INSTALLATION MANUAL
INS09001
ATTENTION INSTALLERS:
These instructions must be
left with the customer
www.insigniarange.com
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
WARRANTY REG NO: __________________________
To claim your full 5 year warranty, register your shower within 90 days of delivery at: www.insigniarange.co.uk/
warrantyreg.aspx. Standard 12 month warranty applies if outside this time period.
Last Modified: 13/09/2017
www.insigniarange.co.uk
30 Day Technical Support:
(NOTE: This service is only available to customers from the day of delivery,
please have your supplier's details and your postcode to hand before calling)
Replacements Parts:
inside of your warranty contact:
www.insigniarange.co.uk/customerService.aspx
Spares/Replacements Parts:
outside of your warranty
contact 0844 800 3069
01908 226545
Advertisement
Related Manuals for Insignia INS09001
Summary of Contents for Insignia INS09001
- Page 1 INSTALLATION MANUAL 30 Day Technical Support: 01908 226545 INS09001 (NOTE: This service is only available to customers from the day of delivery, please have your supplier’s details and your postcode to hand before calling) Replacements Parts: inside of your warranty contact: www.insigniarange.co.uk/customerService.aspx...
-
Page 2: Table Of Contents
www.insigniarange.com Last Modified: 13/09/2017 Contents Introduction Electrical Requirements What’s In The Boxes? Screw Pack Contents Plumbing Requirements Schematics Starting The Installation Electric Box Connections Steam Generator Connections Sealing and Water Testing Control Panel Instructions Help Book Information Parts lists... - Page 3 Last Modified: 13/09/2017 Thank you for your recent purchase of an Insignia shower. Please read this booklet with great care to ensure you get the best out of your build and have a shower that will last for many years to come! Like everything, in order to obtain a first class product that will serve you well for many years, the effort and correctness put into the assembly will reflect in the quality of your finish.
- Page 4 DURING BUILD, LIKE ALL SHOWERS CORRECT SEALING IS IMPERATIVE. If you are using Insignia’s RubberGum, please ensure the product does not come in contact with your silicone as this will cause the RubberGum to fail and will not adhere as intended.
- Page 5 www.insigniarange.com Last Modified: 13/09/2017 TOTAL ELECTRICAL REQUIREMENTS Voltage Rating 220 -240AC Frequency Rating 50HZ Power Rating 2.8KW Your electrical contractor should understand ALL legal requirements of connection before undertaking any work or installation. UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF!!! Note for electrician. This product comes with 13 amp plug(s) fitted with an RCD unit. We leave it this way for you to connect this your own way due to continued additions to current regulations.
- Page 6 www.insigniarange.com Last Modified: 13/09/2017 Tool Requirements None Supplied Scissors Stanley Blade Silicone Gun Spirit Level Tape Measure Philips Screwdriver Electric Drill PREVENT INJURIES! This product may contain sharp edges. Assemble using gloves. Safety Gloves Safety Glasses Use safety glasses when handling glass or drilling. Adhesive Requirements Bacteria Resistant Sanitary Silicone - (for vertical joints) RubberGum...
- Page 7 Note: In some cases you may have more screws than needed, this is done so you have spares! VERY IMPORTANT Have you got everything? If not please contact the Insignia Support Line on 01908 226545. Remember NEVER book your tradesman until everything has arrived, been checked and is present.
-
Page 8: What's In The Boxes
www.insigniarange.com Last Modified: 13/09/2017 Whilst the next steps show you how to assemble your shower we want to make sure you have a correct build to ensure you get a trouble free shower. Therefore our advice is to follow the instructions and perform a dry run to ensure you are confident with the build and you understand fully how the unit is assembled. When we use the word “DRY RUN”... - Page 9 www.insigniarange.com Last Modified: 13/09/2017 Pressure Requirements from your house supply We recommend a bar pressure between 2.5 and 3.4 BAR. If you have a combi boiler system no problem should be experienced. If you have a gravity feed older type installation (hot water tank type usually less than 1 bar) you will almost certainly need a pump.
- Page 10 www.insigniarange.com Last Modified: 13/09/2017...
- Page 11 www.insigniarange.com Last Modified: 13/09/2017 TO START Make sure you have a clear space, remember when finished and in place you need access to check your build and able to pull the shower out for servicing or should you have the need to replace anything! Take the shower tub and remove all the protective wrapping and fit the waste.
- Page 12 www.insigniarange.com Last Modified: 13/09/2017 Step 1 Align the two back walls together, run a bead of silicone in between the panels and screw together using the ST12 screws. Apply Rubbergum under the left hand glass panel and place in position Step 2 Repeat step 1 on the right hand side of the tray...
- Page 13 (please note, if your column has a rubber seal at the bottom , take the rubber off and apply silicone inside the rubber and replace) Step 4 The next step is to attach the uprights to the top & bottom rails using the ST35 screws (wider rail with Insignia logo at the top)
- Page 14 www.insigniarange.com Last Modified: 13/09/2017 Step 5 Take the 2 flat front glass panels and lay them down gently and attach the “U” shape glass seal to the glass (non frame side) and cut off any excess. Step 6 Insert the front glass panels into the uprights as shown in the image...
- Page 15 www.insigniarange.com Last Modified: 13/09/2017 Step 7 Now using the ST20 screws, screw in position as indicated by the image. Pilot holes will be required to be made on site using the drill piece. Step 8 Now use the corner uprights and place into position on either side of the frame as indicated by the image on the right...
