ASSEMBLY INSTRUCTIONS
2
(4)
LEFT
(7L)
(4)
(4)
3
RIGHT
(7R)
6
(4)
(4)
RIGHT
(7R)
(4)
LEFT
(7L)
GQBrands.com
STEP 2:
Slide 1x Hand Rail Base - Left (Part 7L)
and slide 1x Leg Cap (Part 4) into a T-Joint
to secure it.
Then Slide 1x Hand Base Rail - Right (Part
7R) one leg apart from the Left side as
shown on to a T-Joint, and secure with 1x
Leg Cap (Part 4).
NOTE:
The Hand Rail Bases (Parts 7L & 7R) need
to have one leg in between to be able to
have enough distance to connect.
Place the remainder of the Leg Caps on
the rest of the T-Joints.
STEP 3:
Flip the trampoline over to stand on its own
Lay out the Jump Mat with Mesh (Part 5)
in the center of the frame with the Logo
facing up.
CustomerService@GQBrands.com
1-866-498-5269
