Summary of Contents for musikelectronic geithain MO-2
- Page 1 MO-2 Instructions for installation and use...
-
Page 2: Table Of Contents
Basic information Guidelines Safety instructions Unboxing Delivery contents Cleaning Environmental conditions Guarantee acknowledgements Positioning Positioning near walls Stereo operation Surround operation Set-up the speakers Mains connection Cable connection Adjustment controller Status indication Specifications Acoustic measurements Notes musikelectronic geithain GmbH MO-2... -
Page 3: Introduction
The usual burn-in period is not required, because the speakers are artificially aged in-house. Please read the technical description and manual to take advantage of the capabilities of these speakers and ensure safe operation. musikelectronic geithain GmbH MO-2... -
Page 4: Disclaimer
Technical data and appearances are subject to changes without notice. Errors and omissions excepted. Musikelectronic Geithain GmbH assumes no liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. -
Page 5: System Description
SYSTEM DESCRIPTION System description The loudspeaker of the type MO-2 is a compact studio monitor of our MO series. It is qualified for the use in near-field and middle-field applications as well as in outside broadcasting vans. With multichannel application we recommend the supplement by one of our active bass loudspeakers. -
Page 6: Basic Information
; Clean only with dry or slightly moistened cloth. ; Protect the power cord from being walked on, pinched or damaged in any other way. Pay particular attention to plugs and the point where they exit the device. musikelectronic geithain GmbH MO-2... - Page 7 BASIC INFORMATION ; Do not attempt to service this product yourself as opening or removing cover may expose you to dangerous voltage or other hazards. ; Refer all servicing to qualified service personnel. musikelectronic geithain GmbH MO-2...
-
Page 8: Unboxing
The speakers are shipped in proper condition. Unpack the speaker carefully and check for visible damages. In case of damages report them to your retailer. Keep the packaging, in case the speaker has to be transported in the future. Delivery contents ; Speaker MO-2 ; Mains cable ; Technical description and user manual Cleaning The speaker is made of real wood veneer and needs to be nurtured in the same way as furnishings. -
Page 9: Positioning
For optimum listening experience a minimum distance of 50 cm (19.7″) to walls and furniture should be ensured. Avoid corner installations because unwanted bass accentuation could arise. ; Minimum distance to wall b ≥ 50 cm (19.7″) musikelectronic geithain GmbH MO-2... -
Page 10: Stereo Operation
60° hearing zone ; Distance between speakers and your listening position a = 1 m … 2.6 m (3′3″ … 8′6″) ; Adjust the speaker horizontally to the height of the ear at the listening position musikelectronic geithain GmbH MO-2... -
Page 11: Surround Operation
; Distance between speakers and your listening position a = 1 m … 2.6 m (3′3″ … 8′6″) In case installation in the prescribed way is not possible in your listening room most decoding devices allow adjustments of single speakers. musikelectronic geithain GmbH MO-2... -
Page 12: Set-Up The Speakers
When using a signal source with unbalanced outputs (RCA) you need to balance the connecting cables. This avoids hum and other noise interferences. The table and the following figure show the wiring. Unbalanced RCA to balanced XLR Connections Loudspeaker (XLR-3M) Cable Source (RCA) musikelectronic geithain GmbH MO-2... -
Page 13: Adjustment Controller
The two-coloured LED at the front of the speaker is used as status indicator of the device. ; LED green: indicates normal operation of the device ; LED red: indicates the operation of the overload protection circuit; Output power limitation to protect the components from overloading musikelectronic geithain GmbH MO-2... -
Page 14: Specifications
398 mm × 254 mm × 245 mm (15.7″ × 10″ × 9.7″) Weight 11 kg (24.3 lbs) Design of the cabinet MDF wood in ash black veneered; different veneers and colours on request Lateral mounting with lateral mounting; without lateral mounting on request musikelectronic geithain GmbH MO-2... -
Page 15: Acoustic Measurements
ACOUSTIC MEASUREMENTS Acoustic measurements All acoustic measurements are carried out under anechoic conditions with 1 m (3′3″) distance. [dB] [Hz] Free field frequency response 0° 45°h [Hz] Total harmonic distortions P = 90 dB musikelectronic geithain GmbH MO-2... -
Page 16: Notes
NOTES Notes musikelectronic geithain GmbH MO-2... - Page 17 NOTES musikelectronic geithain GmbH MO-2...
- Page 18 NOTES musikelectronic geithain GmbH MO-2...
- Page 19 NOTES musikelectronic geithain GmbH MO-2...
- Page 20 BDA_MO-2_18.05.2018_ENV17 musikelectronic geithain gmbh STUDIO MONITORING - HIGHEND LOUDSPEAKER - SOUND REINFORCEMENT SYSTEMS SYSTEMS Nikolaistraße 7 04643 Geithain / Germany Phone: +49 (0) 34341 3110 Fax: +49 (0) 34341 31144 Email: info@me-geithain.de www.me-geithain.de...
