- Page 1 OPERATING INSTRUCTIONS WPSI12 Portable Soldering Station & TCP12 Soldering Tool Weller Tech Sheet Product Code: 060586 Issue A 24/05/05...
- Page 2 8-hour shift between charges. The battery fitted to the WPSI12 is of the Sealed Lead-acid type as this battery can be charged when only partially depleted without problems with battery memory. The recommended charge time is 12 hours. The charger will automatically switch to a holding charge when it detects that the battery is fully charged.
- Page 3 Heater type: Fibreglass and ceramic insulated heating element. Reverse wound for low leakage and magnetic field cancellation. Tip type: Weller PT series Copper with heavy iron, nickel and chromium plated for long life. Connector: Automotive cigarette lighter style. Recovery time: 11 seconds from 37ºC drop with PTA7 tip.
- Page 4 50 sec. To switch the tool off, remove the plug from the receptacle. Always use the lowest temperature tip that will handle the load you are soldering. The Weller® magnastat control system delivers maximum power to the tip regardless of the tip temperature chosen therefore, there is no need to use high temperature tips to handle heavier soldering loads. Using lower temperature tips and properly selecting tip styles, will protect sensitive components from heat damage.
-
Page 5: Safety Instructions
Do not use the cord for purposes for which it is not designed. Never carry the soldering tool by the cord. Don’t use the cord to pull the power plug from the socket. Protect the cord from heat, oil and sharp edges. Weller Tech Sheet Product Code: 060586 Issue A 24/05/05... - Page 6 Do no work on electrically live parts. Applications with other Weller equipment. If the soldering tool is to be used together with other Weller equipment and attachments, also observe the warning notices given in the corresponding operation manual. Observe the valid safety regulations for your workplace.
- Page 7 - Repair or replace switch if defective. - Remove the heater assembly and check for short circuits in the wiring inside the handle. Repair wiring as required, or replace the cord/handle assembly. Weller Tech Sheet Product Code: 060586 Issue A 24/05/05...
- Page 8 When installing new tips, they should slide freely into the heater. Don’t try to clean the tip with abrasive materials other then the Weller® WPB1 polishing bar. Never file the tip, to do so will greatly reduce tip life.
-
Page 9: Replacement Parts
WPSI12 AND TCP-12 SOLDERING PENCIL REPLACEMENT PARTS AND ACCESSORIES REPLACEMENT PARTS OPTIONAL PARTS KEY NO.PART NO. DESCRIPTION PART NO, DESCRIPTION HE60-12 Heater Not shown TC205 Sponge SW60D Switch Assembly PH1201 Stand, includes Iron holder and sponge HO60A Handle WPB1 Weller Polishing bar... - Page 10 Weller Tech Sheet Product Code: 060586 Issue A 24/05/05...
-
Page 11: Customer Service
CUSTOMER SERVICE Should your WPSI12 require repair or adjustment it may be sent to the following address: Cooper Tools (Australia) 519 Nurigong St Albury NSW 2640 AUSTRALIA Attn. Repair Department Ph. (02) 6058-0300 Fax (02) 6021-7403 Weller Tech Sheet Product Code: 060586 Issue A 24/05/05... - Page 12 Cooper Tools Pty. Limited 519 Nurigong Street Albury, N.S.W. 2640 Australia Tel: 61-2-60580300 www.cooperhandtools.com Fax: 61-2-60217403 Weller Tech Sheet Product Code: 060586 Issue A 24/05/05...
