- Page 1 DUST COLLECTOR MODEL G1028Z/G1029 INSTRUCTION MANUAL COPYRIGHT © 1991 BY GRIZZLY IMPORTS, INC.REG # TX 3170576 WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY IMPORTS, INC. REVISED FEBRUARY, 2002. PRINTED IN TAIWAN...
- Page 2 WARNING Some dust created by power sanding, sawing, grind- ing, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...
-
Page 3: Table Of Contents
1. SAFETY SAFETY INSTRUCTIONS FOR POWER TOOLS ...2 ADDITIONAL SAFETY INSTRUCTIONS FOR DUST COLLECTORS ...4 2. CIRCUIT REQUIREMENTS G1028Z ...5 G1029 ...5 GROUNDING ...6 EXTENSION CORDS ...6 3. INTRODUCTION COMMENTARY...7 UNPACKING ...8 PIECE INVENTORY ...8 CLEAN UP...9 SITE CONSIDERATIONS ...9 4. -
Page 4: Safety
G1028Z/G1029 Dust Collector VISITORS... - Page 5 14. USE RECOMMENDED ACCESSORIES. Consult the owner’s manual for recom- mended accessories. The use of improper accessories may cause risk of injury. G1028Z/G1029 Dust Collector 15. DO NOT OVER-REACH. Keep proper 16. REDUCE THE RISK OF UNINTENTION- 17. MANY WOODWORKING TOOLS CAN...
-
Page 6: Additional Safety Instructions For Dust Collectors
Additional Safety Instructions For 1. THIS DUST COLLECTOR IS TO BE USED FOR WOOD DUST COLLECTION ONLY. Do not use this dust collector to pick up liq- uids and metal scrap including, but not lim- ited to, nails and filings. Metallic debris will contact the spinning impeller and could spark. -
Page 7: Circuit Requirements
Do not attempt to rewire the motor if the diagram is missing. Contact the appropriate service center for more information. A plug is not provided with the G1028Z. It will be necessary to purchase a standard 110V plug from your local hardware store. If you are rewiring for 220V, see Figure 1 for the recommended 220V receptacle. -
Page 8: Grounding
110V or 220V. The extension cord must also con- tain a ground wire and plug pin. Always repair or replace extension cords when they become worn or damaged. G1028Z/G1029 Dust Collector T e a p g c g t r m... -
Page 9: Introduction
SECTION 3: INTRODUCTION Commentary Grizzly Industrial, Inc. is proud to offer the Model G1028Z/G1029 Dust Collector. These dust col- lectors are a part of Grizzly’s growing family of fine machinery. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoyable operation and proof of Grizzly’s commitment to customer satis-... -
Page 10: Unpacking
Unpacking The Model G1028Z/G1029 Dust Collector is shipped from the manufacturer in a carefully packed carton. If you discover the machine is damaged after you’ve signed for delivery, please call Customer Service immediately for advice. Save the containers and all packing materials for possible inspection by the carrier or its agent. -
Page 11: Clean Up
Your Model G1028Z/G1029 represents a moder- ate weight load in an average footprint. Most com- mercial or home shop floors should be sufficient to carry the weight of the Model G1028Z/G1029. If you question the strength of your floor, you can opt to reinforce it. -
Page 12: Assembly
Mount the casters to the base plate using sixteen (16) ⁄ adjust- loose clothing after they Base "-18 x ⁄ " hex bolts provided. See Figure 2. Figure 2. Mounting casters to base. G1028Z/G1029 Dust Collector... -
Page 13: Collector Body
⁄ "-18 x provided. Figure 3. Mounting collector to base. G1028Z/G1029 Dust Collector The outlet can now be attached to the main col- lector body. Insert the rubber gasket between the collector and lower outlet flange and secure using eight (8) See Figure 4. -
Page 14: Support Brackets
18 x ⁄ " bolts provided, as shown in Figure 6. Figure 6. Mounting collector to brackets. -12- G1028Z/G1029 Dust Collector T h e r e a r e t w o l o w e r c o l l e c t o r... -
Page 15: Flex Hose
Tighten each hose clamp until snug as shown in Figure 7. Figure 7. Attaching flex hose. G1028Z/G1029 Dust Collector Bags Hook the top loop of the filter bag over the support bracket as shown in Figure 8. -
Page 16: Inlet
Figure 10. Tightening steel band. -14- Inlet Press the “Y” inlet onto the inlet cover flange as shown in Figure 11. The inlet is secured to the collector body by a press-on fit. Figure 11. Installing “Y” inlet. G1028Z/G1029 Dust Collector... -
Page 17: Designing The System
On the other hand, the stationary system is more versa- tile and convenient. The Model G1028Z/G1029 is designed to be a central dust collector system. Locate the dust col- lector in an out of the way location such as a cor- ner or separate room. -
Page 18: System Grounding
However, the cost of specifically designed flexible duct can vary greatly. Grizzly offers polyethylene hose which is well suited for the removal of particulate matter, especially saw- dust, since it is durable and completely flexible. - Page 19 (Figure 12) around the blast gate without interruption to the grounding system. Copper Ground Wire Figure 12. Ground jumper wire when using plastic blast gates and metal duct. G1028Z/G1029 Dust Collector G round ScrewFlex-Hose Plastic Blast Gate Metal Duct -17-...
