NTI Trinity Tft399 Installation And Operation Manual page 91

Tft Series
Item Part #
8 85797
8 84434
8 82650
8 84157
8 85798
8 84471
8 84470
8 85480
9 82054 (83204)
9 85462
9 82989
9 85684
10 83870
11 82774
12 82600-1
13 83883
13 85112
13 83194
14 84442
14 85377
14 84435
15 84419
15 84039
16 84424
17 84463
17 84464
17 84465
18 84454
18 85344
18 84457
18 85804
18 84460
19 84474
20 83608
21 84455
21 85345
21 84458
21 85805
21 84461
23 84423
25 84546
26 84453
26 85228
Models
Tft201
Tft60-85
Tft110
Tft155, Tft175, Tft200,
Tft250
Tft285
Tft300-399 (pre s/n 20916)
(LP)
Tft300-399 (pre s/n 20916)
(NG)
Tft340-399 (post s/n 90974)
Tft60-110, Tft155, Tft175,
Tft200, Tft250
Tft154, Tft201
Tft300-399 (pre s/n 20916)
Tft285, Tft340-399 (post s/n
90974)
Tft60-399
Tft60-399
Tft60-110, Tft155, Tft175,
Tft200, Tft250
Tft60-110, Tft155, Tft175,
Tft200, Tft250
Tft154, Tft201
Tft285-399
Tft60-110, Tft155, Tft175,
Tft200, Tft250
Tft154, Tft201
Tft285-399
Tft60-285
Tft300-399
Tft60-399
Tft60-154
Tft155-285
Tft300-399
Tft60-110
Tft154
Tft155-250
Tft285
Tft300-399
Tft60-399
Tft60-399
Tft60-110
Tft154
Tft155-250
Tft285
Tft300-399
Tft60-399
Tft60-399
Tft60-110
Tft154
Installation and Operation Instructions
Description
LP-Venturi Insert
Gas Valve Orifice 4.15mm, LP
Gas Valve Orifice 5.2mm, LP
Gas Valve Orifice 6.2mm, LP
Gas Valve Orifice 5.2mm, LP
Gas Valve Orifice 7.4mm, LP
Gas Valve Orifice 9.6 mm, NG
Gas Valve Orifice 6.75 mm, LP
Gas Valve VK8115V1341B (Valve Only)
Gas Valve, GB 055, 24VDC
Gas Valve VR8615VB 1044B
Gas Valve GB 057
Ignition Electrode, Dual (Includes P/N: 82774), gap =
3/16 to 1/4 inch
Igniter Gasket, Graphite (Ignition Electrode / Flame
Rod)
Gas Valve Regulator Vent Upgrade Kit c/w Clamp
(Includes P/N: 83134)
O-Ring, Gas Valve Inlet
O-Ring, Gas Valve Inlet
O-Ring, Gas Valve Inlet
Gas Valve Inlet Adapter, 1/2" NPT, Straight
Gas Valve Inlet Adapter, Tft154
Gas Valve Inlet Adapter, 3/4" NPT, Elbow
Sensor, Supply & Return Dual
Sensor, Supply & Return Dual
Low Water Cut Off
Pipe Coupling, Groove Joint, 1"
Pipe Coupling, Groove Joint, 1-1/4"
Pipe Coupling, Groove Joint, 1-1/2"
Supply Pipe, SS, 1"
Supply Pipe, SS 1"
Supply Pipe, SS, 1-1/4"
Supply Pipe, SS, 1-1/4"
Supply Pipe, SS 1-1/2"
Auto Air Vent, 1/2" NPT
Flue Sensor, Dual
Return Pipe, SS 1"
Return Pipe, SS 1"
Return Pipe, SS 1-1/4"
Return Pipe, SS 1-1/4"
Return Pipe, SS 1-1/2"
Receptacle, 120VAC
Sight Glass Assembly Tft-series
Heat Exchanger ASME
Heat Exchanger ASME
│
Trinity
91
