Arrow VD108-A Owner's Manual & Assembly Instructions

Hide thumbs Also See for VD108-A:

Owner's manual & assembly instructions (32 pages)

page of 32

/ 32
Bookmarks

Quick Links

Download this manual

Owner's Manual & Assembly Instructions

Y01

Model No.

708850107

BUILDING DIMENSIONS

*Approx.

Foundation

Size

10' x 8'

121" x 92 3/4"

3,0m x 2,3m 307cm x 236cm

All manuals and user guides at all-guides.com

VD108-A

* Size rounded off to the nearest foot

Storage Area

Sq. Ft. Cu. Ft.

470

123 1/4"

6,9m

13,3m

313cm

Exterior Dimensions

(Roof Edge to Roof Edge)

Width

Depth

Height

95 1/4"

82 1/8"

242cm

209cm

697.68618

CAUTION: SOME PARTS HAVE SHARP EDGES. CARE

MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES

TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ

SAFETY INFORMATION PROVIDED IN THIS MANUAL

BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES

WHEN HANDLING METAL PARTS.

Interior Dimensions

(Wall to Wall)

Width

Depth

Height Width Height

118 1/4"

90"

300cm

229cm

205cm 141cm 176cm

Door

Opening

80 7/8" 55 1/2" 69 1/4"

Need help?

Do you have a question about the VD108-A and is the answer not in the manual?

