INSTALLATION MANUAL
INS1057.1
ATTENTION INSTALLERS:
These instructions must be
left with the customer
www.insigniarange.com
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
WARRANTY REG NO: __________________________
To claim your full 5 year warranty, register your shower within 90 days of delivery at:
www.insigniarange.co.uk/warrantyreg.aspx. Standard 12 month warranty applies if outside this time period.
Last Modified 08/10/2020
www.insigniarange.co.uk
30 Day Technical Support:
(NOTE: This service is only available to customers from the day of delivery,
please have your supplier's details and your postcode to hand before calling)
Replacements Parts:
inside of your warranty contact:
www.insigniarange.co.uk/support
Spares/Replacements Parts:
outside of your warranty
visit www.insigniaoutlet.co.uk
01908 226545
Advertisement
Table of Contents
Related Manuals for Insignia INS1057.1
Summary of Contents for Insignia INS1057.1
- Page 1 INSTALLATION MANUAL 30 Day Technical Support: 01908 226545 INS1057.1 (NOTE: This service is only available to customers from the day of delivery, please have your supplier’s details and your postcode to hand before calling) Replacements Parts: inside of your warranty contact: www.insigniarange.co.uk/support...
- Page 2 Last Modified 08/10/2020 Thank you for your recent purchase of an Insignia shower. Please read this booklet with great care to ensure you get the best out of your build and have a shower that will last for many years to come! Like everything, in order to obtain a first class product that will serve you well for many years, the effort and correctness put into the assembly will reflect in the quality of your finish.
- Page 3 www.insigniarange.com Last Modified 08/10/2020 TOTAL ELECTRICAL REQUIREMENTS Voltage Rating 220 -240AC Frequency Rating 50HZ Power Rating Your electrical contractor should understand ALL legal requirements of connection before undertaking any work or installation. UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF!!! Note for electrician. This product comes with 13 amp plug(s) fitted with an RCD unit. We leave it this way for you to connect this your own way due to continued additions to current regulations.
- Page 4 DURING BUILD, LIKE ALL SHOWERS CORRECT SEALING IS IMPERATIVE. If you are using Insignia’s RubberGum, please ensure the product does not come in contact with your silicone as this will cause the RubberGum to fail and will not adhere as intended.
-
Page 5: Table Of Contents
www.insigniarange.com Last Modified 08/10/2020 Contents Introduction Electrical Requirements What’s In The Boxes? Screw Pack Contents Plumbing Requirements Schematics Starting The Installation Steam Generator Connections Sealing and Water Testing Control Panel Instructions Spare Parts List Steam Room & Shower Safety Guide Steam Room Usage Guide How to use AMI System (2nd Gen) Bathroom Electrical Zones... -
Page 6: What's In The Boxes
www.insigniarange.com Last Modified 08/10/2020 Whilst the next steps show you how to assemble your shower we want to make sure you have a correct build to ensure you get a trouble free shower. Therefore our advice is to follow the instructions and perform a dry run to ensure you are confident with the build and you understand fully how the unit is assembled. When we use the word “DRY RUN”... - Page 7 www.insigniarange.com Last Modified 08/10/2020 Tool Requirements None Supplied Scissors Stanley Blade Silicone Gun Spirit Level Tape Measure Philips Screwdriver Electric Drill PREVENT INJURIES! This product may contain sharp edges. Assemble using gloves. Safety Gloves Safety Glasses Use safety glasses when handling glass or drilling. Adhesive Requirements Bacteria Resistant Sanitary Silicone - (for vertical joints) RubberGum...
- Page 8 Small Washers Drill Piece VERY IMPORTANT Have you got everything? If not please contact the Insignia Support Line on 01908 226545. Remember NEVER book your tradesman until everything has arrived, been checked and is present. No replacement/missing parts can be obtained free of charge during or after the build. Any claims can only be within the timescale permitted (48...
- Page 9 www.insigniarange.com Last Modified 08/10/2020 Pressure Requirements from your house supply We recommend a bar pressure between 2.5 and 3.4 BAR. If you have a combi boiler system no problem should be experienced. If you have a gravity feed older type installation (hot water tank type usually less than 1 bar) you will almost certainly need a pump.