- Page 16 Step 10 Meet the frame to the side panels as per the hand opening of your choice ( Note: If the insignia logo is at the bottom simply peal it off and place on the top rail) Rubbergum...
- Page 17 www.insigniarange.com Last Modified: 13/09/2017 Step 11 Now using the ST20 screws and screw in position as indicated by the image. Pilot holes will be required to be made on site using the drill piece.
- Page 18 www.insigniarange.com Last Modified: 13/09/2017 Step 11 Screw down the roof to the back and side panels using the ST20 screws as well as the back walls to the shower tray using ST20 screws from the rear of the shower.
- Page 19 www.insigniarange.com Last Modified: 13/09/2017 Roof Lights (If pre-fitted bypass this step) The roof lights come packed in with your accessories and need to be inserted on site. On top of the roof there are 24 nuts, which simply need tightening by hand. Once this is done, the lights simply push onto the fitting.
- Page 20 www.insigniarange.com Last Modified: 13/09/2017 Accessory Installation Please Note Ensure all grey backing film on the rear of the glass panels are pierced through the existing glass holes with a knife to provide an efficient smooth fitting and location of the accessories. We recommend using a screwdriver on the smaller holes.
- Page 21 www.insigniarange.com Last Modified: 13/09/2017 Hand Shower Attach the chrome riser bar to the glass wall ensuring the water inlet is inserted through the lower large hole and hand tightened from the rear side. Now tighten the chrome shower holder ensuring that this will take the Monsoon Head hand shower itself without falling (please note over tightening will pre-...
- Page 22 www.insigniarange.com Last Modified: 13/09/2017 Handle Ensuring that the inner thread is protruding out from the handle far enough, place the handle on the outside of the door and secure by tightening the inner chrome knob to the protruding inner thread. Door Wheels Fit the adjustable wheels to the top and bottom of the glass doors and ensure the wheels are at their lowest position and hang on the inner curved rails with the wheels facing the outside...
- Page 23 Shower Valve Device output may differ from the image. Please refer to your outer chrome faceplate in- side your Insignia shower as a reference point. IF YOUR DIAL DOES NOT CORRESPOND TO THE APPROPRIATE DEVICE: Turn on your water to the shower and note which output the water exits from then turn off the water and swap over the relevant hose.
-
Page 24: Electric Box Connections
www.insigniarange.com Last Modified: 13/09/2017 Electric Box Connections Connect the cables below to the corresponding devices on the shower Roof Light Antenna Speaker Speaker Ozone Thermostatic probe Power Supply... -
Page 25: Steam Generator Connections
www.insigniarange.com Last Modified: 13/09/2017 Steam Generator Connections The steam generator has 3 connections. Steam Outlet: Connect the white insulated hose to the white steam pod within your shower. Make sure these are fitted in the correct position as they are only attached for transportation reasons only. - Page 26 www.insigniarange.com Last Modified: 13/09/2017 Silicone Seal (vertical joints) RubberGum (horizontal joints) TESTING FOR WATER LEAKS LEAVE THE SHOWER 24 HOURS AFTER BUILD TO ALLOW SEALANT TO CURE AND ENSURE THE SHOWER IS AWAY FROM ITS FINAL POSITION TO ALLOW REAR VIEWING Ensure all connections are tight and sealed including the waste, body jets and steam outlet (model dependent) on your shower.We also advise to run a thin bead of silicone around the control panel.
-
Page 27: Control Panel Instructions
Then simply go on your device and pair up with the shower which will be named as “INS”. please search for “Insignia Showers” on YouTube and find our “SUN While your Bluetooth device is connected, use the music function button to pause and resume your Control Panel”... - Page 28 www.insigniarange.com Last Modified: 13/09/2017 Control Panel Instructions Connecting to Bluetooth Step2 Step1 Then simply go on your device and To connect a device via pair up with the shower which should be shown as “INS”. Once this is Bluetooth, press the music complete you will hear a beep to function button twice (which signify you’re connected and ready to...
- Page 29 Once your control panel has been switched off the 03 system will automatically start and you will see “03” on your control panel. To see our tutorial videos for operating this control panel’s features, please search for “Insignia Showers” on YouTube and find our “SUN Control Panel” Playlist, or you can click here...
- Page 30 www.insigniarange.com Last Modified: 13/09/2017 Need Help? Then simply download the following "Help" advice booklet found at this link below. This contains many useful items such as is your parts warranty registered, advice on cleaning / servicing your shower cabin, fault finding and many more items. This is a MUST to read and not just "HELP". It saves time in nearly all cases, avoiding contact with ourselves as most answers are there for a ready fix! Simply visit: www.insigniarange.co.uk/help.aspx...
-
Page 31: Parts Lists
Part Description Part Code Part Description Part Code Part Description SP027 Monsoon Shower head SP300 Waste hose INS09001-7 Top & Bottom Rail INS09001-14 Curved corner post SP048 Massage jet—2 open ends SP301 White insulated pipe SP048A Massage jet—1 open, 1 closed... - Page 32 All images are registered with ImageTraker Insignia™ is a registered trademark of Maclean International Ltd All images are subject to copyright. Images may not be used in any way shape or form with out written permission from Maclean International Ltd. Images are NOT permitted...
