KU26 Ver. 1.3

8.1 K-2SPK ACCESSORY

This accessory is used to connect a Speakon cable to a KU26. It features two Speakon connectors wired
in parallel giving you the possibility to wire two or more KU26s in parallel using only Speakon cables.
The two wires situated at the back of the K-2SPK carry the signal from the 1+ contact (red wire) and
1- contact (black wire) of the Speakon connector. Wire them to the phoenix connector as shown in the
previous section (by default, they are wired in serial configuration). Use the four screws and the four
hexagonal spacers included to mount the K-2SPK on the KU26.
A MPL IFIER
OUTPUT
KU26s wired in parallel via Speakon cables
9
