Owner's Manual & Assembly Instructions
SR01
Model No.
712760104
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
10' x 12'
121" x 143 1/4"
3,0m x 3,6m 307cm x 364cm
AR1012-B
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
115
686
123 1/4" 145 3/4"
10,7m
2
19,4m
3
313cm
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
Height
81 3/8"
370cm
207cm
VC1012-B
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Width
Depth
118 1/4" 140 1/2" 80 1/8" 55 1/2"
300cm
357cm
204cm
Door
Opening
Height Width Height
60"
141cm 152cm
Advertisement
Related Manuals for Arrow AR1012-B
Summary of Contents for Arrow AR1012-B
- Page 1 Owner's Manual & Assembly Instructions SR01 Model No. AR1012-B VC1012-B CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ 712760104 SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
- Page 2 A foundation is also necessary as a base in order to construct a square and level building. Anchoring and foundation materials are not included with your building. We recommend the combined use of an Arrow Floor Foundation Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct the foundation and anchoring system of your choice.
- Page 3 PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
- Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
- Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
- Page 6 ATTIC KIT / WORKBENCH KIT FLOOR FOUNDATION KITS Heavy-duty galvanized steel bars that fit all 10' wide Arrow buildings. They install quickly and easily to help organize space and create more useable space as an attic or workbench.
- Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 9 A. To support a plywood deck B. To be filled with sand. We recommend the combined use of 1. an ARROW FLOOR FOUNDATION KIT and 2. an ARROW ANCHORING KIT as an effective method of securing the building to the ground.
- Page 10 It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia.
- Page 11 65109 67468 66646 #8-32 Acorn Nut (4) Peak Cap (2) 66045 Washer (429) Handle (2) (Packed with Screws) (Arrow Logo) (11 sheets of 40) 66183 67545 66242 66382 Roof Trim Cap Weather Stripping (1) Door Slide (4) Lower Door Guide (4) (2 right &...
- Page 12 Parts List SR12 Parts in Carton One Assembly Part Part Quantity Check Key No. Number Description in Carton List 8576 Right Gable 8577 Left Gable 6264 Horizontal Door Brace 7743 Roof Panel 9086 Right Roof Panel 9087 Left Roof Panel 8538 Right Door 8539...
- Page 13 Assembly by Key No. SR13...
- Page 14 8934 Ramp (1) Parts Needed For 9367 Front Floor Frame (2) Step 1 8936 Rear Floor Frame (2) Floor Frame Assemblies 10392 Side Floor Frame (4) SV14 The front floor frame is made up of three pieces. The side floor frames 9367 and the rear floor frame are made up of two pieces.
- Page 15 5986 Rear Wall Angle (2) Parts Needed For 10389 Rear Wall Channel (2) Step 2 10390 Side Wall Channel (4) Frame Assemblies 10394 Side Wall Angle (4) SR15 The main frame pieces reinforce the walls. These pieces will later be in- Rear Wall Channel 10389 118 1/8"...
- Page 16 Parts Needed For Step 3 10397 Roof Beam (8) Roof Beam Assemblies SV16 The roof beams join the two gables and support the roof panels. The main roof beam is made up of four pieces 10397 overlapped back to back at the cen- ter.
- Page 17 Parts Needed For 6403 Door Track Splice (1) Step 4 Door Track Assembly 9366 Door Track (2) SO17 NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall. It is made up of three pieces. 6403 Using the door track splice, (painted), join the door track...
- Page 18 Front Floor Assembly (1) Parts Needed For Step 5 Side Floor Assembly (2) Floor Frame Rear Floor Assembly (1) SW18 RIGHT REAR 10392 STEP Place the floor frame pieces that 8936 you assembled earlier on the foun- dation. Assemble the four corners of the floor frame using two screws at each corner as shown.
- Page 19 Parts Needed For 6515 Wall Panel (2) Step 6 9373 Front Wall Panel (2) Corners 6514 Corner Panel (4) SR19 NOTE Narrow The remainder of the building assembly Side requires many hours and more than one 6514 person. Do not continue beyond this point Wide Side if you do not have enough time to com- plete the assembly today.