-
Page 20: Design Suggestions
The location of the main line duct and each branch line. The location of any obtrusion such as a joist or heating duct, that will require special duct routing. Branch Line Main Line Figure 14. Bird’s eye planning view. G1028Z/G1029 Dust Collector Dust Collector... -
Page 21: Operations
Failure to do this may result in serious personal injury. G1028Z/G1029 Dust Collector Once assembly is complete and adjustments are done to your satisfaction, you are ready to test run the machine. Turn on the power supply at the main panel. -
Page 22: Maintenance
SECTION 7: MAINTENANCE General Regular periodic maintenance on your Model G1028Z/G1029 Dust Collector will ensure its opti- mum performance. Make a habit of inspecting your machine each time you use it. Check for the following conditions and repair or replace when necessary: Loose mounting bolts. -
Page 23: Closure
Washington location using the address in the Introduction. The specifications, drawings, and photographs illustrated in this manual represent the Model G1028Z/G1029 as supplied when the manual was prepared. However, due to Grizzly’s policy of continuous improvement, changes may be made at any time with no obligation on the part of Grizzly. -
Page 24: Wire Diagram
GREEN GROUND WIRE, ARE INTERCHANGEABLE, THEREFORE COLORS ARE NOT SPECIFIED. -22- WIRE DIAGRAM 110 VOLT MOTOR WIRES BLACK YELLOW WHITE 220VOLT MOTOR WIRES YELLOW BLACK GREEN (GROUND) TO 110 VOLT POWER SUPPLY WHITE GREEN (GROUND) TO 220 VOLT POWER SUPPLY G1028Z/G1029 Dust Collector... -
Page 25: Machine Data
Impeller Size, G1028Z ...11" Impeller Size, G1029...12" Air Suction Capacity, G1028Z ...1400 C.F.M. Air Suction Capacity, G1029 ...1600 C.F.M. Static Pressure (Inches of Water), G1028Z ...9" Static Pressure (Inches of Water), G1029 ...11" Construction: Base ...Fabricated Sheet Metal with Casters Impeller Type ...Radial... -
Page 26: Parts Breakdown And Parts Lists
.5241 36.565 m80BT10.45 0 0 10.45 193.430 23.9297 l2.375236.56m65 10196 31846.4659159.03 3202.4659159.03 4 -352.9466l158.9 19875.8377156.96(m113.071 315.3068005.56m65 m914 67315.6.4657314.305c5063.434 l48831 41343.724 m613.6(m82813 35254.2 6314484.4643m109378 TD713 352613.5 m159.4643m1 532.31563.433529 1 4 1543.720.45 0 0 10.45 193.430 31999BT4791483)TjET65.01917316.296 -352.017 6211.9 159930.95 ]0 d208.587 254962 15.8.987 2549625250930.95 ]08.58 32072433 Tm8.147lS96 -0196981914.117223.8.147l5c51 15572.940.45 0 0 10.45 52.1931710.935 3726.43)Tj55.0455 -1.6402 T26.22 G1028Z/G1029 Dust Collector... - Page 27 P1029025 PACKING (G1029) P1028026 UPPER BAG SUPPORT G1027 BAG, UPPER P1028028 GASKET PK32M KEY 6 x 6 x 28 (G1028Z) PK28M KEY 7 x 7 x 29 (G1029) POWER CORD PWRCRD220S MOTOR CORD PWRCRD220L P1028035 FILTER CLAMP P1028Z038 QUICK RELEASE CLAMP ⁄...
-
Page 28: Warranty And Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance. -
Page 29: Warranty Card
