- Page 1 True FLAT Touch Display LCD Monitor User Manual Installation Guide 10.4” True FLAT Touch LCD Monitor (USB Interface) MODEL: KKF1040B-TR i-Tech Company LLC TOLL FREE: (888) 483-2418 EMAIL: info@itechlcd.com WEB: www.iTechLCD.com...
-
Page 2: Table Of Contents
" " Warning! It will cause malfunction if the monitor is operating with incorrect power voltage. Do not exposure this unit in the rain or moisture environment to reduce the risk of fire or electric shock. Contents FCC Warning Statement.....................2 Introduction........................3 Features................................3 Unpacking the monitor ............................3... -
Page 3: Fcc Warning Statement
I. FCC Warning Statement WARNING Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Introduction
II. Introduction The 10.4" True Flat Monitor is color TFT LCD monitors, with compact and ecological design. The power consumption is only 2.5W with LED backlight. Features - Optimal display resolution 800 * 600 - No ventilation hole design - Light weight, only 800g physically for 10.4" True Flat Monitor. - VESA 75 * 75 mm wall mount standard - Integrate with resistive touch Unpacking the monitor... -
Page 5: Installation
III. Installation I/O placement USB Monitor USB Cable Control Buttons ▲ UP / ▼DOWN key：When adjustment item is selected, the two keys are defined to decrease or increase the value of brightness. -
Page 6: Touch Driver Installation
Touch Driver installation （ for Touch model ） only 1. Double click “setup.exe” from driver menu 2. Click “next” from welcome window 3. Click “next” from choose destination location window 4. Click “next” from ready to install the program 5. Click “next” from setup type 6. - Page 7 Calibration procedures: Double click “POS Touch+” icon to run calibration function Follow 9 points linearity calibration procedures and save the data Follow free draw calibration Exit calibration menu Reboot PC...
-
Page 8: Installation Guide
IV. Installation Guide PC requirements USB Monitor software can be used on PCs, from Netbooks, Notebooks/Laptops to Desktops. The driver will run on processors ranging from Atom N270 based PCs, basic single Core CPUs, and of course the latest Dual, Quad Core and Core i3/i5/i7 CPUs. The performance of the software is dependent upon the processing power available, as well as the Operating system in use. - Page 9 For 6 screens where 1 screen can run full screen DVD video: o 1.8 GHz Core Duo o 1 GB RAM At least one USB 2.0 port 30 MB of free disk space Computer Screen for use with the the DisplayLink device, if it is not integrated ...
- Page 10 Graphics Card Support (Windows 2000/XP) All graphics cards are supported on Windows 2000/XP. Supported Languages The following languages are supported in version 5.2, on all supported operating systems: Arabic Bahasa Indonesian Bulgarian Chinese (Traditional) Chinese (Simplified) ...
- Page 11 Installing the USB Monitor Software • Make sure to connect the USB cable and begin the installation after your PC has booted. • The Setup program requires about one minute for the installation. If you turn the power off or remove the USB cable while the Setup program is running, it may cause an error with the PC or the Windows operating sys-tem.
- Page 12 When setup is finished, a monitor icon is created in the system tray at the bottom of the monitor screen, and the information for the installed USB monitor is displayed. 5. When the installation is completed, configure the following settings to use multiple monitors. (1).
- Page 13 Configuring the USB Monitor Display Information 1. When the driver setup for the USB monitor is finished, a monitor icon is created in the system tray at the bottom of the monitor screen. 2. Click the monitor icon to display a list of connected USB monitors. Select the monitor for which you want to configure the display settings.
- Page 14 2. Click “Device Manager”. 3. A list of the installed device will be displayed, as shown in the figure below. - The Initial Screen Settings after Installing the Program • Applicable mode: Extend mode • Mode position: To the right of the primary screen •...
- Page 15 Restrictions on the USB Monitor Supported OS (Operating Systems) • Windows XP - Service Pack 1 or earlier: Unsupported - Service Pack 2 or later: Supported • Windows 2000 - Service Pack 3 or earlier: Not Supported - Service Pack 4 or later: Supported •...
-
Page 16: Troubleshooting
V. Troubleshooting Check List Note Before calling for assistance, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the In-formation section or contact your dealer. There is no image on the screen. - Page 17 Q & A How I can clone or extend screen mode? Open the “Display Properties” window and select the “Settings” tab, How can I remove the “USB Monitor Installation Program” completely? Click “Add/Remove Programs” in the “Control Panel”. A list of “currently installed programs”...
-
Page 18: Mechanical Dimension
VI. Mechanical dimension... -
Page 19: Product General Specification
VII. Product General Specification Monitor with Touch Monitor Model Monitor Touch Monitor stand with stand Cabinet color Black Display size 10.4" Active Area 211.2 * 158.4 mm Optimal Resolution 800 * 600 Color Arrangement RGB-stripe Brightness (Panel) 300 cd/m² (typ) Contrast Ratio 500:1 Response Time...