- Page 10 www.insigniarange.com Last Modified 08/10/2020...
- Page 11 www.insigniarange.com Last Modified 08/10/2020 TO START Make sure you have a clear space, remember when finished and in place you need access to check your build and able to pull the shower out for servicing or should you have the need to replace anything! Take the shower tub and remove all the protective wrapping and fit the waste.
- Page 12 www.insigniarange.com Last Modified 08/10/2020 Step 2 Place the mirrored back panel marked “Right” to the side glass ensuring that the side glass frame at its wide point is at the rear of the shower and wide black decorative paint is at the top. Align the back panel to lip on the side glass and once you are happy with the alignment, run a bead of silicone...
- Page 13 Last Modified 08/10/2020 Step 4 Now attach the front fixed panels using ST35 screws. (wider rail with the Insignia logo at the top) Step 5 Then screw the inner uprights into the top and bottom rails using the ST25 screws. To do this you will need to use the...
- Page 14 www.insigniarange.com Last Modified 08/10/2020 Step 6 Insert the corner uprights onto the outer front fixed glass pan- els as shown in the image Step 7 Now use the ST14 screws to secure into place...
- Page 15 Rubber- along the bottom of the frame. Then screw together using the ST14 screws. Step 9 Your Insignia shower should now like this.
- Page 16 www.insigniarange.com Last Modified 08/10/2020 Step 10 Align the roof with your shower walls and the bath tub and using the ST14 screws and SW9 washers fix the back walls to the roof by screwing upwards from the rear of the shower. NOTE: If a small gap exists silicone seal later Step 11 Screw down the back walls to the bath tub using ST25 screws and SW9 washers from the rear of...
- Page 17 www.insigniarange.com Last Modified 08/10/2020 Accessory Installation Please Note Inside wall of the shower Ensure all grey backing film on the rear of the glass panels are pierced through the existing glass holes with a knife to provide an efficient smooth fitting and location of the accessories. We recommend using a screwdriver on the smaller holes.
- Page 18 www.insigniarange.com Last Modified 08/10/2020 Hand Shower Attach the chrome riser bar to the glass wall ensuring the water inlet is inserted through the lower large hole and hand tightened from the rear side. Now tighten the chrome shower holder ensuring that this will take the hand shower itself without falling (please note over tightening will prevent the holder from sliding up and down) Thermostatic Probe...
- Page 19 www.insigniarange.com Last Modified 08/10/2020 Wheels Fit the adjustable wheels to the top and bottom of the glass doors and ensure the wheels are at their lowest position and hang on the inner curved rails with the wheels facing the outside of the glass. Once all wheels are fitted and on the rails you can adjust the wheels by turning the plastic bolt clockwise in which in turn will pull the wheels towards the track ensuring a secure a tight fit.
- Page 20 www.insigniarange.com Last Modified 08/10/2020 AMI Install—Guard Version Place in middle hole first Turn Tri-Jet to tighten Use Allen key to tighten left chrome outlet Use Allen key to tighten right chrome outlet Note: Connect the 1 metre insulated hose to the back of the Tri-Jet outlet to the ‘steam out’...
- Page 21 Bath Connection Body Jets inside your Insignia shower as a reference point. IF YOUR DIAL DOES NOT CORRESPOND TO THE APPROPRIATE DEVICE: Turn on your water to the shower and note which output the water exits from then turn off the water and swap over the relevant hose.
- Page 22 www.insigniarange.com Last Modified 08/10/2020 Electric Box/Steam Generator Connections Roof Light Antenna Speaker Speaker Thermostatic Probe Power Supply...
-
Page 23: Steam Generator Connections
www.insigniarange.com Last Modified 08/10/2020 Steam Generator Connections The steam generator has 3 connections. Steam Outlet: Connect the white insulated hose to the tri-jet steam system within your shower. Make sure these are fitted in the correct position as they are only attached for transportation reasons only. - Page 24 www.insigniarange.com Last Modified 08/10/2020 Roof Lights The roof lights come packed in with your accessories and need to be inserted on site. On 1. Insert Lights top of the roof there are 24 nuts, which simply need tightening by hand. Once this is done, the lights simply push onto the fitting.
