User Manual
|-T~E^j|"~I
C^DN^RA^TY
20" LCD
i A P - 2 0 0 0
Aluminum front bezel
i N A P - 2 0 0 0
Front NEMA4/IP65
i O P - 2 0 0 0
Universal Mounting Open Frame
i-Tech Company LLC
TOLL FREE: (888) 483-2418 • EMAIL:
Dedicated LCD display solutions
^
F ^
(
info@iTechLCD.com
• WEB:
^
^
REACH
J
www.iTechLCD.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for I-Tech iAP-2000
Summary of Contents for I-Tech iAP-2000
- Page 1 Aluminum front bezel i N A P - 2 0 0 0 Front NEMA4/IP65 i O P - 2 0 0 0 Universal Mounting Open Frame REACH |-T~E^j|"~I i-Tech Company LLC C^DN^RA^TY TOLL FREE: (888) 483-2418 • EMAIL: info@iTechLCD.com • WEB: www.iTechLCD.com...
- Page 3 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 4: Table Of Contents
Contents Part. 1 > iAP-2000 / iNAP-2000 Package Content Structure Diagram & Dimension Mounting Hardware & Installation Part. 2 > iOP-2000 Package Content Structure Diagram & Dimension Mounting Hardware & Installation Part. 3 > Specifications / OSD Product Specifications On-screen Display Operation (OSD P. - Page 5 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 6: Part. 1 > Iap-2000 / Inap-2000
< Part 1 > < 1.1 > Package Content - iAP / iNAP-2000 iAP-2000 / iNAP-2000 20" LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 Mounting hardware X 1 pack Mounting bracket x... - Page 7 20" LCD Display < 1.2 > Structure Diagram - i A P / i N A P - 2 0 0 0 Front view iAP-2000 iNAP-2000 • - © ■J Rear view (?) Rear case — — — i ;...
- Page 8 < 1.2 > Dimension - iAP / iNAP-2000 Front View Side View iAP-2000 o> o> iNAP-2000 <* — ] 50.8 50.8 »7.6 518.5 J661 _Z£L Rear View 488.6 UNIT: mm 1mm ■ 0.03937 inch ° ° ° — - - »...
- Page 9 < 1.3 > Panel Mount Installation - iAP / iNAP-2000 20" LCD Display M4*50mm screw M4*6mm Mounting screw bracket x8 pcs x8 pcs x 4 pcs l£ Hardware set part no. UV-BK#2 '■■■* Steps ■ Install 4 mounting brackets with 8 x M4*6mm screws ■...
- Page 10 < 1.3 > VESA mount Installation - iAP / iNAP-2000 M4 screw VESA mount (100*100mm ) I Hardware and M4M pcs for VESA mount are not provided...
-
Page 11: Package Content
< Part 2 > 20" LCD Display < 2.1 > Package Content i O P - 2 0 0 0 i O P - 2 0 0 0 20" LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 Basic I/O Power... - Page 12 < 2.2 > Structure Diagram - iOP-2000 Front view Rear view (T) Rear case © LCD panel • • • • • • •I » » » » » » (3) Audio speaker (for HDMI, Audio or TV option ) «...
- Page 13 < 2.2 > Dimension - iOP-2000 2 0 " LCD Display Front View Side View 31.246.8,2424 35 , 35,43.3,43.3,35,35,24,24,46.831.8 • C O . iOP-2000 • ■ft • • • <==. • £ 1 4JQ8_ 66.1 509.5 UNIT: mm Rear View 1mm ■...
- Page 14 < 2.3 > Installation - iOP-2000 (1 ) Universal mount 31246.82 * & ...! ■• w «: 1 7 5 ( I I ) VESA mount (100*100mm ) ..••-- M4 screw Hardware and M4M pcs for VESA mounting are not provided...
-
Page 15: Product Specifications
< Part 3 > 20" LCD Display < 3.1 > Product Specifications iAP-iNAP-2000 iOP-2000 Mechanical Mechanical Mechanical Mechanical Mechanical Mechanical Design Design Design Design Design Design Black, RAL 9005 Front Panel Black. RAL 9005 Rear Casing Black, RAL 9005 100x 100mm VESA Mounting 100 x100mm Universal mount... - Page 16 iOP-2000 iAP-iNAP-2000 Product (W x D x H ) 509.5x66.1 x 388.6 mm 512.5x72.1 x 391.6 mm 20.1 x2.6x 15.3 inch 20.2x2.8x15.4 inch Packing ( W x D x H ) 651 x 124x597 mm 651 x 124x597 mm 25.6x4.9x23.5 inch 25.6x4.9x23.5 inch Net Weight 6kgs/13.2lbs...
