- Page 1 INSTRUCTION MANUAL F05 / 49616 PORTABLE HYDRAULIC POWER UNIT Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 999 3165.6 REV 1 © 1999 Greenlee Textron 12/99...
-
Page 2: Table Of Contents
Exploded View ... 12–13 Parts List ... 14–15 Description The Fairmont F05 Portable Hydraulic Power Unit is a lightweight power source intended for use with open- center hydraulic tools. The F05 provides a maximum flow of 17 liters per minute (4.5 gallons per minute) and a maximum pressure of 104.5 Bar (1500 psi). -
Page 3: Important Safety Information
• Do not fill fuel tank near an open flame, sparks, or when smoking. Failure to observe this warning will result in severe injury or death. Greenlee Textron / Subsidiary of Textron Inc. Do not run power unit engine in a confined area. Engine exhaust fumes are toxic. -
Page 4: Important Safety Information
Nearby personnel can be injured by flying parts in the event of a tool malfunction. Greenlee Textron / Subsidiary of Textron Inc. Use appropriate lifting equipment. Make sure all components used to lift this power unit are rated for 90 kg (200 lbs) and are securely attached to the frame of the power unit. -
Page 5: Identification
F05 Portable Hydraulic Power Unit Identification Parts of the F05 Portable Hydraulic Power Unit 1. Gasoline-Powered Engine 2. Serial Number 3. Hydraulic Tank Coupler 4. Hydraulic Pressure Coupler Greenlee Textron / Subsidiary of Textron Inc. 5. Flow Control Knob 6. Hydraulic Reservoir Cap 7. -
Page 6: Specifications
Flash Point ... Equal to or Greater Than 340 F Pour Point ... Equal to or Less Than -30 F Greenlee Textron / Subsidiary of Textron Inc. Some hydraulic fluids which meet these criteria include, but are not limited to, the following:... -
Page 7: Hoses And Fittings
Refer to a Fairmont catalog or publication 999 1032.2, Low Pressure Quick Couplers, Adapters and Hoses. Pressure Greenlee Textron / Subsidiary of Textron Inc. Hose Connections Power Source Port Identification The pressure port on the power unit is the upper port (labeled PRESSURE). -
Page 8: Operation
Failure to wear eye protection can result in serious eye injury from flying debris or hydraulic oil. Greenlee Textron / Subsidiary of Textron Inc. Do not disconnect tool, hoses or fittings while the power source is running or if the hydraulic fluid is hot. -
Page 9: Operation
(with the hydraulic control knob in the OFF position). Warm hydraulic fluid puts less internal pressure on the hoses than cold hydraulic fluid. Greenlee Textron / Subsidiary of Textron Inc. Stopping the Power Unit Set the flow control knob to the OFF position before shutting the engine off. -
Page 10: Maintenance
In case some pressure has built up, loosen hoses, fittings or components slowly. Greenlee Textron / Subsidiary of Textron Inc. MAINTENANCE SCHEDULE Use this schedule to maximize the power unit’s service life. See the tool owner’s manual and the engine owner’s manual for the maintenance of those items. -
Page 11: Troubleshooting
Incorrect hydraulic fluid viscosity. Hydraulic fluid dirty. Power source output is low. Greenlee Textron / Subsidiary of Textron Inc. If the problem is in the tool, see the troubleshooting section of the tool instruction manual. If the problem is in the power source, see the troubleshooting table below. -
Page 12: Exploded View
F05 Portable Hydraulic Power Unit Exploded View Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070... - Page 13 F05 Portable Hydraulic Power Unit Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070...
-
Page 14: Parts List
49647 49648 49649 49650 49651 49652 49653 49654 Greenlee Textron / Subsidiary of Textron Inc. PART NO. DESCRIPTION 504 9625.5 Fitting, 3/8" x 2.5 Nipple ... 2 504 9626.3 Nut, Jam ... 11 504 9627.1 Bolt, 1/4" NC x 3/4 ... 14 504 9628.0... -
Page 15: Parts List
49677 49678 49679 49680 49681 49682 49683 49749 49746 Greenlee Textron / Subsidiary of Textron Inc. PART NO. DESCRIPTION 504 9655.7 Bolt, 1/4" x 1-1/2 ... 2 504 9656.5 Filter, Manifold, Hydraulic ... 1 504 9657.3 Screw ... 3 504 9658.1 Bolt, 1/4"... - Page 16 Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Drive, Rockford, IL 61109-2988 USA Customer Service (International): 815/397-7070 • Fax: 815/397-9247 Customer Service (North America): 800/435-0786 • Fax: 800/451-2632, 815/397-1865 Canada Fax: 800/524-2853 Printed in the U.S.A.
