INSTALLATION MANUAL
INS3000
ATTENTION INSTALLERS:
These instructions must be
left with the customer
www.insigniarange.com
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
WARRANTY REG NO: __________________________
To claim your full 5 year warranty, register your shower within 90 days of delivery at: www.insigniarange.co.uk/
warrantyreg.aspx. Standard 12 month warranty applies if outside this time period.
Last Modified: 13/06/2017
www.insigniarange.co.uk
30 Day Technical Support:
(NOTE: This service is only available to customers from the day of delivery,
please have your supplier's details and your postcode to hand before calling)
Replacements Parts:
inside of your warranty contact:
www.insigniarange.co.uk/customerService.aspx
Spares/Replacements Parts:
outside of your warranty
contact 0844 800 3069
01908 226545
Advertisement
Related Manuals for Insignia INS3000
Summary of Contents for Insignia INS3000
- Page 1 INSTALLATION MANUAL 30 Day Technical Support: 01908 226545 INS3000 (NOTE: This service is only available to customers from the day of delivery, please have your supplier’s details and your postcode to hand before calling) Replacements Parts: inside of your warranty contact: www.insigniarange.co.uk/customerService.aspx...
-
Page 2: Table Of Contents
www.insigniarange.com Last Modified: 13/06/2017 Contents Introduction Electrical Requirements What’s In The Boxes? Screw Pack Contents Plumbing Requirements Schematics Starting The Installation Electric Box Connections Steam Generator Connections Sealing and Water Testing Control Panel Instructions Help Book Information Parts List... - Page 3 Last Modified: 13/06/2017 Thank you for your recent purchase of an Insignia shower. Please read this booklet with great care to ensure you get the best out of your build and have a shower that will last for many years to come! Like everything, in order to obtain a first class product that will serve you well for many years, the effort and correctness put into the assembly will reflect in the quality of your finish.
- Page 4 DURING BUILD, LIKE ALL SHOWERS CORRECT SEALING IS IMPERATIVE. If you are using Insignia’s RubberGum, please ensure the product does not come in contact with your silicone as this will cause the RubberGum to fail and will not adhere as intended.
- Page 5 www.insigniarange.com Last Modified: 13/06/2017 TOTAL ELECTRICAL REQUIREMENTS Voltage Rating 220 -240AC Frequency Rating 50HZ Power Rating 2.8KW Your electrical contractor should understand ALL legal requirements of connection before undertaking any work or installation. UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF!!! Note for electrician. This product comes with 13 amp plug(s) fitted with an RCD unit. We leave it this way for you to connect this your own way due to continued additions to current regulations.
- Page 6 www.insigniarange.com Last Modified: 13/06/2017 Tool Requirements None Supplied Scissors Stanley Blade Silicone Gun Spirit Level Tape Measure Philips Screwdriver Electric Drill Adhesive Requirements Bacteria Resistant Sanitary Silicone - (for vertical joints) RubberGum Plumbers Mait (for waste joints) Not Supplied Supplied Not Supplied Hardware Requirements A Steam Shower requires 3 x 1 Metre Braided Hose...
-
Page 7: What's In The Boxes
www.insigniarange.com Last Modified: 13/06/2017 Whilst the next steps show you how to assemble your shower we want to make sure you have a correct build to ensure you get a trouble free shower. Therefore our advice is to follow the instructions and perform a dry run to ensure you are confident with the build and you understand fully how the unit is assembled. When we use the word “DRY RUN”... - Page 8 Note: In some cases you may have more screws than needed, this is done so you have spares! VERY IMPORTANT Have you got everything? If not please contact the Insignia Support Line on 01908 226545. Remember NEVER book your tradesman until everything has arrived, been checked and is present.
- Page 9 www.insigniarange.com Last Modified: 13/06/2017 Pressure Requirements from your house supply We recommend a bar pressure between 2.5 and 3.4 BAR. If you have a combi boiler system no problem should be experienced. If you have a gravity feed older type installation (hot water tank type usually less than 1 bar) you will almost certainly need a pump.
- Page 10 Please note the ‘U’ shaped channel is meant to face inwards to allow the glass to fit correctly. (Thinner rail without Insignia logo on) PLEASE NOTE The screw head needs to bypass the OUTER hole. If this does not occur...
- Page 11 www.insigniarange.com Last Modified: 13/06/2017...
- Page 12 www.insigniarange.com Last Modified: 13/06/2017 Step 2 Push the “U Shape” glass seal onto the glass panel prior to insertion into the frames. Please ensure the thin seal is on the entrance side of the panels with the thicker to the rear side. The next step is to attach both front fixed glass panels.