-
Page 17: On-Screen Display Operation
20" LCD Display < 3.2 > On-screen Display Operation ( O S D ) O Power light ® <► <► * • Green = On • Orange ■ Power saving Membrane Switch Function Power on / off LCD ■ Display the OSD menu 4><P<§0 Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button <jl>... -
Page 18: Part 4 > Options
< Part 4 > Options < 4.1 > Option Table Options iAP / iNAP SDI " " • HDMI* or DVI-D S-Video * + Composite ( BNC ) Audio Touchscreen MCS multi-display control DC Power MIL-type / lockable connector Quad display TV (Analog ) * ^ 4 , * * *... -
Page 19: Sd-Sdi
< 4.2 > Options : 3G / HD / SD-SDI input 20" LCD Display iTechLCDs' SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with NetView Full HD 1080p and ultra high resolution 1920 x 1200 LCD displays, iTech LCD provides a SDI input module without using additional space or power and it... -
Page 20: Mcs
< 4.3 > Options : MCS More control is always good. Especially when it is necessary and easy. i T e c h L C D provides MCS solution to control the OSD of ( Multi-display Control) various N e t V i e w LCD display up to 64 units. The RS-232C is used for the communication between the PC and the first display via a 15 feet serial cable while the CAN bus is used for the various LCD displays cascade together via CAT 5/6... -
Page 21: Av2.2D
< 4.4 > Options 20" LCD Display AV2.2D Upgrade Options - DVI-D DVI-D TMDS single link ) - AV ( S-Video + Composite, BNC ) Audio ( 3.5mm audio jacks for audio & out, and 2W + 2W speakers ) A u d i o I Power S-Video _... - Page 22 How to Use RC-1 Remote Controller © ©00© 0©©0 0@00 © POWER Sv/itches on or off the TV © MUTE Turn on or off the speaker © INPUT Switch to signal input mode Select channels. For channel numbers 10 and above. ®...
- Page 23 20" LCD Display < 4.5 > AV3.0 Upgrade Options - H M D I (HDMI 1.1.CEA-861-D) - DVI-D ( DVI-D TMDS single link ) - AV ( S-Video + Composite, BNC ) - Audio ( 3.5mm audio jacks for audio &...
-
Page 24: Resistive
< 4.6 > Options : Touchscreen & driver 20" USB Touchscreen Specification Model Model Model Model Model Model Model Model Model Model Model Model Model Model Model Model Model e-Resistive Technology Technology Technology Technology Technology Technology Technology Technology Technology Technology Technology Technology Technology... - Page 25 20" LCD Display < 4.6 > Options : Touchscreen & driver TRB Driver Please follow the below steps to setup the touch screen:- Step 1. Run the bundled CD disc or download the driver Step 2. Double click the Setup.exe Step 3.
- Page 26 < 4.7 > Options : DC Power © © Model Input rating Input voltage: 24-Volt 48-Volt Input range: 1 8 - 3 6 V 36 ~ 75V Input current - No load 50 mA 50 mA - Full load 4880 mA 2442 mA Output rating Output voltage:...
-
Page 27: Mil-Type Or Lockable Connector
< 4.8 > Options : MIL-type or Lockable Connector 20" LCD Display Input Part no. MIL Standard type type MIL - D T L - 26482 MS3470W8-33P tfS^Q DC Power *** Connector Connector (Male) MS3470W14-15P MS3470W14-15P MIL - D T L - 26482 MIL - D T L - 26482 VGA *** VGA ***... - Page 28 < 4.9 > Options : Quad Display Video IN 1 - 4 RS-232 VCR in Video Loop S-Video Power Alarm I/O VCR out 1 - 4 QD Specification Description Item Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16 7 M NTSC Imaging System...
-
Page 29: Tv (Analog)
20" LCD Display < 4.10 > Options : TV ( Analog ) A u d i o Power BNC S-Video .—^ © © O O O H D M I <i ■ ■ ■ • • ■ • • ■ • ; . 0 out - in - in Video PC * * *... - Page 30 How to Use RC-2 Remote Controller © © © ® © © © © ® <E) (MENUJ f / \ ) £EL=CTJ k s P E C T J <D M0W@ <£> f i-^z O © 0 0 © (™y x^y W°9 ©...
- Page 31 I-TECH i-Tech Company LLC C O M P A N Y TOLL FREE: (888) 483-241 8 • EMAIL: info wiTechLCD.com • WEB: www.iTech .com...
