True FLAT Display LCD Monitor
User Manual

Installation Guide
10.4" True FLAT LCD Monitor (VGA Interface)

i-Tech Company LLC
TOLL FREE: (888) 483-2418
EMAIL:
info@itechlcd.com
WEB:
www.iTechLCD.com
MODEL: KKF1040V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KKF1040V and is the answer not in the manual?

Questions and answers

Related Manuals for I-Tech KKF1040V

Summary of Contents for I-Tech KKF1040V

  • Page 1 True FLAT Display LCD Monitor User Manual   Installation Guide 10.4” True FLAT LCD Monitor (VGA Interface) MODEL: KKF1040V   i-Tech Company LLC TOLL FREE: (888) 483-2418 EMAIL: info@itechlcd.com WEB: www.iTechLCD.com...

  • Page 2: Table Of Contents

    " " Warning! It will cause malfunction if the monitor is operating with unspecified power supply unit or incorrect power voltage. Do not exposure this unit in the rain or moisture environment to reduce the risk of fire or electric shock. Contents FCC Warning Statement....................2 II.

  • Page 3: Fcc Warning Statement

    I. FCC Warning Statement WARNING Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Introduction

    II. Introduction The 10.4" True Flat Monitor is color TFT LCD monitors, with compact and ecological design. The power consumption is only 6W with LED backlight. Features - Optimal display resolution 800 * 600 - No ventilation hole design - Light weight, only 800g physically for 10.4" True Flat Monitor. - VESA 75 * 75 mm wall mount standard - Integrate with resistive touch Unpacking the monitor...
  • Page 5 True Flat Monitor with stand a. LCD Monitor Power adaptor VGA cable（ 8 PIN Mini DIN cable） d. User Manual CD True Flat Touch Monitor a. LCD Monitor b. Power adaptor c. VGA cable（ 8 PIN Mini DIN cable ） d.

  • Page 6: Installation

    III. Installation I/O placement 1 VGA （DIN Type） 2 DC Input 3 USB Input （for Touch model only） To PC 1. Connect VGA cable from monitor to PC 2. Connect USB touch cable to PC 3. Connect DC plug to monitor and the other side to wall outlet...

  • Page 7: Touch Driver Installation （For Touch Model Only

    Touch Driver installation （ for Touch model only ） 1. Double click “setup.exe” from driver menu 2. Click “next” from welcome window 3. Click “next” from choose destination location window 4. Click “next” from ready to install the program 5. Click “next” from setup type 6.
  • Page 8 Calibration procedures: Double click “POS Touch+” icon to run calibration function Follow 9 points linearity calibration procedures and save the data Follow free draw calibration Exit calibration menu Reboot PC...
  • Page 9 OSD settings Main Third First Level Second Level Operating Procedure Level Press “UP” or “DOWN” to adjust H-phase & Auto Adjust H-position & V-position clock automatically. Press “UP” key to increase brightness, “DOWN” Brightness key to decrease brightness. Luminance Press “UP” key to increase contrast, “DOWN” key Contrast to decrease contrast.
  • Page 10 OSD Timeout Exit English French German Press “UP” or “DOWN” to choose any one of the Italian following languages , English , French , Germany , Language Italian , Spanish , Russian , Traditional Chinese Spanish and Simplified Chinese. Russian T.

  • Page 11: Control Buttons

    Control Buttons a.) Pressing to execute AUTO-Adjusting function. This function will set the monitor display area to the optimal position. Auto Adjusting b.) Sometimes this function can't achieve the optimal effects. Please follow the manual adjusting procedure. When the light bar move other item, the key are used to select it, and read to adjust.

  • Page 12: Support Timing Chart

    V. Support timing chart Timing Reference Pixel Resolution FH KHz FV Hz Interlace Mode Standard Polarity Polarity Mode 1 VESA 800×600 36.000 35.156 56.250 Mode 2 VESA 800×600 40.000 37.879 60.317 Mode 3 VESA 800×600 50.000 48.077 72.188 VI. Mechanical dimension...

  • Page 13: Product General Specification

    VII. Product General Specification Monitor with Touch Monitor Model Monitor Touch Monitor stand with stand Cabinet color Black Display size 10.4" Active Area 211.2 * 158.4 mm Optimal Resolution 800 * 600 Color Arrangement RGB-stripe Brightness 300 cd/m² (typ) Contrast Ratio 500:1 Response Time 30 ms (typ)