- Page 13 www.insigniarange.com Last Modified: 13/06/2017 Step 4 Now lock the back glass panel to the completed front frame in the position shown in the image marked “1” Once you have met the back panel inside the front upright as per the close up image walk the panel around to the position shown in the image marked “2”...
- Page 14 www.insigniarange.com Last Modified: 13/06/2017 Step 6 Align the roof with your shower walls and using the ST25 screws fix the back walls to the roof by screwing upwards from the rear of the shower. NOTE: Please start this procedure by first screwing the ST25 screw at one of the front corners (highlighted in the image with the numbers) and then pull the roof to the opposite front corner and screw into position.
- Page 15 www.insigniarange.com Last Modified: 13/06/2017 Accessory Installation Please Note Ensure all grey backing film on the rear of the glass panels are pierced through the existing glass holes with a knife to provide an efficient smooth fitting and location of the accessories. We recommend using a screwdriver on the smaller holes.
- Page 16 www.insigniarange.com Last Modified: 13/06/2017 Hand Shower Attach the chrome riser bar to the glass wall ensuring the water inlet is inserted through the lower large hole and hand tightened from the rear side. Now tighten the chrome shower holder ensuring that this will take the hand shower itself without falling (please note over tightening will prevent the holder from sliding up and down) Thermostatic Probe...
- Page 17 Shower Valve Device output may differ from the image. Please refer to your outer chrome faceplate in- side your Insignia shower as a reference point. IF YOUR DIAL DOES NOT CORROSPOND TO THE APPROPRIATE DEVICE: Turn on your water to the shower and note which output the water exits from then turn off the water and swap over the relevant hose.
-
Page 18: Electric Box Connections
www.insigniarange.com Last Modified: 13/06/2017 Electric Box Connections Connect the cables below to the corresponding devices on the shower Roof Light Antenna Speaker Speaker Ozone Thermostatic probe 12V power Supply... - Page 19 www.insigniarange.com Last Modified: 13/06/2017 Safety precautions Never leave children unattended in the shower or bath. Never bath children (under 12) using whirlpool function if fitted. Regulate the temperature of water before showering Never allow children to use the steam function. This function is for ADULTS ONLY. Always be aware of the steam outlet pod position.
-
Page 20: Steam Generator Connections
www.insigniarange.com Last Modified: 13/06/2017 Steam Generator Connections The steam generator has 3 connections. Steam Outlet: Connect the white insulated hose to the white Tri-Jet system within your shower. Make sure these are fitted in the correct position as they are only attached for transportation reasons only. - Page 21 www.insigniarange.com Last Modified: 13/06/2017 Silicone Seal (vertical joints) RubberGum (horizontal joints) TESTING FOR WATER LEAKS LEAVE THE SHOWER 24 HOURS AFTER BUILD TO ALLOW SEALENT TO CURE AND ENSURE THE SHOWER IS AWAY FROM ITS FINAL POSITION TO ALLOW REAR VIEWING Ensure all connections are tight and sealed including the waste, body jets and steam outlet (model dependent) on your shower.
-
Page 22: Control Panel Instructions
To see our tutorial videos for operating this control panel’s features, music. (further details can be found on the next page) please search for “Insignia Showers” on YouTube and find our “SUN Control Panel” Playlist, or you can click here... - Page 23 www.insigniarange.com Last Modified: 13/06/2017 Control Panel Instructions Connecting to Bluetooth Step2 Step1 Then simply go on your device and To connect a device via pair up with the shower which should be shown as “INS”. Once this is Bluetooth, press the music complete you will hear a beep to function button twice (which signify you’re connected and ready to...
- Page 24 Once your control panel has been switched off the 03 system will automatically start and you will see “03” on your control panel. To see our tutorial videos for operating this control panel’s features, please search for “Insignia Showers” on YouTube and find our “SUN Control Panel” Playlist, or you can click here...
- Page 25 Last Modified: 13/06/2017 Need Help? If so then simply download Insignia’s free comprehensive help and troubleshooting brochure now! Simply visit: www.insigniarange.co.uk/help.aspx...
-
Page 26: Parts List
Internal Items Framework SP068 Sun control panel Part Code Part Description Part Code Part Description SP074 Monsoon Shower head SP195 Blister pack INS3000-3 Bottom Rail SP078 Ozone Module SP227 Microphone Style Hand INS3000-2 Top rail SP171 Roof Lights Shower INS3000-14... - Page 27 All images are registered with ImageTraker Insignia™ is a registered trademark of Maclean International Ltd All images are subject to copyright. Images may not be used in any way shape or form with out written permission from Maclean International Ltd. Images are NOT permitted...
