6. Selector position 6 will be "Valve 1 ON"
Valve 1 will be open for 30 seconds and then will stop.
As soon as it stops, all function LEDs will flash. This will mean machine is ready to go to next position.
So, time for selector position 6 is about 30 seconds.
Note: If user changes the selector position without waiting for 30 seconds, machine will do what is defined for the new selected position.
7. Selector position 7 will be "Valve 2 ON"
Valve 2 will be open for 30 seconds and then will stop.
As soon as it stops, all function LEDs will flash.This will mean machine is ready to go to next position.
So, time for selector position 7 is about 30 seconds.
Note: If user changes the selector position without waiting for 30 seconds, machine will do what is defined for the new selected position.
8. Selector position 8 will be "HEATER ON'
Important points:
1. Water level will be checked before heating and if level is below P0 machine will fill water with main wash valve till P1
2. Connection of NTC will be checked. If there is no connection (open or short circuit), machine will give heating failure
3. If temperature doesn't increase 2°C in 8 minutes, machine will again give heating failure.
Heating failure is: START (L1) and END (L5) LEDs will flash,
After 8 min if there is a failure machine will give failure and if there is not, all function LEDs will flash. This will mean machine is ready to go to next
position.
So, time for selector position 8 is about 8 minute.
Note: If user changes the selector position without waiting for 15 min., machine will do what is defined for the new selected position.
9. Selector position 9 will be "PUMP ON"
NTC will be checked firstly. If the measured temperature is higher than 50°C, then it takes 80 sec cooling water. It will drain until "Pzero plus Empty"
Pump will be open for "till Empty level reached + 15 sec." and then will stop.
As soon as it stops, all function LEDs will flash. This will mean machine is ready to go to next position.
So, time for selector position 9 is about 1, 5 - 2 minutes.
Note: User should wait till pump activation completely finishes in order not to affect behavior of other selector positions.
After position 9; user interface, LED and button check will begin and for these positions, behavior can be followed from the chart.
Notes:
1. For these positions there will be no time restriction (these responses of machine carry no risk of safety), user will manage this.
2. Machine will not warn or indicate that it is ready to go to next position (like "all function LEDs flash" which we will use for first 9 positions)
because there is no certain and restricted time for these responses.
User can pass to next position as soon as completing check of current position
SELECTOR SELECTOR
MODEL POSITION POSITION
10 11
Result Result
L1, L2, L3 L4 & L5
ON ON
B1
L1, L2, L3 L4 & L5
ON ON
B2
SELECTOR POSITION 12
Action Result
LED
PUSH BUTTON
START/PAUSE
START/PAUSE
ON
PUSH BUTTON
LED FUNC 1 ON
FUNC 1
PUSH BUTTON
LED FUNC 2 ON
FUNC 2
LED
PUSH BUTTON
START/PAUSE
START/PAUSE
ON
PUSH BUTTON
LED FUNC 1 ON
FUNC 1
PUSH BUTTON
LED FUNC 2 ON
FUNC 2
SELECTOR POSITION 13
Action Result
NO ACTION L4 ON
TEMPERATURE
L5 ON
SELECTOR MIN
TEMPERATURE
L4 ON
SELECTOR MAX
TEMPERATURE
L4 & L5 ON
SELECTOR MID
SELECTOR POSITION 14 SELECTOR POSITION 15
Action Result Action
NO ALL LEDS NO
ACTION FLASH ACTION
NO ALL LEDS NO
ACTION FLASH ACTION
Result
END LED ( L5 )
ON
END LED ( L5 )
ON
