Omega OS4000 Series User Manual

Omega OS4000 Series User Manual

High speed fiber optic infrared

Advertisement

Quick Links

User' s Guide
MADE IN
Shop online at
omega.com
e-mail: info@omega.com
For latest product manuals:
omegamanual.info
OS4000 SERIES
High Speed Fiber Optic
Infrared Transmitter

Advertisement

loading
Need help?

Need help?

Do you have a question about the OS4000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Omega OS4000 Series

  • Page 1 User’ s Guide MADE IN Shop online at omega.com e-mail: info@omega.com For latest product manuals: omegamanual.info OS4000 SERIES High Speed Fiber Optic Infrared Transmitter...
  • Page 2 Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification. The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
  • Page 3: Table Of Contents

    Table of OS4000 Series High Speed Fiber Optic Infrared Transmitter Contents Table of Contents Section ................Page Packaging Inspection ..................iii Section 1 Introduction ................. 1-1 Section 2 Installation - Laser Sighting ............. 2-1 Section 3 Main Operations ................. 3-1 Section 4 PC Interface ..................
  • Page 4 List of OS4000 Series High Speed Fiber Optic Infrared Transmitter Figures List of Figures Figure Description: ............Page General Dimensions, Fiber Optic Lens Probe Assembly ....2-1 General Dimensions, Lens Probe Mounting Bracket (L1-MB) ..2-1 General Dimensions, Lens Probe Air Purge Collar (L1-AP) ..... 2-2 General Dimensions, Mounting Bracket for the Transmitter ....
  • Page 5: Packaging Inspection

    Packaging Inspection Packaging Inspection The following items are supplied with the OS4001 fiber optic transmitter: • OS4001 fiber optic infrared transmitter • Transmitter mounting bracket & two mounting nuts • 15 Feet shielded power/output cable with 8 pin female connector •...
  • Page 6 OS4000 Series High Speed Fiber Optic Infrared Transmitter NOTES:...
  • Page 7: Section 1 Introduction

    Laser sighting for positioning the Lens Probe, and mounting bracket & mounting nuts. The OS4000 series can be ordered with one analog output and an optional Relay contact closure outputs. The following describes the transmitter model number selection:...
  • Page 8: Section 2 Installation - Laser Sighting

    Installation - Laser Sighting Installation - Laser Sighting Figure 1 shows the general dimensions of the fiber optic lens probe & cable. Figure 2 shows the general dimensions of the lens probe mounting bracket (L1-MB). Figure 3 shows the general dimensions of the lens probe air purge collar (L1-AP). Figure 4 shows the general dimensions of the mounting bracket for the transmitter.
  • Page 9 Installation - Laser Sighting 17.78 HOLDING SCREWS (0.70) ø 41.28 ø 25.91 (1.625) (1.02) ø 22.10 (0.87) BARB ADAPTOR 3/16" ID DIMENSIONS mm (in) ø = DIAMETER 1/4-28 UNF THREAD Figure 3. General Dimensions, Lens Probe Air Purge Collar (L1-AP) 12.7 (0.50) 76.2 DIMENSIONS mm (in)
  • Page 10 Installation - Laser Sighting KNURL OUTSIDE SURFACE 2.5-16 UNF-2B 76.2 (3.0) DIA. 6.35 DIMENSIONS mm (in) (0.250) Figure 5. General Dimensions, Mounting Nut for the Transmitter 2.5-16 UNF-2A SERIAL ID & LASER MODEL NO. LABEL WARNING CERTIFICATION LABEL M8x.75 THREAD TEMPERATURE MATING CONNECTOR 9.53...
  • Page 11 Figure 7. Front Plate With Figure 8. Fiber Cable Connection Laser Warning Certification Label to the Transmitter LOW ALARM LED INDICATOR EMISSIVITY DIAL HIGH ALARM FIBER OPTIC OS4000 SERIES OS4000 SERIES LED INDICATOR GAIN ADJUST HIGH HIGH ALARM ALARM ALARM ALARM...
  • Page 12 Installation - Laser Sighting 146.05 (5.75) 8.89 (0.35) 2.5-16 UNF-2B DEPTH OF ENGAGEMENT OF OS4001 21.59 (0.85) ø 82.55 (3.250) 2.5-16 UNF-2A BUILT-IN OUTLET INLET BARB ADAPTER 3/16" ID AIR PURGE 1/4-28 UNF THREAD COLLAR APPLY DIMENSIONS mm (in) CLEAN AIR ø...
  • Page 13 Installation - Laser Sighting LASER • Press the key on the back plate to turn on the laser beam. The laser power red LED indicator will turn on. The laser beam is projected through the lens probe. The laser spot represents the optical envelop of the lens probe field of view.
  • Page 14: Section 3 Main Operations

