USE AND CARE GUIDE
MEDIA BOOKCASE
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-998-7021
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this media bookcase. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!
Advertisement
Table of Contents
Related Manuals for Home Decorators Collection SK19246E-V-1
Summary of Contents for Home Decorators Collection SK19246E-V-1
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this media bookcase. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Hardware Included ..............3 Table of Contents ............2 Safety Information ............2 Pre-assembly (continued) ..........4 Warranty ................. 2 Package Contents ..............4 3 Year Warranty ...............2 Assembly ............... 5 ... -
Page 3: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Keep children and pets away from build area. Make sure your area is large enough to unpack, sort and assemble the unit. TOOLS REQUIRED Large head Small head Phillips Phillips screwdriver screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 4: Pre-Assembly (Continued)
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Top panel Left door Left side panel Right door Right side panel Bottom panel Top adjustable shelf Back panel Top fixed panel Drawer front panel Partition Drawer left side panel Bottom fixed panel Drawer right side panel Bottom adjustable shelf... -
Page 5: Assembly
Assembly Attaching the magnet □ Attach magnet (FF) to fixed panel (G) with screw (GG) as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance. - Page 6 Assembly (continued) Attaching the partition to the Top fixed panel □ □ a) Install dowel (AA) and bolt (BB) into panel (E). c) Join partition (F) to the panel (E) with dowel (AA). □ b) Insert lock (CC) into partition (F). □...
- Page 7 Assembly (continued) Attaching the bottom fixed panel to the partition □ a) Join panel (G) to partition (F) with dowel (AA). □ b) Tighten panel (G) with screw (EE). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance.
- Page 8 Assembly (continued) Attaching the right panel □ □ a) Install dowel (AA) and bolt (BB) into panel (C). c) Join panel (C) to the assembled body with dowel (AA). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □...
- Page 9 Assembly (continued) Attaching the left panel □ □ a) Install dowel (AA) and bolt (BB) into panel (B). c) Join panel (B) to the assembled body with dowel (AA). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □...
- Page 10 Assembly (continued) Attaching the top panel □ □ a) Install dowel (AA) and bolt (BB) into panel (A). c) Join panel (A) to the assembled body with dowel (AA). □ □ b) Insert lock (CC) into panels (B) and (C). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
- Page 11 Assembly (continued) Attaching the bottom panel □ □ a) Install dowel (AA) and bolt (BB) into panel (K). c) Join panel (K) to the assembled body with dowel (AA). □ □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. b) Insert lock (CC) into panels (B) and (C).
- Page 12 Assembly (continued) Assembling the adjustable shelf □ Insert shelf supports (JJ) in desired positions and place shelves (D) and (H) on the supports.
- Page 13 Assembly (continued) Assembling the back panel □ a) Install wire plug (II) into panel (L) as shown. □ b) Tighten panel (L) to the assembled body with screws (GG) as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance.
- Page 14 Assembly (continued) Attaching the door □ a) Attach left door (I) and right door (J) to the assembled body with screw (HH) as shown. NOTE: Metal plate needs to be to the top. □ b) Attach knob (KK) to door (I) and door (J) with the bolt (LL).
- Page 15 Assembly (continued) Assembling the drawer □ a) Tighten panels (N) and (O) to panel (M) □ c) Tighten panel (P) to the assembled body with screw (EE). with screw (EE). □ b) Slide panel (Q) into the grooves on □ d) Tighten knob (KK) to panel (M) with bolt (LL).
- Page 16 Assembly (continued) Inserting the drawer □ Insert the drawer into the assembled body as shown. NOTE: Make sure the slide piece is at the front end of the glide when installing the drawer into the body. SAFETY RELEASE TAB NOTE: When removing the drawer, tip-up the safety release tab to remove the drawer from the body.
- Page 17 Assembly (continued) Finalizing the assembly □ Install the anti-tipping hardware as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance.
- Page 18 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service. 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-998-7021 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
