert and it can also receive response from other members.

  • Page 35: Troubleshooting

    DP586 DMR Two Way Radio User Manual Only when both the color code and ID matches, the speaker can be turned on to receive. Range: 0~15 (16 groups of color codes) Troubleshooting Problem Cause and Solution A. The battery is used up –charge the battery or change to a new Failed to power battery;...
  • Page 36 DP586 DMR Two Way Radio User Manual A. wrong channel parameters – reset the parameters and try again; Failed to transmit B. the group identity for default contact is wrong – select a right group; or receive C. Beyond the communication scope.
  • Page 37 - 2 -...
