Insignia INS9005 Installation Manual

Hide thumbs

Advertisement

Quick Links

INSTALLATION MANUAL
ATTENTION INSTALLERS:
These instructions must be
left with the customer
www.insigniarange.com
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
WARRANTY REG NO: __________________________
To claim your full 5 year warranty, register your shower within 90 days of delivery at: www.insigniarange.co.uk/
warrantyreg.aspx. Standard 12 month warranty applies if outside this time period.
Last Modified: 08/02/2018
www.insigniarange.co.uk
30 Day Technical Support:
(NOTE: This service is only available to customers from the day of delivery,
please have your supplier's details and your postcode to hand before calling)
Replacements Parts:
inside of your warranty contact:
www.insigniarange.co.uk/customerService.aspx
Spares/Replacements Parts:
outside of your warranty
contact 0844 800 3069
01908 226545

Advertisement

loading

Related Manuals for Insignia INS9005

Summary of Contents for Insignia INS9005

  • Page 1 www.insigniarange.com Last Modified: 08/02/2018 www.insigniarange.co.uk INSTALLATION MANUAL 30 Day Technical Support: 01908 226545 (NOTE: This service is only available to customers from the day of delivery, please have your supplier’s details and your postcode to hand before calling) Replacements Parts: inside of your warranty contact: www.insigniarange.co.uk/customerService.aspx Spares/Replacements Parts:...

  • Page 2: Table Of Contents

    www.insigniarange.com Last Modified: 08/02/2018 Contents Introduction Electrical Requirements What’s In The Boxes? Screw Pack Contents Plumbing Requirements Schematics Starting The Installation Electric Box Connections Steam Generator Connections Sealing and Water Testing Control Panel Instructions Help Book Information...
  • Page 3 Last Modified: 08/02/2018 Thank you for your recent purchase of an Insignia shower. Please read this booklet with great care to ensure you get the best out of your build and have a shower that will last for many years to come! Like everything, in order to obtain a first class product that will serve you well for many years, the effort and correctness put into the assembly will reflect in the quality of your finish.
  • Page 4 DURING BUILD, LIKE ALL SHOWERS CORRECT SEALING IS IMPERATIVE. If you are using Insignia’s RubberGum, please ensure the product does not come in contact with your silicone as this will cause the RubberGum to fail and will not adhere as intended.

  • Page 5: Electrical Requirements

    www.insigniarange.com Last Modified: 08/02/2018 TOTAL ELECTRICAL REQUIREMENTS Voltage Rating 220 -240AC Frequency Rating 50HZ Power Rating 2.8KW Your electrical contractor should understand ALL legal requirements of connection before undertaking any work or installation. UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF!!! Note for electrician. This product comes with 13 amp plug(s) fitted with an RCD unit. We leave it this way for you to connect this your own way due to continued additions to current regulations.
  • Page 6 www.insigniarange.com Last Modified: 08/02/2018 Tool Requirements None Supplied Scissors Stanley Blade Silicone Gun Spirit Level Tape Measure Philips Screwdriver Electric Drill Adhesive Requirements Bacteria Resistant Sanitary Silicone - (for vertical joints) RubberGum Plumbers Mait (for waste joints) Not Supplied Supplied Not Supplied Hardware Requirements A Steam Shower requires 7 x 1 Metre Braided Hose...

