Dual Antenna System Configuration (Optional)

The dual system consists of two VSAT antennas and two ACUs. The ACUs have embedded Dual Antenna
Mediator function, which is capable of controlling and managing two VSAT antenna systems simultaneously.
As shown in the configuration below, connect the cables correctly.
Primary
Antenna
Primary
ACU
Antenna
AC 100~240 V
Primary Rx
Primary Tx
Secondary Rx
Secondary Tx
Modem
(Not supplied)
OpenAMIP
AC 100~240 V
NOTE
The description of this Dual Antenna System is written on the "Appendix A" chapter. Refer to the
"Using Dual Antenna System" on page 121 for more details.
NOTE
TX, RX, 48 VDC Power
Secondary
AC 100~240 V
NMEA Input
2000/0183(GYRO)
LAN 2
LAN 1
TX
Figure: Dual Antenna System Configuration
Secondary
Antenna
ACU
Antenna
Primary Primary
Rx Tx
LAN 3
RX
37
Installing ACU
TX, RX, 48 VDC Power
LAN 3
Switch Router
(Not supplied)
Ship's Gyro
(Not supplied)
Above Decks
Below Decks
