The Automatic operating mode can be selected by pressing the AUTO/MAN Control Key.
The light emitting diodes (LED's) (13) indicate the related operating state.
Information on the display (1)
Nozzle or
bottom heater symbol
Temperature of the nozzle or
bottom heater (with WHP 3000)
Air flow rate in l/min
Time remaining for the
temperature profile step in sec.

2.3 Setting temperature profile

Select the parameters by pressing the Control Key:
TEMP (7):
Symbol for nozzle or bottom heater indicates which temperature is displayed.
AIR (6):
TIME/
PREHEAT (5) :
The active value is marked on the display and can be changed using the UP / DOWN (2) /
(3) Control Keys. Keeping the Control Key depressed, rapidly changes the value.
Find Quality Products Online at:
TEMP
Nozzle 210°C
Pre-Heater
300°C
Nozzle
210°C
Depressed Once
Depressed Twice
Repeat for Steps 1-3
Depressed Once:
Repeat for Steps 1-3
Depressed Once:
Repeat for Steps 1-3
GlobalTestSupply
www.
AIR TIME
40 l 100s
25 l 50s
30 l 15s
: Nozzle temperature during the first step
Temperature of the bottom heater during the first
step
(only with WHP3000)
Air flow rate in l/min during the first step
time remaining in the first step
.com
step 1
step 2
step 3
