INSTALLATION MANUAL
INS0509
1500mm x 900mm
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding your
installation.
Replacements Parts:
https://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts:
https://www.insigniashowers.com/replacement-parts.html
ATTENTION INSTALLERS:
These instructions must be
left with the customer
www.insigniashowers.com
Inside of your warranty period visit:
Outside of your warranty period visit
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
WARRANTY REG NO: _______________________
To claim your full 5 year warranty, register your shower within 90 days visit:
https://www.insigniashowers.com, click support and register for your warranty
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
Last Modified:11/02/2021
1

Advertisement

loading

Related Manuals for Insignia INS0509

Summary of Contents for Insignia INS0509

  • Page 1 Last Modified:11/02/2021 INSTALLATION MANUAL INS0509 1500mm x 900mm 30 Day Technical Support: Call 01908 317512 and request technical support for aiding your installation. Replacements Parts: Inside of your warranty period visit: https://www.insigniashowers.com, click support and make a warranty claim.
  • Page 2 www.insigniashowers.com Last Modified:11/02/2021 Contents Thank you for your purchase Valve/Water Connections Tips for assembly Control Panel Connections Braided Hose QR Code/Link Steam Generator Connections Electrical/Pressure/Tool requirements Sealing your Shower Box contents Control Panel Instructions Screw Pack contents Parts List Levelling the Tray Steam Room &...
  • Page 3 Last Modified:11/02/2021 Thank you for your recent purchase of an Insignia shower. Please read this booklet with great care to ensure you get the best out of your build and have a shower that will last for many years to come! Like everything, in order to obtain a first class product that will serve you well for many years, the effort and correctness put into the assembly will reflect in the quality of your finish.
  • Page 4 TIP 4—Sealing When using Insignia’s RubberGum, please ensure the product does not come in contact with your silicone as this will cause the RubberGum to fail and will not adhere as intended. Rubbergum is immediately waterproof and will gain additional strength over time.
  • Page 5 www.insigniashowers.com Last Modified:11/02/2021...
  • Page 6 www.insigniashowers.com Last Modified:11/02/2021 Electrical Requirements Pressure/Water Requirements Tools Required Voltage Rating 220 -240AC We recommend a BAR pressure between 2.5 and 3.4 BAR. If You will require: you have a combi boiler system no problem should be Frequency Rating 50HZ •...

  • Page 7: What's In The Boxes

    www.insigniashowers.com Last Modified:11/02/2021 Whilst the next steps show you how to assemble your shower we want to make sure you have a correct build to ensure you get a trouble free shower. Therefore our advice is to follow the instructions and perform a dry run to ensure you are confident with the build and you understand fully how the unit is assembled. When we use the word “DRY RUN”...
  • Page 8 Note: In some cases you may have more screws than needed, this is done so you have spares! VERY IMPORTANT Have you got everything? If not please contact the Insignia Support Line on 01908 317512. Remember NEVER book your tradesman until everything has arrived, been checked and is present.
  • Page 9 www.insigniashowers.com Last Modified:11/02/2021 Step 1 — Level the Tray Twist to adjust...
  • Page 10 www.insigniashowers.com Last Modified:11/02/2021 Step 2 — Assemble + Insert waste pipe Check the Spigot is drilled out prior to fitting. If it isn’t ensure you drill it out!
  • Page 11 www.insigniashowers.com Last Modified:11/02/2021 Step 3 — Attach back and side walls Silicone = Red ST20 RubberGum = Blue ST20...
  • Page 12 www.insigniashowers.com Last Modified:11/02/2021 Step 4 — Attach shelves and riser rail...
  • Page 13 www.insigniashowers.com Last Modified:11/02/2021 Step 5 — Attach centre column Silicone = Red ST20 RubberGum = Blue...
  • Page 14 www.insigniashowers.com Last Modified:11/02/2021 Step 6 — Fit front frame (Birds eye view) ST35 ST35 ST25 (Internal) ST35 ST35 (Front view)
  • Page 15 www.insigniashowers.com Last Modified:11/02/2021 Step 7 — Attach corner posts ST14 (Internal View)
  • Page 16 www.insigniashowers.com Last Modified:11/02/2021 Step 8 — Seal Front Panels ST14 (Internal View) Silicone = Red RubberGum = Blue...
  • Page 17 www.insigniashowers.com Last Modified:11/02/2021 Step 9 — Fit roof and LED lights (Internal View)
  • Page 18 www.insigniashowers.com Last Modified:11/02/2021 Step 10 — Fit door handles...
  • Page 19 www.insigniashowers.com Last Modified:11/02/2021 Step 11 — Fit top door wheels Unscrew Slide cover off Door Tighten to secure wheels into door runners.
  • Page 20 www.insigniashowers.com Last Modified:11/02/2021 Step 11 (cont)— Fit bottom door wheels Slide cover off Unscrew Door...
  • Page 21 www.insigniashowers.com Last Modified:11/02/2021 AMI Install Place in middle hole first Turn Tri-Jet to tighten Use Allen key to tighten left chrome outlet Use Allen key to tighten right chrome outlet Note: Connect the 1 metre insulated hose to the back of the Tri-Jet outlet to the ‘steam out’...
  • Page 22 Last Modified:11/02/2021 Shower Valve Device output may differ from the image. Please refer to your outer chrome faceplate inside your Insignia shower as a reference point. Monsoon Head IF YOUR DIAL DOES NOT CORRESPOND TO THE APPROPRIATE DEVICE: Turn on your water to the shower and note which output the water exits from then turn off the water and swap over the relevant hose.