    Main Operations Main Operations Figure 9 shows the back panel with all the controls & LED indications as described below: High Alarm LED – Red, It turns on when in high alarm condition. Low Alarm LED – Red, It turns on when in low alarm condition. Laser LED –...
  • Page 15 Main Operations NOTE: On the mV/Degree analog output models (OS4001-MV), the default output is 1 mV/°F. You can change the output from 1 mV/°F to 1 mV/°C or vice versa by going through the Configuration menu with Response time set for 25 msec or higher. At 1 msec response time, the output is fixed at 1 mV/°F. Polymer Bolt Probe Assemblies The Polymer Bolt probes are offered at Right angle with quick disconnect as shown in Figure 13.
  • Page 16 Main Operations Glass & Quartz Tip Fiber Cable Assemblies We offer twelve different Glass & Quartz tip fiber cable assemblies as listed below. The glass or quartz tip can be replaced in the field. Metal Encased Tip Assemblies Model No. Temperature Range Cable Length 2615-G-*-2650-3...
  • Page 17: Section 4 Pc Interface

    PC Interface PC Interface The OS4000 series comes with a Windows based PC interface software. The ® software runs on Windows Vista, XP, and 2000. The software allows the user to do the following: • Establish communication with the OS4001 and display the temperature in real time both digitally and graphically.
  • Page 18 PC Interface the time goes on, the temperature graph line gets updated as well as the time stamping. 6 – The Settings button allows the user to get into the settings menu. 7 – The Go/Stop button allows the user to start/stop the temperature logging. 8 –...
  • Page 19 PC Interface set points. You can also set the chart temperature scale manually, if the Automatic Scaling is not checked. 16 – Holding Time drop down menu allows the user to select the Peak Holding time from 1 to 60 seconds. This is only active when the Peak-Hold function is selected from the Output Response Time menu.
  • Page 20 PC Interface Peak-Hold Function The OS4000 can be selected for Peak-Hold analog output via. the PC interface software. The holding time can be selected from 1 to 60 seconds. Figure 18 shows a typical Peak-Hold analog output time diagram with a Holding Time of 2 seconds.
  • Page 21: Section 5 Specifications

    Specifications Specifications 15 to 24 Vdc @ 100 mA Power: Power Indicator: Green LED Temperature Ranges Fiber Lens Probes: 200 to 800ºC (392 to 1472ºF) 250 to 1000ºC (482 to 1832ºF) 300 to 1200ºC (572 to 2192ºF) 350 to 1400ºC (662 to 2552ºF) 400 to 1600ºC (752 to 2912ºF) 100 to 425ºC (212 to 797 ºF) Polymer Bolt Probes:...
  • Page 22 Specifications Signal output Averaging: Set by Response Time Selection (Sample & Hold) (25 msec to 3.2 sec) Spectral Response: 1.2 to 2.6 microns IR Detector: InGaAs photo detector Fiber Optic Cable Connector: FC connector, Keyed Analog Outputs: 0 to 5 Vdc @ 250 ohms min load 0 to 10 Vdc @ 1200 ohms min load 4 to 20 mA @ 400 ohms max load 1 mV/Deg @ 250 ohms min load...
  • Page 23 Specifications Air Flow for Lens Probe: 1 to 3 CFM (0.5 to 1.5 Liters/sec) Air purge collar (L1-AP) Operating Relative Humidity: 0 to 95% RH without condensation General Dimensions 63.5 OD x 154 L mm (2.5" OD x 6.062" L) Main Housing: Fiber Optic Lens Probe: 25.4 OD x 184 L mm (1"...
  • Page 24 Notes NOTES:...
  • Page 25 Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.
