Electronic Pressure Switch (Eps); Door Lock; Pump Motor - Whirlpool AWV6200 Service Manual

7.11.

Electronic Pressure Switch (EPS)

1. Remove the connector that is connected to the EPS.
2. Pull the EPS upward to remove as it is shown in the picture.
3. Remove the eps hose handcuffs and eps hose as it is shown
in the picture.
7.12.

Door Lock

1. Remove the connector that is connected to the door lock.
7.13.

Pump Motor

1. Remove pipe clip that fixes the drain hose.
2. Remove pipe clip fixing the tub outlet hose.
23