  • Page 7: What's In The Boxes

    www.insigniarange.com Last Modified: 08/02/2018 Whilst the next steps show you how to assemble your shower we want to make sure you have a correct build to ensure you get a trouble free shower. Therefore our advice is to follow the instructions and perform a dry run to ensure you are confident with the build and you understand fully how the unit is assembled. When we use the word “DRY RUN”...
  • Page 8 Note: In some cases you may have more screws than needed, this is done so you have spares! VERY IMPORTANT Have you got everything? If not please contact the Insignia Support Line on 01908 226545. Remember NEVER book your tradesman until everything has arrived, been checked and is present.
  • Page 9 www.insigniarange.com Last Modified: 08/02/2018 Pressure Requirements from your house supply We recommend a bar pressure between 2.5 and 3.4 BAR. If you have a combi boiler system no problem should be experienced. If you have a gravity feed older type installation (hot water tank type usually less than 1 bar) you will almost certainly need a pump.
  • Page 10 www.insigniarange.com Last Modified: 08/02/2018...
  • Page 11 www.insigniarange.com Last Modified: 08/02/2018 TO START Make sure you have a clear space, remember when finished and in place you need access to check your build and able to pull the shower out for servicing or should you have the need to replace anything! Take the shower tub and remove all the protective wrapping and fit the waste.
  • Page 12 www.insigniarange.com Last Modified: 08/02/2018 Step 1 Attach the left glass panel to the left column (without control panel) using the M4 Nut and Bolt. Ensure you run a bead of silicone between the 2 panels and apply Rubbergum under the bottom of both panels Step 2 Attach the large back panel to the left column using the M4 NUT AND BOLT and again...
  • Page 13 www.insigniarange.com Last Modified: 08/02/2018 Step 3 The next step is to attach the remaining column (with control panel) to back mir- rored panel using the M4 NUT AND BOLT as shown in the picture to the left and again ensure a bead of silicone is placed between the panels and Rubbergum...
  • Page 14 www.insigniarange.com Last Modified: 08/02/2018 Step 5 Attach both uprights to your top and bottom rails using the ST35 screws...
  • Page 15 www.insigniarange.com Last Modified: 08/02/2018 Step 6 With the frame now attached to the back panels, locate and fix the glass panels into place by pushing them as per the arrows in the adjacent image Making sure the edge of the glass with the rubber seal fits into the grove tightly.
  • Page 16 www.insigniarange.com Last Modified: 08/02/2018 Step 7 Place and screw the upright curves into position using the ST20 screws and SW9 washers as indicated by the images.
  • Page 17 www.insigniarange.com Last Modified: 08/02/2018 Step 8 Ensure the back panels are square and you are happy with their final position. Now meet the front frame to the side panels as per the image and screw together using the ST14 screws and SW9 washers. We recommend Rubbergum is placed under the front frame to add to the rigidity of the shower and the overall sealing.
  • Page 18 www.insigniarange.com Last Modified: 08/02/2018 Step 9 Now align the roof to the glass panel and secure into position using the ST20 screws and repeat this process to fix the glass panels to the tray as indicated by the image.
  • Page 19 www.insigniarange.com Last Modified: 08/02/2018 Accessory Installation Please Note Ensure all grey backing film on the rear of the glass panels are pierced through the existing glass holes with a knife to provide an efficient smooth fitting and location of the accessories. We recommend using a screwdriver on the smaller holes.
  • Page 20 www.insigniarange.com Last Modified: 08/02/2018 Monsoon Head Attach the grey hose from your valve to the inner black tube using PTFE tape (please note this only needs to be hand tight. Over tightening will snap/damage the inner black tube) Ozone (o3) Thermostatic Probe Unscrew the chrome pepper pot end and drop Insert the chrome sleeve into the hole situated below...
  • Page 21 www.insigniarange.com Last Modified: 08/02/2018 Wheels Fit the adjustable wheels to the top and bottom of the glass doors and ensure the wheels are at their lowest position and hang on the inner curved rails with the wheels facing the outside of the glass. Please note the push button wheels are for the bottom.
  • Page 22 Connect the hoses to the corresponding inlets on the back of the shower. We suggest using tape thread to ensure a water tight seal. Device output may differ from the image. Please refer to your outer chrome faceplate inside your Insignia shower as a reference point.
  • Page 23 www.insigniarange.com Last Modified: 08/02/2018 Connecting up the water supply The following set up is recommended for the water supply. Left Valve Right Valve Requires 2 x 15mm equal T-Valves Hot Water Cold Water Supply Supply Not Supplied...

  • Page 24: Electric Box Connections

    www.insigniarange.com Last Modified: 08/02/2018 Electric Box Connections Connect the cables below to the corresponding devices on the shower Roof Light Antenna Speaker Speaker Ozone Thermostatic probe 12V power Supply...
  • Page 25 www.insigniarange.com Last Modified: 08/02/2018 Roof Lights The roof lights come packed in with your accessories and need to be inserted on site. On top of the roof there are 23 nuts, which simply need tightening by hand. Once this is done, the lights simply push onto the fitting.
  • Page 26 www.insigniarange.com Last Modified: 08/02/2018 Roof Cover (if supplied) Due to the different coloured light settings this shower model boasts, the wiring is inevitably bigger and more noticeable on top of the shower cabin. Because of this we have a cover that simply slots over the top, secured in place around the thread of the monsoon rain shower.

  • Page 27: Steam Generator Connections

    www.insigniarange.com Last Modified: 08/02/2018 Steam Generator Connections The steam generator has 3 connections. Steam Outlet: Connect the white insulated hose to the white steam pod within your shower. Make sure these are fitted in the correct position as they are only attached for transportation reasons only.
  • Page 28 www.insigniarange.com Last Modified: 08/02/2018 Silicone Seal (vertical joints) RubberGum (horizontal joints) TESTING FOR WATER LEAKS LEAVE THE SHOWER 24 HOURS AFTER BUILD TO ALLOW SEALENT TO CURE AND ENSURE THE SHOWER IS AWAY FROM ITS FINAL POSITION TO ALLOW REAR VIEWING Ensure all connections are tight and sealed including the waste, body jets and steam outlet (model dependent) on your shower.

  • Page 29: Control Panel Instructions

    10 minutes. After this the screen will power off. To see our tutorial videos for operating this control panel’s features, please search for “Insignia Showers” on YouTube and find our “SUN Control Panel” Playlist, or you can...
  • Page 30 www.insigniarange.com Last Modified: 08/02/2018 Control Panel Instructions Connecting to Bluetooth Step 2 Step 1 Then simply go on your device and To connect a device via pair up with the shower which should be shown as “INS”. Once this is Bluetooth, press the music complete you will hear a beep to function button twice (which...
  • Page 31 www.insigniarange.com Last Modified: 08/02/2018 Need Help? Then simply download the following "Help" advice booklet found at this link below. This contains many useful items such as is your parts warranty registered, advice on cleaning / servicing your shower cabin, fault finding and many more items. This is a MUST to read and not just "HELP". It saves time in nearly all cases, avoiding contact with ourselves as most answers are there for a ready fix! Simply visit: www.insigniarange.co.uk/help.aspx...
  • Page 32 Parts List Internal Items Framework Part Code Part Description Part Code Part Description SP130 M Touch Control panel SP143 Monsoon Shower head INS9005-6 Bottom Rail SP191 Blister pack SP078 Ozone Module (for Steam INS9005-5 Top rail SP227 Microphone Hand Shower Showers)
  • Page 33 All images are registered with ImageTraker Insignia™ is a registered trademark of Maclean International Ltd All images are subject to copyright. Images may not be used in any way shape or form with out written permission from Maclean International Ltd. Images are NOT permitted...