- Page 25 www.insigniarange.com Last Modified 08/10/2020 Silicone Seal (vertical joints) RubberGum (horizontal joints) TESTING FOR WATER LEAKS LEAVE THE SHOWER 24 HOURS AFTER BUILD TO ALLOW SEALANT TO CURE AND ENSURE THE SHOWER IS AWAY FROM ITS FINAL POSITION TO ALLOW REAR VIEWING Ensure all connections are tight and sealed including the waste, body jets and steam outlet (model dependent) on your shower.
-
Page 26: Control Panel Instructions
Press once to turn on the panel. Simply press again to turn it off. When powering down the 03 will automatically start and last for approximately 10 minutes. After this the screen will power off. To see our tutorial videos for operating Insignia control panel’s, please search for “Insignia Showers” on YouTube and find our “Insignia Control Panel”... - Page 27 www.insigniarange.com Last Modified 08/10/2020 Control Panel Instructions Connecting to Bluetooth Step 2 Step 1 Then simply go on your device and To connect a device via pair up with the shower which should Bluetooth, press the music be shown as “INS”. Once this is function button twice (which complete you will hear a beep to looks like a musical note) the...
- Page 28 www.insigniarange.com Last Modified 08/10/2020 Need Help? Then simply download the following "Help" advice booklet found at this link below. This contains many useful items such as is your parts warranty registered, advice on cleaning / servicing your shower cabin, fault finding and many more items. This is a MUST to read and not just "HELP". It saves time in nearly all cases, avoiding contact with ourselves as most answers are there for a ready fix! Simply visit: www.insigniarange.co.uk/help.aspx...
- Page 29 Body jet—2 open ends SP187 Drain Hose SP052 Whirlpool pump switch SP048A Body jet—1 open, 1 closed SP305 Magnetic door seals SP117 Insignia Control Panel SP236 Riser bar SP309 Rear door seals SP040 Horizontal Steam Generator SP112 Shower holder (warranty only) SP120...
-
Page 30: Steam Room & Shower Safety Guide
www.insigniarange.com Last Modified 08/10/2020 Steam Room & Shower Safety Guide Never leave children unattended in the shower or bath. Never bath children (under 12) using whirlpool function if fitted. Regulate the temperature of water before showering. Never allow children to use the steam function. This function is for ADULTS ONLY. Always be aware of the steam outlet position. -
Page 31: Steam Room Usage Guide
www.insigniarange.com Last Modified 08/10/2020 Steam Room Usage Guide To use the steam room, turn the control panel on. (1) Press the steam button (2) and your generator will be fed with water and the heating element will begin to heat the water to create steam. (You should be seeing steam from your outlet in approximately 60-90 seconds) To set the temperature you want the cabin to reach, press the function button (3) once the steam is active. -
Page 32: How To Use Ami System (2Nd Gen)
www.insigniarange.com Last Modified 08/10/2020 How to use AMI System (2nd Gen) Your platinum shower is fitted with the latest AMI system (Aromatherapy Modular Infusion) which takes your steam experience to new heights by enjoying fresh, clean, natural fragrance with the AMI Oil Diffuser Steam Guard. Perfectly designed to deliver the maximum amount of aroma in a matter of minutes. -
Page 33: Bathroom Electrical Zones
www.insigniarange.com Last Modified 08/10/2020 Bathroom Electrical Zones... - Page 34 www.insigniarange.com Last Modified 08/10/2020 There are 3 bathroom electrical zones that have been distinguished in the IEE wiring guidelines and these are: Zone 0 is the area inside a bath, basin or shower. It's characterised as 'any area within a bathroom that can hold water'. Any fitting or electrical appliance utilised inside zone 0 must be a maximum of 12 volts (SELV) and completely secured against both partial and total submersion in water (minimum of IPX7) Zone 1 is the region straight above zone 0 to the height of 2.25m from the base of the bath or shower.
-
Page 35: Weee Compliance Statement
(EEE) have to fulfil certain obligations. Under the WEEE directive Insignia is considered the producer of certain products we supply and in line with the demands of the legislation we are pleased to offer the op- portunity to return these products to us for treatment and recycling. - Page 36 www.insigniarange.com Last Modified 08/10/2020...