Questions and answers

Summary of Contents for Arrow VD108-A

Page 1 All manuals and user guides at all-guides.com Owner's Manual & Assembly Instructions Model No. VD108-A 697.68618 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ...
Page 2 A foundation is also necessary as a base in order to construct a square and level building. Anchoring and foundation materials are not included with your building. We recommend the combined use of an Arrow Floor Foundation Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct the foundation and anchoring system of your choice.
Page 3 All manuals and user guides at all-guides.com PLAN AHEAD..BX03 Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
Page 4 All manuals and user guides at all-guides.com SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building.
Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
Page 6 ATTIC KIT / WORKBENCH KIT FLOOR FOUNDATION KITS Heavy-duty galvanized steel bars that fit all 10' wide Arrow buildings. They install quickly and easily to help organize space and create more useable space as an attic or workbench.
Page 7 All manuals and user guides at all-guides.com THIS PAGE LEFT BLANK INTENTIONALLY...
Page 8 All manuals and user guides at all-guides.com THIS PAGE LEFT BLANK INTENTIONALLY...
Page 9 OPTION 1: ARROW FLOOR FRAME KIT: (Order No. FB109-A or 68385-A) Arrow has the best base for your building in this simple kit. It keeps stored items above the ground. This kit should be used with one of the following: A.
Page 10 It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia.
Page 11 (Packed with Screws) Roof Beam Bracket (4) Handle (2) (6 sheets of 40) 66183 66242 66382 Roof Trim Cap 67468 (Arrow Logo) Door Slide (4) Lower Door Guide (4) (2 right & 2 left) Peak Cap (2) 6228 65020 67293...
Page 12 All manuals and user guides at all-guides.com Parts List Assembly Part Part Quantity Check Key No. Number Description in Carton List 8934 Ramp 9367 Front Floor Frame 8936 Rear Floor Frame 9338 Right Rear Wall Angle 9366 Door Track 5287 Splice Post 9339 Left Rear Wall Angle...
Page 13 All manuals and user guides at all-guides.com Assembly by Key No. 30 10...
Page 14 All manuals and user guides at all-guides.com ● ● ● ● ● 8934 Ramp (1) ● Parts Needed For ● ● ● ● ● ● 9367 Front Floor Frame (2) Step 1 ● ● ● ● ● 8936 Rear Floor Frame (2) Floor Frame Assemblies ●...
Page 15 All manuals and user guides at all-guides.com ● ● ● ● ● 9338 Right Rear Wall Angle (1) ● Parts Needed For ● ● ● ● ● ● 9339 Left Rear Wall Angle (1) Step 2 ● ● ● ● ● 9340 Right Side Wall Angle (2) Frame Assemblies ●...
Page 16 All manuals and user guides at all-guides.com ● Parts Needed For ● ● ● ● ● ● 10470 Roof Beam (8) Step 3 Roof Beam Assemblies The roof beams join the two gables 10470 and support the roof panels. The main roof beam is made up of four pieces overlapped back to back at the cen- 10470...
Page 17 All manuals and user guides at all-guides.com ● Parts Needed For ● ● ● ● ● ● 6403 Door Track Splice (1) Step 4 ● ● ● ● ● 9366 Door Track (2) Door Track Assembly NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall.
Page 18 All manuals and user guides at all-guides.com ● ● ● ● ● Front Floor Assembly (1) ● Parts Needed For ● Step 5 ● ● ● ● ● Side Floor Assembly (2) Floor Frame ● ● ● ● ● Rear Floor Assembly (1) RIGHT REAR 9203...
Page 19 All manuals and user guides at all-guides.com ● ● ● ● ● 5288 Corner Post (4) ● Parts Needed For ● ● ● ● ● ● Door Track Assembly (1) Step 6 ● ● ● ● ● Rear Wall Angle Assembly (1) Posts/Top Frames ●...
Page 20 All manuals and user guides at all-guides.com ● Parts Needed For ● ● ● ● ● ● 5287 Splice Post (3) Step 7 ● ● ● ● ● 7311 Door Jamb (2) Splice Post/Door Jamb STEP The door jambs reinforce the door opening and provide an attractive ANGLED END OF SPLICE POST MUST...
Page 21 All manuals and user guides at all-guides.com ● Parts Needed For ● ● ● ● ● ● 9344 Siding Stud (6) Step 8 ● ● ● ● ● 9365 Front Wall Channel (2) Studs/Front Channel The studs provide a surface for at- taching the siding panels.
Page 22 All manuals and user guides at all-guides.com ● Parts Needed For ● Step 9 ● ● ● ● ● 8584 Side Siding (12) Side Siding Each screw in the wall requires a washer. Slide side siding into channels of corner and splice posts, flat edge upward, bottom edge down resting on floor frame.
Page 23 All manuals and user guides at all-guides.com ● Parts Needed For ● Step 10 ● ● ● ● ● 8736 Rear Siding (6) Rear/Front Siding ● ● ● ● ● 8737 Front Siding (6) STEP STEP Slide rear siding into channel of corner and splice posts fastening to Fasten Top Center of rear frame as shown in previous...
Page 24 All manuals and user guides at all-guides.com ● Parts Needed For ● ● ● ● ● ● 6000 Right Gable (2) Step 11 ● ● ● ● ● 6001 Left Gable (2) Gable Assemblies ● ● ● ● ● 5971 Roof Beam Bracket (4) The gables go on top of the front and rear walls to support the roof beams.
Page 25 All manuals and user guides at all-guides.com ● ● ● ● ● Left Gable Assemblies (2) ● Parts Needed For ● Step 12 ● ● ● ● ● Right Gable Assemblies (2) Gables/Braces ● ● ● ● ● 6635 Gable Brace (2) Lift and fasten a right and left gable, under angle at corner, to the rear wall angle with screws.
Page 26 All manuals and user guides at all-guides.com ● Parts Needed For ● ● ● ● ● ● Main Roof Beam (1) Step 13 ● ● ● ● ● Single Roof Beam (2) Roof Beams Spread the two halves of the main STEP roof beam and fasten the roof beam to the gable brace of the front gable.
Page 27 All manuals and user guides at all-guides.com ● Parts Needed For ● Step 14 ● ● ● ● ● 8468 Right Roof Panel (1) Right Roof Panel STEP Installing the roof panels is best done with a step ladder. Begin installing 8469 8468 roof panels at the back right corner of...
Page 28 All manuals and user guides at all-guides.com ● ● ● ● ● 8468 Right Roof Panel (1) ● ● ● ● ● 8469 Left Roof Panel (2) ● Parts Needed For ● Step 15 ● ● ● ● ● 7483 Roof Panel (2) Roof Assembly ●...
Page 29 All manuals and user guides at all-guides.com ● ● ● ● ● 8486 Ridge Cap (1) ● Parts Needed For ● ● ● ● ● ● 7483 Roof Panel (2) Step 16 ● ● ● ● ● 8486 Ridge Cap (1) Panels/Ridge Cap/Trim ●...
Page 30 All manuals and user guides at all-guides.com ● ● ● ● ● 67731 Foam Board (2) ● Parts Needed For ● ● ● ● ● ● 9934 Right Door (1) Step 17 ● ● ● ● ● 9935 Left Door (1) Door Assembly ●...
Page 31 All manuals and user guides at all-guides.com ● Parts Needed For ● ● ● ● ● ● Right Door Assembly (1) Step 18 ● ● ● ● ● Left Door Assembly (1) Door Installation & Adjustment Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the...
Page 32 All manuals and user guides at all-guides.com VD108-A 697.68618 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