  • Page 23: Electric Box Connections

    www.insigniashowers.com Last Modified:11/02/2021 Electric Box Connections Connect the cables below to the corresponding devices on the shower Roof Light Antenna Speaker Speaker Ozone Thermostatic probe Power Supply...

  • Page 24: Steam Generator Connections

    Install a static water line from the shower valve (middle feed) to the steam generator. • Purchase Insignia’s WRAS approved braided hoses, however, you may require a male to male connector to connect them together to make them long enough depending on your shower model (screwfix code: 71087) •...
  • Page 25 www.insigniashowers.com Last Modified:11/02/2021 Silicone Seal (vertical joints) RubberGum (horizontal joints) TESTING FOR WATER LEAKS LEAVE THE SHOWER 24 HOURS AFTER BUILD TO ALLOW SEALANT TO CURE AND ENSURE THE SHOWER IS AWAY FROM ITS FINAL POSITION TO ALLOW REAR VIEWING Ensure all connections are tight and sealed including the waste, body jets and steam outlet (model dependent) on your shower.

  • Page 26: Control Panel Instructions

    Press once to turn on the panel. Simply press again to turn it off. When powering down the 03 will automatically start and last for approximately 10 minutes. After this the screen will power off. To see our tutorial videos for operating Insignia control panel’s, please search for “Insignia Showers” on YouTube and find our “Insignia Control Panel”...
  • Page 27 www.insigniashowers.com Last Modified:11/02/2021 Control Panel Instructions Connecting to Bluetooth Step 2 Step 1 Then simply go on your device and To connect a device via pair up with the shower which should Bluetooth, press the music be shown as “INS”. Once this is function button twice (which complete you will hear a beep to looks like a musical note) the...
  • Page 28 Internal Items Part Code Part Description Part Code Part Description Part Code Part Description SP074 Monsoon Shower head SP117 Insignia Control Panel SP300 Waste hose SP078 Ozone Module SP227 Microphone Style Hand SP301 White insulated thermo SP048 Body jet—2 open ends...
  • Page 29 www.insigniashowers.com Last Modified:11/02/2021 Steam Room & Shower Safety Guide Never leave children unattended in the shower or bath. Never bath children (under 12) using whirlpool function if fitted. Regulate the temperature of water before showering. Never allow children to use the steam function. This function is for ADULTS ONLY. Always be aware of the steam outlet position.
  • Page 30 www.insigniashowers.com Last Modified:11/02/2021 Steam Room Usage Guide To use the steam room, turn the control panel on. (1) Press the steam button (2) and your generator will be fed with water and the heating element will begin to heat the water to create steam. (You should be seeing steam from your outlet in approximately 60-90 seconds) To set the temperature you want the cabin to reach, press the function button (3) once the steam is active.
  • Page 31 www.insigniashowers.com Last Modified:11/02/2021 How to use AMI System (2nd Gen) Your platinum shower is fitted with the latest AMI system (Aromatherapy Modular Infusion) which takes your steam experience to new heights by enjoying fresh, clean, natural fragrance with the AMI Oil Diffuser Steam Guard. Perfectly designed to deliver the maximum amount of aroma in a matter of minutes.
  • Page 32 www.insigniashowers.com Last Modified:11/02/2021 Bathroom Electrical Zones...
  • Page 33 www.insigniashowers.com Last Modified:11/02/2021 There are 3 bathroom electrical zones that have been distinguished in the IEE wiring guidelines and these are: Zone 0 is the area inside a bath, basin or shower. It's characterised as 'any area within a bathroom that can hold water'. Any fitting or electrical appliance utilised inside zone 0 must be a maximum of 12 volts (SELV) and completely secured against both partial and total submersion in water (minimum of IPX7) Zone 1 is the region straight above zone 0 to the height of 2.25m from the base of the bath or shower.
  • Page 34 (EEE) have to fulfil certain obligations. Under the WEEE directive Insignia is considered the producer of certain products we supply and in line with the demands of the legislation we are pleased to offer the op- portunity to return these products to us for treatment and recycling.
  • Page 35 www.insigniashowers.com Last Modified:11/02/2021...