- Page 20 Parts Needed For Step 7 Rear Wall Channel Assembly (1) Mid Frames Side Wall Channel Assembly (2) SR20 The mid frame pieces give rigidity to the side and rear walls. Fasten the rear wall channel across the middle of the rear wall using screws.
- Page 21 Door Track Assembly (1) Parts Needed For Step 8 Rear Wall Angle Assembly (1) Top Frames Side Wall Angle Assembly (2) SR21 The top frame pieces give rigidity to the walls and provide a surface for attaching the gables which support the roof.
- Page 22 Parts Needed For Step 9 6515 Wall Panel (8) Wall Panels SR22 STEP Each wall panel has a crimped rib on one side. The crimped rib should go under the rib of the panel that follows Crimped Rib STEP Underneath Locate all of the wall panels and 6515 Detail Showing...
- Page 23 Parts Needed For Step 10 9369 Door Jamb (2) Front Channel/Door Jamb 9365 Front Wall Channel (2) SO23 The door jambs reinforce the door opening and provide an attractive 9365 trim. Follow these steps for both door jambs. Fasten the front wall channels STEP in their positions between the end of the side wall channel and the cor-...
- Page 24 Parts Needed For 8576 Right Gable (2) Step 11 8577 Left Gable (2) Gable Assemblies 6635 Roof Beam Bracket (4) SR24 The gables go on top of the front and rear walls to support the roof beams. NOTE The gables are packed nested together and might be mistaken as one piece.
- Page 25 Left Gable Assemblies (2) Parts Needed For Step 12 Right Gable Assemblies (2) Gables/Braces 9009 Gable Brace (2) SR25 Lift and fasten a right and left gable, under angle at corner, to the door track and rear wall angle with screws.
- Page 26 Parts Needed For Step 13 Roof Beam Assemblies (4) Roof Beam//Braces 9204 Roof Beam Brace (2) SR26 Wrap the weather stripping tape STEP around the two joined edges of the left and right gables. See diagram. Cut the weather stripping to length and repeat on next gable set.
- Page 27 Parts Needed For Step 14 9086 Right Roof Panel (1) Right Roof Panel SR27 Installing the roof panels is best done with a step ladder. Install the first roof panel at the back right corner of the building. Each screw and bolt in the roof requires a washer.
- Page 28 Parts Needed For 9087 Left Roof Panel (1) Step 15 7743 Roof Panel (2) Ridge Cap & Panels 6869 Ridge Cap (1) SR28 Install a left roof panel 9087 at the Screws To left rear corner of the roof. Roof Beam Cover the joint at the peak with weather stripping tape.
- Page 29 Parts Needed For 7743 Roof Panel (2) Step 16 Ridge Cap & Panels 6868 Ridge Cap (1) SR29 Install the second ridge cap 6868 overlapping the first ridge cap while installing two roof panels 7743. Hint: The bolts on the ridge cap need to be left loose to move the ridge cap to the side and overlap the ribs of the next roof panel.
- Page 30 6869 Ridge Cap (1) Parts Needed For 7743 Roof Panel (2) Step 17 9087 Left Roof Panel (1) Ridge Cap & Panels 9086 Right Roof Panel (1) SR30 Install the third ridge cap 6869 overlapping the second ridge cap while installing the remaining two roof panels 7743.
- Page 31 Parts Needed For Step 18 6015 Side Roof Trim (4) Roof Trim 6014 Side Roof Trim (2) SQ31 Attach the side roof trim pieces to the lower end of the roof panels on each side of the building using screws at each panel overlap.
- Page 32 3719 Door Handle Brace (2) 8538 Right Door (1) Parts Needed For Step 19 8539 Left Door (1) Door Assembly 6264 Horizontal Door Brace (4) 6278 Vertical Door Brace (2) SO32 The steps on this page tell how to assemble the right door. You will perform exactly the same procedures for the left door.
- Page 33 Parts Needed For Right Door Assembly (1) Step 20 Door Installation & Adjustment Left Door Assembly (1) SQ33 Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP STEP building) behind door jamb into the...
- Page 34 SOME FACTS ABOUT RUST SO34 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
