Whirlpool AWV6200 Service Manual page 10

AUTOTEST
Time in seconds (to be adjusted)
5 10 15 20 25 30 35 40 45 50 55 60 65
Entering autotest
Changing power to 220 50Hz
Main Voltage 50 Hz
Door Lock Powered (Depends on door lock)
Motor Ramp to max spin
Time until motor is stopped (Depends on the motor stop time)
Motor Preferred Run (Direction to Right)
Motor Inverse Run (Direction to Left)
EV1 0.16 l/s(flowrate dependent of washer)
EV2 0.16 l/s(flowrate dependent of washer)
Test stopped until option 1 is pressed (led blinking)
PW+W valves up to pressure switch level (Depends on the water level)
NTC check
Heather resistance
Pump
Ready Led (Activated with motor ramp to max spin)
End Led (Activated with motor ramp to max spin)
Option 1 Led (Depends on the motor stop time)
Option 2 Led (Activated with motor preferred run)
Ntc detection : Software will detect NTC's resistance value and will check if the temperature is between 5°C < Tdetected < 40°C. If it is inside the range, heating step will be done.
If temperature value is outside the range, then it means NTC is detecting the temperature in a wrong way and heating step will be skipped.
10
