Transmitter Layout

ZMT Transmitter

1. SMA Antenna Connector
2. OLED Display
3. Card / Power Key
4. Microphone Input Connector (3 Pin Lemo)
5. INC / Record Key
Increases the parameters of a menu item.
•
When in the home screen pressing INC with the CARD key will put the transmitter into record.
•
When in the transport control screen while not recording will cause the transmitter to playback.
•
Pressing while playing back will advance playback, multiple presses will cause playback to advance in
•
larger increments.
Press and hold while in the transport control screen will advance to the next segment.
•
Press it while in the home screen will display the group and unit code and the time left on the card.
•
6. DEC / Stop Key
Decreases the parameters of the menu items.
•
When in the home screen pressing DEC with the CARD key will stop the recording.
•
When playing back in the transport control screen will cause the transmitter to stop playback.
•
Press and hold while in the transport control screen will jump back to the previous segment.
•
Pressing it three times quickly while in the home screen will access the sub menu.
•
7. Menu / Play Key
Press it to access the next menu item.
•
Press it with the CARD key to playback a segment.
•
IC: 12755A-ZMT
