model g1163
portable dust collector
oWner's manual
Copyright © oCtoBEr, 1994 By grizzly industrial, inC., rEvisEd July, 2008 (tr)
Warning: no portion of this manual may be reproduced in any shape
or form Without the Written approval of grizzly industrial, inc.
#tv0495 printEd in taiWan

Advertisement

Table of Contents
loading

Related Manuals for Grizzly G1163

Summary of Contents for Grizzly G1163

  • Page 1 Copyright © oCtoBEr, 1994 By grizzly industrial, inC., rEvisEd July, 2008 (tr) Warning: no portion of this manual may be reproduced in any shape or form Without the Written approval of grizzly industrial, inc.

  • Page 3: Table Of Contents

    Contact info ... 2 Machine data sheet ... 3 section 1: safety ... 4 safety instructions for Machinery ... 4 additional safety for dust Collectors ... 6 section 2: circuit reQuirements ... 7 110/220v operation ... 7 section 3: setup ... 8 setup safety ...

  • Page 4: Introduction

    We are proud to offer the Model g1163 portable dust Collector. this machine is part of a growing grizzly family of fine woodworking machinery. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoyable operation and proof of grizzly’s com-...

  • Page 5: Machine Data Sheet

    Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 MODEL G1163 1 HP LIGHT DUTY DUST COLLECTOR Product Dimensions: Weight... 45 lbs. Length/Width/Height... 44 x 18 x 19-1/2 in. Foot Print (Length/Width)... 14 x 14 in.

  • Page 6: Section 1: Safety

    Collector...
  • Page 7 Collector...

  • Page 8: Additional Safety For Dust Collectors

    Collector...

  • Page 9: Section 2: Circuit Requirements

    NOTICE the model g1163 is prewired for 110v oper- ation. if you plan to operate your machine at 220v, the motor must be rewired (see page 20). full load amperage draw amp draw at 110v (prewired) ...

  • Page 10: Section 3: Setup

    Otherwise, filing a freight claim can be difficult. When you are completely satisfied with the condi- tion of your shipment, inventory the contents. g1163 portable dust Collector...

  • Page 11: Inventory

    (e.g. a nut or a washer), we will gladly replace them; or for the sake of expediency, replacements can be obtained at your local hardware store. g1163 portable dust Collector site considerations placement location Consider existing and anticipated needs, size of...

  • Page 12: Assembly

    6. Clamp ⁄ "-20 X 1 ⁄ " figure 6. attaching the collection bag. Flange Bolts ⁄ "-20 X ⁄ " to the base. g1163 portable dust Collector...

  • Page 13: Wall Mounting (Optional)

    lines.
  • Page 14 9. Ensure that each machine is continu- ously grounded to the grounding terminal in your electric service panel. ground screw Flex-hose External ground Wire internal ground Wire figure 9. Flex-hose grounded to machine. g1163 portable dust Collector...

  • Page 15: Test Run

    Make sure all tools and objects used during setup are cleared away from the machine. Connect the machine to the power source. g1163 portable dust Collector verify that the machine is operating correctly by turning the machine ON. —When operating correctly, the machine runs smoothly with little or no vibration or rubbing noises.

  • Page 16: Section 5: Operations

    -14- this entire operating your Model g1163 is simple and straightforward. Move the dust collector near the machine to a location where it will not interfere with the workpiece being processed, connect the duct, connect the ducting ground, and you are ready to begin.

  • Page 17: Section 6: Accessories

    12. rigid Metal Flex hose. g1163 portable dust Collector g4679—grounding Kit Eliminate potential hazards by dissipating static charges. Kit includes 50' of 14-gauge bare cop- per wire, electrical connectors, grounding screws, terminal ends and instructions.
  • Page 18 75 feet away, saving you trip to your collector whenever you operate a shop machine. figure 18. Model h2797 remote Control. g1163 portable dust Collector...

  • Page 19: Section 7: Maintenance

    While the Model g1163 excels at collecting the majority of wood dust produced by your machines, it is not an air filter; therefore, we strongly rec- ommend the supplemental aid of a shop air filter such as the grizzly g0572.

  • Page 20: Section 8: Service

    1. inspect/replace stripped or damaged bolts/nuts, and re-tighten with thread locking fluid. 2. tighten/replace. 3. tighten/replace mounting hardware; chock casters if mobile. 4. replace dented fan cover; replace loose/damaged fan. 5. test by rotating shaft; rotational grinding/loose shaft requires bearing replacement. g1163 portable dust Collector...

  • Page 21: Dust Collector Operation

    2. Bag clamp is loose or damaged. g1163 portable dust Collector possible solution 1. stabilize the dust collector. 2. disconnect dust collector from power, and inspect the impeller for dents, bends, loose fins. replace impeller if any damage is found.

  • Page 22: Wiring Diagram

    Wiring diagram start capacitor. 110v junction box. 220v junction box. -20- g1163 portable dust Collector...

  • Page 23: Parts Breakdown

    -21- g1163 portable dust Collector...

  • Page 24: Parts List & Labels

    (800) 523-4777 or www.grizzly.com to order new labels. -22-...

  • Page 27: Warranty And Reasons

    Warranty and reasons...
