Whirlpool AWV6200 Service Manual page 37

Tacho and stator (full field-half field) ohm resistance values for the motor types are listed in the below table.
MOTOR
KODU
32003986
32004905
32006966
32007450
32004572
32008809
30027193
30023397
32002064
32003425
32000536
32000271
32000535
30027193
32008661
30023397
32004970
32004969
32009041
32004968
32009040
32008659
32008660
32005496
32007954
32007955
32008852
32008853
FİRMA
(TAM SARGI) (ohm)
ACC 3.30-/+ 7%
ACC 2.70-/+ 7%
ACC 3.00-/+ 7%
ACC 2.70-/+ 7%
ACC 1.20-/+ 7%
ACC 0.96-/+ 7%
ANAIMEP 1.87-/+7%
ANAIMEP 1.75-/+7%
ANAIMEP 2.01-/+7%
ANAIMEP 2.01-/+7%
ASKOLL (CESET) 1.01-/+7%
ASKOLL (CESET) 1.40-/+7%
ASKOLL (CESET) 1.24-/+7%
ASKOLL (CESET) 2.26-/+7%
ASKOLL (CESET) 1.90-/+7%
ASKOLL (CESET) 1.83-/+7%
ATB 1.62-/+ 7%
ATB 1.62-/+ 7%
ATB 1.62-/+ 7%
ATB 1.20-/+ 7%
ATB 1.20-/+ 7%
BROAD OCEAN 2.15-/+7%
BROAD OCEAN 2.15-/+7%
IDEA 4.60-/+7%
WELLING 2.08-/+7%
WELLING 1.59-/+7%
WELLING 2.00-/+7%
WELLING 2.15-/+7%
Resistance values for the motor types
STATOR
TAKO (ohm)
184-/+7%
184-/+7%
184-/+7%
184-/+7%
184-/+7%
184-/+7%
180-/+10%
180-/+10%
180-/+7%
180-/+7%
68.7-/+7%
68.7-/+7%
68.7-/+7%
68.7-/+7%
68.7-/+7%
68.7-/+7%
87-/+12%
87-/+12%
87-/+12%
87-/+12%
87-/+12%
66.7-/+7%
66.7-/+7%
227-/+7%
66.6-/+7%
66.6-/+7%
66.6-/+7%
66.6-/+7%
STATOR
SICAKLIK
(YARIM SARGI) (ohm)
20 °C
1.20-/+7%
20 °C
1.04-/+7%
20 °C
1.50-/+7%
20 °C
1.08-/+7%
20 °C
0.60-/+7%
20 °C
-
20 °C
-
20 °C
-
20 °C
-
20 °C
-
20 °C
-
20 °C
0.56-/+7%
20 °C
-
20 °C
-
20 °C
0.74-/+7%
20 °C
-
20 °C
-
20 °C
0.81-/+7%
20 °C
0.81-/+7%
20 °C
-
20 °C
-
20 °C
-
20 °C
-
20 °C
-
20 °C
-
20 °C
-
20 °C
-
20 °C
-
